Alfa Network WiFi-Camp Pro 2 Installation Manual

Extend and Share Wi-Fi Signal

Installation Guide

Hardware Installation

1
2
1. Mount the antenna AOA-2409TF to Tube-U ( N ) securely, and seal the gap on
the N-type connector with weather-resistant tape.
2. Mount the omni antenna to Camp Pro Wi-Fi Extender Router, and connect
Tube-U ( N ) with R36A via USB cable provided in the package.
3. Connect the power adapter to the Camp Pro Wi-Fi Extender Router.
Before proceeding any further, please make sure the USB LED on CampPro
WiFi Externder is "ON".
To Infinity and Beyond
3
2

Package Content

Thank you for choosing Camp Pro 2 Hotspot Wi-Fi Extender.
The following items should be inside your retail box:
• 1 x Camp Pro Wi-Fi Extender Router (R36A)
• 1 x Tube-U ( N ) USB Outdoor Signal Receiver
• 1 x AOA-2409TF Outdoor 9 dBi Antenna for Tube-U ( N )
• 1 x Omni 5 dBi antenna for use with R36A
• 1 x DC Power Adapter for Camp Pro Wi-Fi Extender Router
• 1 x Outdoor Water-Resistant Tape for securing antenna
with Tube
• 1 x Car 12v Charger for Camp Pro Wi-Fi Extender Router
power supply
• 1 x USB cable for connecting Camp Pro Wi-Fi Extender
Router and Tube-U(N)
How to Start WiFi-CampPro 2 Device Configurations
- Via wired connection :
Connect computer to CampPro Wi-Fi Extender
Router LAN1 port via Ethernet RJ-45 cable.
Open your web browser, and type-in
"wificamppro2.myalfasetup.com"
"192.168.36.1" in the address bar.
When Ethernet connection is made, the LAN1 LED will be "ON".
- Via wireless connection :
On your laptop, tablet computer or
smartphone, enable WiFi service on your
device, and search WiFi name"WiFiCamp
Pro2-xxxxxx", then associate with it.
Open your web browser, and type-in
"wificamppro2.myalfasetup.com"
"192.168.36.1" in the address bar.
- Via QR code connection :
On smartphone/tablet device, search WiFi name "WiFiCampPro2-xxxxxx",
and associate with it.
Run QR code reader app, and read the QR code sticker on WiFi Extender.
In QR code app, select "Open URL", and device portal page will be shown.
About running QR code app on Android and iOS devices:
iOS 11 or later: please use built-in camera app to read the QR code.
If there is no QR code scanner/reader in your smart phone, please search
reader"
on the Apple App Store or Android Play Store, and install it to read the QR
code from device.
1 1
ANT LAN2 PoE LAN1 PWR
or
or
wificamppro2.myalfasetup.com
free "QR
