Celabs HX40M Instruction Manual

CE labs can support many areas of your audio and video
distribution needs.
We manufacture:
- Digital Signage software and Media Players
- HD Matrix Switchers
- RF modulators
- RF ampli ers
- HDMI and Component HD distribution ampli ers
- CAT 5 Signal Extenders
- VGA Extenders and Splitters
- and cables of all types.
See our full product line at www.celabs.net
WARRANTY
Cable Electronics, Inc. warrants this product to be free from defects in
material and workmanship, under normal use and service, for a period
of one year from the purchase by the original purchaser. If this product is
defective or malfunctions, Cable Electronics will replace or repair this unit
(at their option) within a reasonable time. No expressed or implied warranty
is made for any defects caused by immersion or exposure to liquids, abuse,
neglect, improper operation of unit, excess wear and tear and defects
resulting from unauthorized disassembly and or modi cation.
3209 Wood Drive
Garland, TX 75041
Phone: (469) 429-9200
Toll free: (800) 767-6189
Fax: (469) 429-9205
www.celabs.net
.
Document: HX40M_Manual.pdf
930-3040-01 – Rev. A
HX40M
HDMI
™
Extender Series
HDMI & IR UTP Extender Series over Single CAT5e/6 cable
™
extends your HDTV display up to 70 meters at 1080i/720p
and 40 meters at 1080p. It is equipped with HDMI
and supports DVI equipment with allowing use of a HDMI to DVI
.
adapter. It provides an easy and exible cabling solution for
integrating home theater components.
Features:
• Extends HDMI signal over one CAT5e/6 cable
• Transmission range up to 70 meters by 1080i/720p
• Transmission range up to 40 meters by 1080p@60Hz@24bit
• Built in auto equalization for easy plug and play
• Transmitter unit has built in EDID auto backup function
• HDCP compatible
& IR CAT5
