Summary of Contents for Milestone MPTP-T100S
- Page 1 User Manual MPTP-T100S HDMI/IR/RS232/Ethernet Twisted Pair Over Single Cable All Rights Reserved Version: MPTP-T100S_2016V1.0...
-
Page 2: Safety Precautions
HDMI/IR/RS232 Twisted Pair POC Extender SAFETY PRECAUTIONS To insure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for possible future shipment ... - Page 3 HDMI/IR/RS232 Twisted Pair POC Extender NOTICE: Please read this user manual carefully before using this product. Pictures shown on this manual are for reference only, different model and specifications are subject to real product. This manual is only for operation instruction only, not for any maintenance usage. The functions described in this version are updated till April 2016.
-
Page 4: Table Of Contents
HDMI/IR/RS232 Twisted Pair POC Extender Table of Contents 1. Introduction ......................... 1 1.1 Introduction to MPTP-T100S ................1 1.2 Features ......................1 1.3 Packing List ....................... 1 2. Product Appearance ....................2 2.1 MPTP-T100T ..................... 2 2.2 MPTP-T100R ..................... 3 2.3 Twisted Pair Cable Connection ................ -
Page 5: Introduction
CAT5e cable, the input HDMI signal can be long-distance transmitted, and the control signal (IR & RS232) is able to work in a bi-directional way, and POC are supported by MPTP-T100S. With its Ethernet ports, MPTP-T100S also supports internet access to work in a LAN. -
Page 6: Product Appearance
HDMI/IR/RS232 Twisted Pair POC Extender 2. Product Appearance 2.1 MPTP-T100T Figure 1 Interfaces of MPTP-T100T Name Description On: Used to show the working status, blinks when in normal working state, turns off when stop working. Link: Twisted Pair Link status indicator. It will keep on when Link connection is successful. -
Page 7: Mptp-T100R
HDMI/IR/RS232 Twisted Pair POC Extender 2.2 MPTP-T100R Figure 2 Interfaces of MPTP-T100R Name Description Out: When connected with device which supports HDCP and works normally, this LED will keep on. If the device does not support HDCP, the LED will blink. ... -
Page 8: Twisted Pair Cable Connection
HDMI/IR/RS232 Twisted Pair POC Extender 2.3 Twisted Pair Cable Connection The twisted pair used in MPTP-T100S must be a straight-through cable. The connectors can be T568A or T568B, but both sides must be the same. TIA/EIA T568B TIA/EIA T568A Cable color... -
Page 9: System Connection
Please cut off the power of the HDMI source device and the output displaying device before accessing with MPTP-T100S, as it may damage to MPTP-T100S. Ensure that all connections (including the power cord) are done before turning on the power to work with MPTP-T100S. -
Page 10: System Applications
MPTP-T100R connecting with power adapter is enough with its POC function). 3.4 System Applications As its good performance in control and transmission, MPTP-T100S can be widely used in computer realm, monitoring, large screen displaying, conference system, education and bank securities institutions etc. -
Page 11: Specification
HDMI/IR/RS232 Twisted Pair POC Extender 4. Specification Model MPTP-T100T MPTP-T100R Spec Input 1 HDMI, 1 IR in, Input Signal 1 IR in, 1 HDBaseT, 1 RS232 1 RS232 1 HDMI female 1 3.5mm mini jack for IR in Input Connector 1 3.5mm mini jack for IR in 1 RJ-45 1 3P captive connector... - Page 12 HDMI/IR/RS232 Twisted Pair POC Extender Power Supply Input: 100VAC~240VAC, 50/60Hz; Output: 24VDC 1.25A Dimension (W*H*D) 152x30x 84mm Net Weight 0.8Kg...
-
Page 13: Panel Drawing
HDMI/IR/RS232 Twisted Pair POC Extender 5. Panel Drawing MPTP-T100T 30 mm 14 mm 152 mm Figure 4 MPTP-T100T MPTP-T100R 14 mm 30 mm 152 mm Figure 5 MPTP-T100R... -
Page 14: Troubleshooting & Maintenance
HDMI/IR/RS232 Twisted Pair POC Extender 6. Troubleshooting & Maintenance Problems Causes Solutions Incorrect setting on the Check the display’s setting display Output images in display show with ghost Try another high quality A cable of bad quality connection cable Check with oscilloscope or No signal at the input / multimeter if there is any output end... -
Page 15: After-Sales Service
HDMI/IR/RS232 Twisted Pair POC Extender 7. After-sales Service If there appear some problems when running the device, please check and deal with the problems reference to this user manual. Any transport costs are borne by the users during the warranty. 1) Product Limited Warranty: It is warranted that the product will be free from defects in materials and workmanship for three years, which starts from the first day you buy this product (The purchase invoice shall prevail).
