Spinna Winna Operators Manual Part No. 990xxx Issue 1 • 3 PLAYER WITH COIN SHELVES, CHANGER AND NON CHANGER, MK4 AND MK5 COIN ENTRY SYSTEMS. • 2 PLAYER TICKET PAYOUT WITH COIN SHELVES AND SLIDING SKILL COIN ENTRY. 4 Wilton Road, Haine Business Park,...
1.4. How to Contact Cromptons Leisure International Ltd…………………. 2. Product Overview…………………………………………………………… 5 2.1. Main Features………………………………………………………….. 2.2. Description…………………………………………………………….. 3. A Step by Step Guide to Setting up your Spinna Winna……………….… 6 4. Troubleshooting……………………………………………………………... 11 5. Maintenance Tasks………………………………………………………….. 14 5.1. Recommended Daily Routine Maintenance……………………………… 14 5.2.
Where applicable, the fuse cover must be in place before the machine is switched on. • To maintain the safety of the machine use only Cromptons or Cromptons- approved parts. The use of other parts or non-approved modifications to the machine could be hazardous.
EMC………. Electro Magnetic Compatibility PSU………. Power Supply Unit LED………. Light Emitting Diode RH………. Right Hand How to contact Cromptons Leisure International Ltd. By Telephone: • 0044 (0)1843 593335 – For Spares and Service. • 0044 (0)1843 593335 – For Sales. By Fax: •...
Spinna Winna Operators Manual Part No. 990xxx Issue 1 2. PRODUCT OVERVIEW 2.1 Main Features Florescent and halogen playfield lighting Removable top sign Hinged playfield doors with gas strut support Playfield CDS coin entry Hinged CDS access door Payout door...
Spinna Winna Operators Manual Part No. 990xxx Issue 1 3. A STEP BY STEP GUIDE TO SETTING UP YOUR SPINNA WINNA UNPACKING Locate the access door keys attached to the outside of the machine as shown. The keys marked “11” open the glass playfield, the coin entry and the payout doors.
Page 7
Spinna Winna Operators Manual Part No. 990xxx Issue 1 ELECTRICAL CONNECTION Ensuring that the mains electrical supply is earthed and complies with the specification on the supply voltage label, Connect the machine to a supply voltage WARNING Take care when handling supply voltage parts as miss-handling could lead to electrical shock.
Page 8
Spinna Winna Operators Manual Part No. 990xxx Issue 1 FILLING THE CHANGERS (IF FITTED) If your machine is NOT fitted with changers go to step 10 otherwise on each section, open the payout door and fill the payout hopper with approx. 500 coins. The red “change available”...
Page 9
Spinna Winna Operators Manual Part No. 990xxx Issue 1 IS EVERYTHING OK? An information display is located on the electronics panel fitted on the LH bulkhead of section 1 behind the payout door. Check this display to ensure that the machine is operating correctly.
Page 10
Spinna Winna Operators Manual Part No. 990xxx Issue 1 FLOATING THE PLAYFIELD With the glass doors open and the machine turned on, spread approx 600 PUSHER BOX coins evenly over each playfield area and pusher box. To settle the machine ready for...
Spinna Winna Operators Manual Part No. 990xxx Issue 1 4. TROUBLESHOOTING Do this first…… Many of the faults that may occur are as easy to fix as 1….2….3…. Check the information display in the master section of the machine for a fault condition.
Page 12
Spinna Winna Operators Manual Part No. 990xxx Issue 1 PROBLEM POSSIBLE CAUSE SUGGESTED REMEDY One or more playfield Lamp failure. Replace lamp. halogen lamps are not See section 5.6 page 20. working while others are. Output fuse blown. Replace output fuse.
Page 13
Spinna Winna Operators Manual Part No. 990xxx Issue 1 PROBLEM POSSIBLE CAUSE SUGGESTED REMEDY I have a C.D.S. mk5 Badly adjusted micro switch. Re adjust micro switch. validated coin entry which See C.D.S. manual. does not release coins when Faulty solenoid.
Spinna Winna Operators Manual Part No. 990xxx Issue 1 5. MAINTENANCE TASKS WARNING: • Maintenance and repair work should only be carried out by suitably skilled and trained persons. • To avoid electrical shock, switch off and disconnect electrical power supply before working on the machine.
