user-manual saniswiss "biosanitizer-automate" (230V)
5
3
1
Saniswiss SA
chemin des tulipiers 19 • 1208 Geneva • Switzerland
t +41 22 718 75 75
f +41 22 718 75 76
info@saniswiss.com
www.saniswiss.com
•
•
•
8
4
10
6
9
7
2
how to use the selector
vol. to be treated
10
20
25
35
40
50
70
130
200
260
350
emergency stop
The device can be stopped at any moment by pressing on the button
to activate the spray (8).
bad functionning
the device does not start and the sign light of the switch on/off (3)
does not ignite:
- verify the power of your electrical network
- verify the fuse (2) behind of the device.
the device works but does not uses the product:
- verify that the jet (9) is not tapped
waranty
A copy of the present certificate of guarantee of the biosanitizer-auto-
mate should be kept affectedly by the customer; it shall be presented
general
F
device presentation
diffuser type
1 power Cable
name biosanitizer-automate
protection class IP10.
2 used fuse
operating temperature 10°C to 40°C.
3 switch for power on/off
storage temperature 0°C to 50°C.
4 support
operating humidity and storage 25% to 75%.
5 button of nose of the diffuser
class 1 power classification
6 nozzle
do not use in presence of a flammable anesthetic mixture.
7 bottle
intermittent.
8 button to activate the spray, "start" button
9 jet
medical classification according to Medical Device Directive 93/42/EEC
10 volume selector
class IIa medical device (marking CE1253).
symbol record
characteristics
protective earth.
power
1000 W
tension
230 V mono+T
precautions
frequency
50 to 60 Hz
The manufacturer will not be held liable for any bodily harm or material
intensity
4,5 A
damages caused by inappropriate or abnormal use of the devise contrary
maximum intensity
10 A
to the precautions recommended in the list below (non exhaustive list) :
speed of rotation of the turbine
22000 rpm
- use only the product saniswiss-biosanitiizer™
tank capacity
750 ml
- make sure that electric power matches your country's current standards
gross weight
9,7 kg
- dot not insert an object or fluid in the nozzle of biosanitizer-automate
whether on or off
net weight (without liquid or bottle) 9,0 kg
- avoid moving biosanitizer-automate when it contains the product,
size
h 39cm x
place it in order to keep the bottle horizontaly
53,6cm x 29cm
- check the presence of the nozzle (9)
performances
- remove the bottle from the biosanitizer-automate for transport
speed-exit of air
80 m/s
- check that room is not equipped with alarm sensor. If this happens,
maximal volume to be treated
350m
3
a specialist may preferably adapt the sensitivity of the alarm sensors.
average biosanitizer output
350ml/h
- do not use the unit on it's support
to the retailer or to the saniswiss Inc. ch. des tulipiers 19, 1208 Geneva,
Switzerland, to attest of the guarantee, the other copy shall be kept by
spraying-time
consumption
the retailer.
2 mn 20 sec
40 ml
clauses
3 mn 30 sec
60 ml
What follows is not exclusive of the legal guarantee foreseen by the
4 mn 50 sec
80 ml
articles 1641 and following ones of the civil code concerning hidden
6 mn
100 ml
defects.
7 mn 10 sec
120 ml
9 mn 30 sec
160 ml
objects
The guarantee consists of the free supply of the parts that are consid-
12 mn
200 ml
ered defective by our technical services, the exchanged parts becomes
24 mn
400 ml
the property of the company.
36 mn
600 ml
Repairs required afterward wrong operations, abnormal uses, care-
48 mn
800 ml
lessness or excess loads of the device as well as those required
60 mn
1000 ml
because of variations of the electricity network , voltage surges or
defective installations, etc. can not be guaranteed. Also the guaran-
tee nullifies in case of intervention and repair by qualified techni-
cian not member of the saniswiss Inc. The seals of the device have
to be untouched. Besides, if an abnormal corrosion of supple parts,
radiator hoses, joints, was noticed indicating the use of another
liquid, the guarantee would be also void.
transportation
The material travels under the responsibility of the user; in case of dam-
ages during the transportation, the addressee has to make any reserves
to the carrier before taking delivery of the device.
duration
The biosanitizer-automate is guaranteed during a period of 2 years as
from the day of the reception of the device by the user.
The device diffuses a chemical substance, therefore it is necessary to
pay attention :
- do not inhale the product
- do not smoke near the biosanitizer-automate while it is working
- do not steer it towards an incandescent zone
- do not be located in the room during the spray
use
- move the unit to the front and install the support located under the unit
- screw the cartridge of saniswiss-biosanitizer (750 ml)
- tighten to prevent sagging
- close back the support
- connect the device with the electrical network 230/50 Hz with the
power cable (1)
security check
- select with the button (8) the volume of the room to be treated
(it corresponds to a time of use, check table 5)
- press on the switch (3) to power on the biosanitizer-automate
- steer exit ( 6 ) towards zones to be diffused using the handle (4)
- press on the "Start On" button (8) a buzzer rings during 15
seconds and leaves you the time to go out of the room
to be treated. The device stops automatically.
- wait at least for 90 minutes before going into the room
- press on the switch (3) to power off the device
- change the filter (10) once or twice a year, according to it wear
- check the effectiveness, regularly with our culture dishes
> if a problem appears, then disconnect the device and to
consult your retailer
maintenance
The device should be kept in a dry and clean place remote from any
possible projections. During cleaning, do not use spray into the holes
of the nozzles nor the interstice of the automate. Clean and remove
debris that could stick on the metal-filter located under the automate.
in case of doubts reading the user-manual, please contact our
support specialist at saniswiss Inc. t +41 22 718 75 75
biosanitizer-automate saniswiss
The biosanitizer-automate saniswiss is made of quality.
saniswiss undertake for a duration of 2 years to guarantee any
1253
waranty certificate
customer copy
device biosanitizer-automate
SN :........
timer 10 – 350 m
3
defect of material or manufacture.
