Source Capture Air Purification System HA-SCP-G3 Owner’s Manual Table of Contents HealthyAir® HA-IFM-1111 Filter Important Safety Instructions Technical Specifications Packaging Reference Packing Notice Component Reference Assembly Instructions 7-11 12-13 Operation Guidelines 14-16 Filter Replacement Maintenance Basic Service and Troubleshooting 18-22 Electrical Wiring Schematic 1-Yeart Limited Warranty Product Registration Form...
Page 2: Healthyair Ha-Ifm-1111 Filter
® HealthyAir Model HA-SCP-G3 Source Capture Air Purification System with ® HealthyAir HA-IFM-1111 Filter www.aerovexsystems.com...
Page 3: Important Safety Instructions
WARNING Unplug the power cord before servicing or replacing filters. Failure to do so could result in serious personal injury and death. I. Important Safety Instructions Read the Owner's Manual and Important Safety Instructions carefully. Failure to follow these instructions could cause a malfunction of the filter or unsatisfactory performance.
Page 4: Technical Specifications
II. Technical Specifications Model Number HA-SCP-G3-W/B/G Rated Voltage 120V/60HZ Power Consumption 200W Weight 37 lbs. (17 kg) Base Dimensions 14x12x24 in. (350×310×615 mm) Flex Hose Length 45 in. (114.3 cm) Air Flow Rate 240 cfm (400 m Noise Level 56 dB...
Page 5: Packaging Reference
III. Packaging Reference The Source Capture Air Purification System is shipped in two (2) cartons, as follows: Carton 1: (1) Source Capture Air Purification Unit w/ (1) Integrated Filter Module, (4) Wheel Casters, (1) Acoustic Mat, (1) Remote Control, (1) Power Cord, (1) Screwdriver, (1) Manual Carton 2: (1/2) Flex Hose + Hood, (1/2) Hose Clamp, (1/2) Grill + LED Cable + LED Bulb (Optional)
Page 6: Packing Notice
IV. Packaging Notice NOTICE Before operating the machine, do the following: 1. Open the Access Door (Refer to Section 8.2) 2. Remove the Integrated Filter Module (HA-IFM-1111) 3. Remove the plastic wrapping from the filter! 4. Re-install the Integrated Filter Module 5.
Page 7: Component Reference
V. Component Reference 23. G4 Bulb Mount (Option) 1. Outer Frame 12. eHEPA ® Filter 24. LED Grill (Option) 2. Acoustic Mat 13. eGrid 25. LED Cable Plug (Option) 3. Blower/Motor 14. Silicon Seal 26. LED Cable Socket 4. Metal Screen 15.
Page 8: Assembly Instructions
VI. Assembly Instructions 6.1 Install Caster Wheels The following procedure is for Standard Application of the unit, whereby purified air is vented through the Base Plate and recirculated within the facility. For Outside Vent Applications, in which purified air is vented out of the facility, skip Section 6.1 and refer to the wheel installation instructions in Section 6.4.
Page 9 VI. Assembly Instructions 6.2 Install LED Lighting (Optional) Note that, the LED Lighting system is an optional feature. To add this feature, visit www.aerovexsytems.com and If LED Lighting was not purchased, skip section and proceed to Section 6.3. 6.2.1 Mount the LED Light Bulb on the Grill, by inserting the lip of the bulb into the 4-piece cylinder located in the center of the Grill.
Page 10 VI. Assembly Instructions 6.3 Install Flex Hose The Flex Hose is constructed of interlocking bands that enable its length and shape to be adjusted. Note that, the Flex Hose will unravel if it is lengthened or bent past its tolerance point. The diameter of the Flex Hose can be also adjusted by 10% by rotating sections of the hose counterclockwise.
Page 11 VI. Assembly Instructions 6.4 Install Outside Vent Adapter (Optional) Note that, the Outside Vent Adapter is an optional feature. To add this feature, visit www.aerovexsystems.com. The Outside Vent Adapter comes with one (1) Outlet Flange, one (1) Outlet Port Cover Plate, and has two (2) Outlet Ports, that enable it to exhaust air from the back or side depending on which configuration is preferred.
Page 12 VI. Assembly Instructions 6.5 Install Outside Vent Adapter (Optional) 6.5.1 Re-install each of the four (4) Caster Wheels to the bottom of the Outside Vent Adapter, as shown in Fig. 4. 6.5.2 Install the Outlet Flange on one of the Outlet Ports, based a determination of the ideal setup configuration.
