Summary of Contents for ATM Tech SC41T-CODEC
- Page 1 User Manual SC41T-CODEC 4K Scaler with Soft Codec All Rights Reserved Version: SC41T-CODEC_2017V1.0...
-
Page 2: Fcc Statement
4K Scaler with Soft Codec Preface Read this user manual carefully before using the product. Pictures shown in this manual is for reference only. Different models and specifications are subject to real product. This manual is only for operation instruction only. The functions described in this version are updated till August 7, 2017. -
Page 3: Safety Precautions
4K Scaler with Soft Codec SAFETY PRECAUTIONS To insure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for possible future shipment. -
Page 4: Table Of Contents
4K Scaler with Soft Codec Contents 1. Introduction ............................1 1.1 Introduction to SC41T-CODEC ....................1 1.2 Feature ............................. 1 1.3 Package List ..........................2 2. Specification ............................3 2.1 Transmitter ..........................3 2.2 Receiver ........................... 4 3. Panel Description ..........................5 3.1 Transmitter .......................... -
Page 5: Introduction
1. Introduction 1.1 Introduction to SC41T-CODEC This SC41T-CODEC is a conferencing system codec kit supporting resolutions up to 4K@30Hz 4:4:4 and HDCP 2.2. It includes Transmitter and Receiver, providing AV switching, audio de-embedded, and USB extension, plus system control. All video, audio, control, USB and Ethernet signals can be transmitted over a single CATx cable up to 100m. -
Page 6: Package List
4K Scaler with Soft Codec 1.3 Package List 1 x SC41T-CODEC-T Transmitter 2 x Mounting Ears with 4 Screws Transmitter 4 x Plastic Cushions 1 x Power Adapter (24VDC,2.71A) 1 x RS232 Cable (3-pin phoenix connector to DB9) ... -
Page 7: Specification
4K Scaler with Soft Codec 2. Specification 2.1 Transmitter Video (2) HDMI; (1) DP; (1) VGA Video Input (2) Female HDMI; (1) DisplayPort; (1) Female VGA Video Input Connector (15-pin) (1) HDMI; (1) HDBaseT Video Output Video Output Connector (1) Female HDMI; (1) RJ45 Supports 3840x2160@30Hz, 1920x1080, 1280x720 Output Resolution Standards... -
Page 8: Receiver
4K Scaler with Soft Codec 2.2 Receiver Video Video Input (1) HDBT; (1) HDMI Video Input Connector (1) RJ45; (1) Female HDMI Video Output (1) HDMI Video Output Connector (1) Female HDMI Supports 3840x2160@30Hz, 1920x1080, 1280x720 Output Resolution Standards Compliant with HDMI 1.4 & HDCP2.2 Audio Audio Output (1) Stereo balanced L/R audio... -
Page 9: Panel Description
4K Scaler with Soft Codec 3. Panel Description 3.1 Transmitter 3.1.1 Front Panel RELAY 1 1-HDMI 2-HDMI 3-DP 4-VGA RX HDMI SOURCE RETURN MENU VOL - DISPLAY VOL + AUTO/3s ENTER MUTE/3s RELAY 2 ① POWER LED: The LED illuminates red when power is applied, or orange when the auto-switching mode is chosen. -
Page 10: Rear Panel
4K Scaler with Soft Codec 3.1.2 Rear Panel CONTROL PC 1 PC 2 DEVICE 1 DEVICE 2 RS232 TCP/IP FIRMWARE HDBT 1-HDMI 2-HDMI 3-DP 4-VGA AUDIO HDMI INPUT OUTPUT DC 24V ① INPUT: VIDEO: 2 HDMI inputs, 1 DP input and 1 VGA input. ... -
Page 11: Receiver
4K Scaler with Soft Codec 3.2 Receiver 3.2.1 Front Panel FIRMWARE HDBT HDMI 1 2 3 ① POWER LED: The LED illuminates red when power is applied. ② HDBT LED: The LED illuminates green when HDBT input signal present. ③ HDMI LED: The LED illuminates green when HDMI input signal present. ④... -
Page 12: System Connection
4K Scaler with Soft Codec 4. System Connection 4.1 Usage Precaution Verify all components and accessories included before installation. System should be installed in a clean environment with proper temperature and humidity. All of the power switches, plugs, sockets and power cords should be insulated and ... -
Page 13: Button Control
4K Scaler with Soft Codec 5. Button Control Front panel buttons can be used for signal switching, OSD, volume adjusting. 5.1 Manual Switching Press the SOURCE/AUTO button to select one input source for Transmitter, press again to select next source, switching sequentially between 1-HDMI, 2-HDMI, 3-DP and 4-VGA. -
Page 14: Auto Switching
4K Scaler with Soft Codec 5.2 Auto Switching Long-press SOURCE/AUTO button for 3 seconds or more to enable auto-switching mode, and the auto-switching mode abides by the following principles: New input Once detecting a new input signal, the Transmitter would switch to this new signal automatically. -
Page 15: Rs232 Control
4K Scaler with Soft Codec 6. RS232 Control As RS232 commands can be transmitted to Receiver from the Transmitter, so it is able to control the Transmitter or the third-party device (such as projector) on Receiver from local. The baud rate support 2400, 4800, 9600(default), 19200, 38400, 57600 or 115200. 6.1 RS232 Connection There are two RS232 control modes. -
Page 16: Rs232 Control Software
4K Scaler with Soft Codec 6.2 RS232 Control Software Installation/uninstallation Installation Copy the control software file to the computer connected with the Transmitter. Uninstallation Delete all the control software files in corresponding file path. Basic Settings First to connect the Transmitter with all input devices and output devices needed, then to connect it with a PC which is installed with RS232 control software. -
Page 17: Rs232 Command
