Explorer LNE4322 Series Quick Start Manual

Contents
• IR Eyeball Dome IP Camera*
• Mounting Kit*
• Mounting Template*
• Cat5e UL Compliant (CM) Ethernet Extension Cable*
* Per camera.
ATTENTION
- It is recommended to connect the camera to the NVR or
an external PoE switch. If using a DC power adapter with the camera, a
REGULATED power supply is REQUIRED for use with this camera. Use of
a non-regulated, non-conforming power supply can damage this product
and voids the warranty.
Warning/Caution
• Use the camera only with compatible Lorex NVRs
• Read this guide carefully and keep it for future reference
• Follow all instructions for safe use of the product and handle with
care
• Do not disassemble the camera
• Do not point the camera directly towards the sun or a source of
intense light
• Periodic cleaning may be required. Use a damp cloth only. Do not use
harsh cleaners or aerosol cleaners
• The supplied cable is rated for in-wall and surface mounting. Cables
for floor-to-floor installations are sold separately (CMR type). These
www.lorextechnology.com
and other cables are available at

Installation Tips

• Point the camera where there is the least amount of obstructions
(i.e. tree branches)
• Install the camera in a location that is difficult for vandals to reach
• Secure cabling so that it is not exposed or easily cut
• Camera rated for outdoor use. Installation in a sheltered location
recommended
Dimensions
93mm / 3.66"
70mm / 2.75"
Resources
Need Help?
Visit us online for up-to-date
software and complete instruction manuals
1
Go to www.lorextechnology.com
2
Search the model number of your product
3
Click on your product in the search results
4
Click on the Downloads tab
The following resources are always at your fingertips
Product Information Specification Sheets
User Manuals Software Upgrades
Quick Start Guides Firmware Upgrades
© 2016 Lorex Corporation
As our product is subject to continuous improvement, Lorex Corporation & subsidiaries reserve the right to
modify product design, specifications & prices without notice and without incurring any obligation. E&OE
LNE4322_SERIES_TRIFOLDQSG_EN_R1
4MP HD IR EYEBALL DOME IP CAMERA
Quick Start Guide
English Version 1.0
.
LNE4322 Series
