Smoke Sensor
Features
UL217 Listed
•
Sleek design
•
Wall tamper
•
Strong, reliable RF signal
•
Low Battery indication
•
Key Instructions
1. Read the "INSTALLING YOUR SMOKE ALARM" section
a. Install your Smoke Alarm.
2. Enroll the Smoke Alarm in a panel:
a. Place the JAQX Smart Hub into wireless enrollment mode by pressing the
external red button for 3 seconds until hub beeps.
b. Send an enrollment signal from the sensor by press & holding TEST button
until you hear the sounder beep.
3. Confirm that the sensor has been properly enrolled by checking for new FLOOD zone
on your JAQX App or in your customer portal.T
4. Test the Smoke Alarm is enrolled in a panel:
a. Press & hold TEST button until you hear the sounder beep.
b. Panel will indicate a Smoke Test.
c. Read the "WEEKLY TESTING OF YOUR SMOKE ALARM" section:
5. Test the functionality of the Smoke Alarm.
Operation
Situation
Sounder
Temporal 3
Actual smoke
(Loud)
Press & hold test
Temporal 3
button
(Loud)
Removing Sensor
Temporal 3
from Mount
(Loud)
Chirp
Low Battery
Temporal 3
Maintenance Needed
(Loud)
LED
Wireless Signal to Panel
RED
Wireless Smoke Alarm Signal
(pulsing)
sent to hub.
Wireless Smoke Test Signal
RED
sent to hub.
(pulsing)
Yellow
Tamper/Trouble signal to be
(Steady)
sent to hub.
Yellow/Red
(blink)
Yellow
Supervisories Not Sent
(Pulsing)
Specifications
Approval:
Smoke Sensitivity:
Heat Temperature:
Smoke Technology:
aHeat Alarm Point: 135 – 149 F (UL
Alarm Sound:
Replacement Battery:
Temperature Range:
Humidity:
Housing dimensions:
Frequency:
System Compatibility:
User's Manual:
Design & Manufacture:
Recovery
Silence an actual alarm with the TEST button. Sensor will return to
alarm if smoke is still present.
Sensor: Restore by releasing the test button
Restore by remounting.
Replace Unit
UL217 Single Station Smoke Alarm & Heat Alarm
1.31 – 2.28 %/ft
135 to 140 F
Photoelectric
Temporal Three
Panasonic CR123A
Duracell DL123A
32 to 120 F (Long Term)
10 – 85% Relative Humidity
4.7 inch diameter, 2.1 inch high
433.92 MHz
RE6100 series panels with capacity of up to 96 zones
47-0001-08 Rev A
Resolution Products, Inc.
1402 Heggen Street
Hudson, WI 54016
