Mounting

Before mounting the product, read and follow the safety recommendations indicated in the

Orientation

The Data Stream 8 may be mounted in any position; however, make sure adequate ventilation is provided
around the product.

Rigging

• Before deciding on a location for the product, always make sure there is easy access to the product
for maintenance and programming purposes.
• Make sure that the structure onto which you are mounting the product can support the product's
weight. See the Technical Specifications
• When mounting the product overhead, always use a safety cable. Mount the product securely to a
rigging point, whether an elevated platform or a truss.
• When rigging the product onto a truss, use a mounting clamp of appropriate weight capacity.
Mounting Diagram
Safety Cable
(such as CH-05 from
Chauvet)
Page 6 of 11
for weight information.
Mounting Clamp
(such as CLP-15 or CLP-15N
from Chauvet)
Mounting Hole M12
Safety
Data Stream 8 User Manual Rev. 1
S
ETUP
Notes.
