- Page 1 Parsifal 90 & 120 Downdraft Extractor Installation & User Instructions Please read these instructions carefully before installing and operating this appliance...
-
Page 2: Table Of Contents
3.4.1 Electrical Wiring Diagram 3.4.2 Controls 4. Use & Maintenance 4.1 Cleaning the Metal Filters 4.2 Carbon Filters 4.2.1 Polyester Carbon Filters 4.2.2 Long Life Carbon Filters 4.3 Cleaning the Hood 5. Technical Data 6. Dimensions 10-11 6.1 Parsifal 90 6.2 Parsifal 120... -
Page 3: Introduction
Dear Customer, For the correct use of the appliance and to We wish to thank you for choosing this Air Uno cooker prevent accidents, the instructions given in this hood. In order to get the best performance from your booklet must always be followed. -
Page 4: Installation
Parsifal 90 cut-out dimensions on top of worktop ATTENTION: Accessible parts may become hot when the hood is used with cooking appliance. 3. Installation... - Page 5 housing just fits under the kitchen top. Then use should any technical assistance b required. An the adjustable feet to raise the housing until it authorised service engineer must carry this out. touches the underside of the worktop (Fig 4). Failure to comply with this condition will significantly increase the costs that could be charged in the case of Parsifal...
-
Page 6: Motor Options
3.2 Motor Options 3.3 Re-circulating Options The Parsifal can be made re-circulating by using the The Parsifal can be used with any of the AMR09, Plinth charcoal filter kit. AMR10, AMR20, AME12, AMF10, AMF13 or AMD09 motors. 3.3.1 Plinth Charcoal Filter Kit If you are using the AMD09 motor then this must be attached directly to the side of the Parsifal this can be This option can only be used with the AMF10 or AMF13... -
Page 7: Electrical Wiring Diagram
3.4.1 Electrical Wiring Diagram Motor connection 230V power supply Cable with faston for microswitch Remote antenna (must remain free) Optional flat control cable... -
Page 8: Controls
The metal filters fitted in the hood should be washed 3.4.2 Controls every 2-3 months, depending on how much the hood is used, using hot water and a liquid detergent that is The Parsifal can be controlled by either the remote not too aggressive. -
Page 9: Cleaning The Hood
detergent. The filter should be washed on its own to prevent particles of food from fastening in it and then 5. Technical Data causing an unpleasant smell later on (Fig 13). To reactivate, the carbon filter should be dried in the Parsifal 900mm &... -
Page 10: Dimensions
6. Dimensions 6.1 Parsifal 90 X = adjustable between 40mm and 120mm... -
Page 11: Parsifal 120
6.2 Parsifal 120 1170 1200 X = adjustable between 40mm and 120mm... - Page 12 Copyright of all contents of this leaflet is vested in CD (UK) Ltd t/a Air Uno. Any part may not be reproduced without permission. The contents of this leaflet are accurate at the date of printing but, because CD (UK) Ltd t/a Air Uno has a policy of continual development, it may be superseded and should be disregarded if specifications or appearances are changed.
