4. Adjusting the flange focal length
When you use the PS-IMS-F3 adapter on your Sony PMW-F3 it might be necessary to
adjust the flange focal length. Therefore refer the subitem „Adjusting the flange focal
length" of the chapter „Attaching a Lens" in your Sony PMW-F3 user manual.
5. Manufacturer Information
The manufacturer of this product is:
P+S Technik GmbH
Siemensstraße 12
85521 Ottobrunn / MunichGermany.
Phone: +49 89 45 09 82 30
Please find worldwide authorised representations and dealers on our homepage www.
pstechnik.de or send an e-mail to info@pstechnik.de for contact details.
Concerning any service and warranty requests, please contact your local representation
or P+S Technik GmbH directly.
www.pstechnik.de
User Manual
for PS-IMS-F3 adapter for Sony PMW-F3
ENGLISH
Before operating this product, please
read the instruction carefully and save
this manual for future use. Subject to
technical change without any prior notice.
Art. Nr. 27561 | v1105
www.pstechnik.de
Advertisement
Table of Contents
Summary of Contents for P+S Technik PS-IMS-F3
- Page 1 4. Adjusting the flange focal length When you use the PS-IMS-F3 adapter on your Sony PMW-F3 it might be necessary to adjust the flange focal length. Therefore refer the subitem „Adjusting the flange focal length“ of the chapter „Attaching a Lens“ in your Sony PMW-F3 user manual.
- Page 2 1) Put the IMS Mount on the Flange. 4) Move the Clamping Plate in the The PS-IMS-F3 adapter is designed to be assembled with an IMS Mount once and to be Verify the pin fits into the IMS Mount Flange until the holes in the Flange are left there.
