B&B Electronics DP-660 User Manual

B&b electronics industrial power supply user's manual
Hide thumbs
1
2
3
4
5
6
Table of Contents

Advertisement

Quick Links

Download this manual
Introductions ..................................................................................................................1
1.0
Input Specifications ...............................................................................1
2.0
Output Specifications.............................................................................1
3.0
General Features ....................................................................................2
4.0
Environment specifications....................................................................2
5.0
International standards ...........................................................................3
6.0
Mechanical Specification.......................................................................4
DP-660
Industrial Power Supply
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DP-660 and is the answer not in the manual?

Questions and answers

Related Manuals for B&B Electronics DP-660

Summary of Contents for B&B Electronics DP-660

  • Page 1 Industrial Power Supply Introductions ...1 Input Specifications ...1 Output Specifications...1 General Features ...2 Environment specifications...2 International standards ...3 Mechanical Specification...4 DP-660 User’s Manual...

  • Page 2: Input Specifications

    Introductions The DP-660 is a dual output, DIN-Rail mounted, 65 watts switching power supply. It has over voltage protection in main output and over load latch off mode protection on all output. 1.0 Input Specifications 1.1 Input voltage The range of input voltage is from 85VAC to 270VAC 1.2 Input Frequency...

  • Page 3: General Features

    For some reason the power supply fails to control itself, the build-in over voltage protection circuit will shut down the outputs to prevent damaging external circuits. The trip point is around 26V to 31V. The power supply will go into latch-off mode against short circuit or over load conditions, and have to OFF and ON the AC input to restart the power supply.

  • Page 4: International Standards

    5.0 International standards The following data is by open frame testing (Board only). Internal PCB model No.: SNP-9069 5.1 Safety standards Designed to meet the following standards: UL 1950 D3 CSA 22.2 No. 234 VDE EN 60 950 5.2 EMI standards Designed to meet the following conducted limits.: FCC docket 20780 curve “B”...

  • Page 5: Mechanical Specification

    6.0 Mechanical Specification Dimensions: 44mm(W)x 150mm(H)x 122mm(D) DP-660 I n d u s t r i a l P o w e r S u p p l y G N D G N D O u t p u t N .
  • Page 6 6.1 Din-Rail mounting The DP-660 can be direct install to 35mm DIN-Rail. 6.2 Connectors 6.2.1 AC inputs connector: Pitch 5.08mm screw terminal block Wire range : 12AWG~22AWG / 2.5mm² Pin Assignments: N.C. F.G. 6.2.2 DC output connector: Pitch 5.08mm screw terminal block Wire range : 12AWG~22AWG / 2.5mm²...