Spinna Winna Operators Manual Part No. 990xxx Issue 1 The bob tilt Topsign access door The bob tilt is housed in the top sign as shown and can be reached by removing the access panel on the rear of the top sign.
Page 16
Spinna Winna Operators Manual Part No. 990xxx Issue 1 Main connector The sensitivity of the intelligent tilt mechanism can be adjusted by turning the potentiometer labelled ‘VR1’ on the P.C.B. Turning it anti-clockwise increases sensitivity and turning it clockwise decreases sensitivity.
Spinna Winna Operators Manual Part No. 990xxx Issue 1 5.3 Removing the top sign You will need……… • A Philips screwdriver • A 13mm open ended spanner Open the glass playfield doors on the end sections and remove the light diffusers to gain access to the top sign support fixings.
Spinna Winna Operators Manual Part No. 990xxx Issue 1 3.4 Replacing a playfield florescent lamp. 5.4 Replacing a playfield florescent lamp. You will need………… You will need………… • A Philips screwdriver • Playfield access door keys • A 13mm open end spanner •...
Spinna Winna Operators Manual Part No. 990xxx Issue 1 5.5 Replacing a top sign florescent lamp You will need……. • A Philips screwdriver. • Florescent lamp part No. S100176. Retaining fasteners Disconnect the machine from the mains supply before starting this procedure.
You will need……. • Playfield access door keys. • Halogen lamp part No. S100132. Note: use only replacement parts of the correct rating specified by Cromptons. Using parts of the wrong type could cause damage. Open the playfield access door to the affected section.
• Halogen fuse part No. FU100XXX. • Mains supply fuse part No. FU100049. Note: use only replacement parts of the correct rating specified by Cromptons. Using parts of the wrong type could cause damage. Disconnect the machine from the mains supply before starting this procedure.
• 8mm nut runner or socket. • Playfield drive motor part No. S010146 for 220v or part No. S010147 for 110v. Note: use only replacement parts of the correct rating specified by Cromptons. Using parts of the wrong type could cause damage.
Spinna Winna Operators Manual Part No. 990xxx Issue 1 Removing and accessing the MK4 and MK5 CDS unit Securing Screws Open the hinged CDS door and remove the two securing screws holding the CDS unit in place. To prevent damage or injury take care to support the CDS from falling when removing the securing screws.
Spinna Winna Operators Manual Part No. 990xxx Issue 1 5.10 Accessing the sliding coin entry To gain access to the coin flipper unit, open the hinged coin entry door housing the sliding coin entry. Coin entry door Automatic alignment linkage...
Spinna Winna Operators Manual Part No. 990xxx Issue 1 5.11 Refilling the tickets TICKET BOX Open the payout door and insert the new ticket stack into the ticket box. Feed the end of the tickets into the slot at the top of the dispenser and press the button on the side of the unit to manually advance the tickets.
Spinna Winna Operators Manual Part No. 990xxx Issue 1 3.9 Changing the coin of play. Please contact our customer services department for details of a kit of parts that can be supplied to properly and safely change the coin of play.
Spinna Winna Operators Manual Part No. 990xxx Issue 1 6. SYSTEM SETTINGS, WARININGS AND MESSAGES A sheet containing all the system settings is attached inside the machine adjacent to the control PCB. This sheet gives the various settings for dipswitches with regard to payouts etc.
Spinna Winna Operators Manual Part No. 990xxx Issue 1 SCHEMATIC WIRING DIAGRAM SCM 113 SPINNA WINNA 3 PLAYER SPEAKER 485 COMMS 130636 CN13 COLOUR KEY HALOGEN FUSE BK - BLACK BACK PANEL L N E BL - BLUE MAIN CONTROL PCB...
Spinna Winna Operators Manual Part No. 990xxx Issue 1 SCHEMATIC WIRING DIAGRAM SCM 114 SPINNA WINNA 2 PLAYER 110V TKT SPEAKER 485 COMMS 130636 CN13 COLOUR KEY HALOGEN FUSE BK - BLACK BACK PANEL L N E BL - BLUE...
Page 30
Spinna Winna Operators Manual Part No. 990xxx Issue 1 Page 30 of 31...
Page 31
Spinna Winna Operators Manual Part No. 990xxx Issue 1 Page 31 of 31...