Page 13: Operation Guidelines
VII. Operation Guidelines 7.1 Source Capture System Positioning Place the HealthyAir Source Capture Air Purification System in the desired ® location and place it on the Acoustic Mat to dampen the sound. Once the unit is in place, adjust the Flex Hose to position the Hood approximately 6” from the source of the particulate and fumes.
Page 14: Operation Guidelines
VII. Operation Guidelines 7.3 Source Capture System Controls • TIMER button, on the Control Panel and Remote Control, is for operation of the timing clock. When this feature is in use the unit will automatically shut off after the set time expires. The system’s default timing is 4 hours of operation.
Page 15: Filter Replacement
VIII. Filter Replacement 8.1 Replacement Filter The HealthyAir ® Source Capture Air Purification System (HA-SCP-G3) utilizes the HealthyAir® Series 1111 Integrated Filter Module (HA-IFM-1111). Note that, only manufacturer supplied HealthyAir® Replacement Filters are compatible with HealthyAir® Source Capture Systems. No other replacement filters are to be used with this unit.
Page 16 VIII. Filter Replacement 8.2 Filter Change 8.2.3 Remove the used Integrated Filter Module. Caution: The HV Contact Spring may store a slight charge even after the unit is powered off. Avoid direct contact with the HV Contact Spring. 8.2.4 Install a new Integrated Filter Module (HA-IFM-1111) into the Filter Compartment, as shown in Fig.
Page 17: Filter Replacement
VIII. Filter Replacement 8.3 Filter Change Indicator Light Reset Once the filter has been replaced and the unit is powered on, the Filter Change indicator light may continue to flash. To reset the filter change timer and deactivate the flashing light, go through the following reset procedure: 8.3.1 Unplug the Power Cord from the Power Socket, wait a couple seconds and plug the Power Cord back into the Power Socket.
Page 18: Maintenance
IX. Maintenance Caution: The HV Contact Spring may store a slight charge even after the unit is powered off. Avoid direct contact with the HV Contact Spring. 9.1 Cleaning Filter To extend the effective life of the Integrated Filter Module, remove the filter from the unit and use a standard vacuum to remove collected particulate from the Pre-Filter section.
Page 19: Basic Service And Troubleshooting
X. Basic Service and Troubleshooting The Basic Service Guide should cover most performance issues. If you continue to experience issues after referring to this list, please contact Healthy Air Inc. 10.1 Air Purification System is Inoperable If the unit fails to power on, the issue may be the result of one of the following causes.
Page 20 X. Basic Service and Troubleshooting 10.3 Air Purification System Powers On but Fan is Inoperable If the unit powers on but the fan fails to operate, the issue may be the result of a faulty motor and will require service by the manufacturer or a professionally licensed electrician.
Page 21 X. Basic Service and Troubleshooting 10.5 Flex Hose Fails to Remain in Position If the Flex Hose assembly fails to remain in position, the issue may be the result of one of the following causes or may require replacement parts. Possible Cause Solution Flex Hose rigidity reduced...
Page 22 X. Basic Service and Troubleshooting 10.7 LED Light Fails to Turn On If the LED Light fails to turn on, the issue may be the result of one of the following causes and may require replacement parts. Possible Cause Solution LED Cable is not connected Reconnect LED Cable LED Mount is faulty...
Page 23 X. Basic Service and Troubleshooting 10.11 Reduced Airflow/Reduced Dust Collection Efficiency If the fan/motor is properly functioning, but the unit exhibits reduced airflow and/or reduced particulate collection efficiency the issue may be the result of one of the following cause and may require filter replacement. Possible Cause Solution Integrated Filter is fully loaded...
Page 24: Electrical Wiring Schematic
XI. Electrical Wiring Schematic Fig. (11) – Electrical Wiring Schematic...
Page 25: 1-Yeart Limited Warranty
Healthy Air Inc. 1-Year Limited Warranty Healthy Air Inc. only makes this 1-Year Limited Warranty ("Limited Warranty") to the original retail purchaser who submits the enclosed Warranty Registration Card within 10 days of purchase by email to Sales@HealthyAir.com. This Limited Warranty applies only to the repair or replacement of any manufactured or supplied part of this product which, upon inspection by Healthy Air Inc.
Page 26: Product Registration Form
Healthy Air Inc. 1-Year Limited Warranty Product Registration Form Please complete the Product Registration Form and submit it to Healthy Air Inc. within ten (10) days of the original purchase, to validate 1-Year Limited Warranty. Submit the completed form via email by sending a scanned image or photograph to info@aerovexystems.com.