4K Scaler with Soft Codec Please set the parameters of COM number, bound rate, data bit, stop bit and the parity bit correctly, and then you are able to send command in Command Sending Area. 6.3 RS232 Command Communication protocol: RS232 Communication Protocol Baud rate: 9600 Data bit: 8 Stop bit: 1... -
Page 18: Output Resolution
4K Scaler with Soft Codec Command Function Feedback AUMT V1 Mute VGA auxiliary input audio. Audio Mute VGA: Enable AUMT V0 Unmute VGA auxiliary input audio. Audio Mute VGA: Disable Audio Mute Source: Get the Source mute status. Enable ?GET AUMT Get the VGA auxiliary audio mute status. -
Page 19: Auto Power-Off Setup
4K Scaler with Soft Codec Command Function Feedback 1920x1080. 1920x1080 Set the output resolution for Receiver to RX Device Resolution: RRES 03 1280x720. 1280x720 Get the output resolution for Tx Device Resolution: Transmitter. 1920x1080 ?GET RES Tx Device Resolution: Get the output resolution for Receiver. 1920x1080 6.3.4 Auto Power-off Setup Command... -
Page 20: Cec Command
4K Scaler with Soft Codec Command Function Feedback Manual Switch Mode no Manual Switch Mode: Set the power-off TIME M1 input to shutdown time: 1 time to 1 minute. minutes Manual Switch Mode no Manual Switch Mode: Set the power-off TIME M2 input to shutdown time: 2 time to 2 minute. -
Page 21: Relay Control
4K Scaler with Soft Codec 6.3.6 Relay Control Command Function Feedback RLY1 ON Turn on the Relay 1. Relay 1 on RLY1 OFF Turn off the Relay 1. Relay 1 off RLY2 ON Turn on the Relay 2. Relay 2 on RLY2 OFF Turn off the Relay 2. -
Page 22: Osd Control
4K Scaler with Soft Codec 7. OSD Control The system provides a powerful OSD operation menu, including picture settings and system setup. Operation: Press the button MENU/ENTER to enter OSD menu. Press direction buttons (Left/Right/Up/ down) to select function on OSD menu. ... -
Page 23: Setup
4K Scaler with Soft Codec 7.2 Setup Including Menu Language, Restore Default, Software Update, Baudrate, TX Resolution, RX Resolution and SW Version. Menu Language: Supports 7 languages, including English (default), Chinese etc. Restore Default: Restores to original system state. ... -
Page 24: Gui Control
4K Scaler with Soft Codec 8. GUI Control In addition to control the system via front panel button and RS232 control software. The system can be controlled via web-based GUI. It allows users to interact with the system through graphical icons and visual indicators. Type 192.168.0.178 in your browser, it will enter the log-in interface shown as below: This system divides into administrator and user mode. -
Page 25: Control Menu
4K Scaler with Soft Codec 8.1 Control Menu Type the default user name and password, and then click Login to enter the control menu shown as below: Sources: Click the corresponding button (1-HDMI, 2-HDMI, 3-DP, 4-VGA and RX HDMI) to select video input source. -
Page 26: Configuration Menu
4K Scaler with Soft Codec 8.2 Configuration Menu ① Setting Click on control menu to enter configuration menu shown as below: Output Resolution: Select the output resolution for Transmitter or Receiver. Update: EDID: Insert the USB flash disk with EDID file to the FIRMWARE port of Transmitter, and then click EDID button to start update procedure. - Page 27 4K Scaler with Soft Codec ② Network Click Network to enter the below menu to select the dynamic or static mode. Under static mode, then IP address, subnet mask and gateway can be reset. ③ Source Click Source Label to enter the below menu to rename the input selection buttons.
-
Page 28: Rs232 Control Menu
4K Scaler with Soft Codec 8.3 RS232 Control Menu ① Click RS232 Control on the top of interface to enter the below menu to send commands to control far-end third-party device. Status: Local: Refers to the RS232 port of the Transmitter. ... - Page 29 4K Scaler with Soft Codec ② Click RX DISPLAY to enter the below menu to set the ON/OFF button function to turn on/ off the display device (such as projector). Status: ON or OFF can be chosen. Baud Rate: Supports 2400、4800、9600、19200、38400、57600、115200. ...
-
Page 30: Password Menu
4K Scaler with Soft Codec 8.4 Password Menu Click Password on the top of interface to enter the below menu to reset the username and password. 8.5 GUI Update Web-based GUI for the Scaler Switcher supports online update in http://192.168.0.178:100. Type the username and password (the same as the GUI log-in settings, modified password will be available only after rebooting) to log in the configuration interface. -
Page 31: Panel Drawing
4K Scaler with Soft Codec 9. Panel Drawing CONTROL PC 1 PC 2 DEVICE 1 DEVICE 2 RS232 TCP/IP FIRMWARE HDBT 1-HDMI 2-HDMI 3-DP 4-VGA AUDIO HDMI INPUT OUTPUT DC 24V 4K Scaler w/ Soft Codec 220.0 mm RELAY 1 1-HDMI 2-HDMI 3-DP 4-VGA... -
Page 32: Troubleshooting & Maintenance
4K Scaler with Soft Codec 10. Troubleshooting & Maintenance Problems Potential Causes Solutions Bad quality of the connecting Try another high quality cable cable. Output image with snowflake Make sure the Fail or loose connection connection is good Check with oscilloscope No signal at the input / output or multimeter if there is any signal at the input/... -
Page 33: Customer Service
4K Scaler with Soft Codec 11. Customer Service The return of a product to our Customer Service implies the full agreement of the terms and conditions hereinafter. There terms and conditions may be changed without prior notice. ① Warranty The limited warranty period of the product is fixed 3 (three) years. The warranty period runs from the date purchase indicated on the invoice.
