Rokinon 14mm F2.8 ED AS IF UMC Lens Instruction Manual

14mm F2.8 ED AS IF UMC Lens
Instruction Manual
Thank you for purchasing the 14mm F2.8 ED AS IF UMC lens.
We believe that you will have a special photographic experience with the 14mm F2.8
ED AS IF UMC lens.
Advantages of the 14mm F2.8 ED AS IF UMC lens
1. It compensates for aberrations by using a complex aspherical and glass aspherical
lens and, at the fully opened position, produces high resolution and high contrast at
the center of the lens as well as around the periphery.
2. Controls chromatic aberration optimally by using premium optical glass with high
refraction and extra-low dispersion.
3. Allows precision focus control by providing a soft and wide focus operation area.
4. Ultra multi coating design for optimum suppression of ghost images and vivid color
image reproduction.
5. Maintains an unchanged size with its inner focus design.
This product is designed with its own mount so you can easily take photographs by
mounting the lens directly onto the camera, without installing an additional adaptor .
Read this manual carefully to familiarize yourself with your lens for correct use.
※ Please read the Safety Precautions at the back of this instruction manual prior to use.
Please read this instruction manual prior to use.
Sony (Minolta) Mount
The diaphragm of the 14mm F2.8 ED AS IF UMC Sony (Minolta) mount is not
compatible with the camera. If the brightness is set to F8 or above, you may not be
able to set the correct focus due to a difficulty in viewing the subject through the
camera viewfinder. Turn the aperture adjustment ring so it is fully open when
attaching the lens to the camera, and then set the depth of field and brightness you
want prior to shooting.
1) Set the camera mode dial to M.
2) Set the focus adjustment lever of the camera to MF.
3) Adjust the shutter speed to achieve the appropriate exposure for the
brightness.
(The procedures above are for the α350. The settings for the camera or the menu may vary based
on the model or due to a functional upgrade. Refer to the camera instruction manual or contact the
camera manufacturer for detailed information.)
2) Hold down the AF button and turn the dial until it is set to MF. (Focusing)
AF + control dial ▶ MF setting (manual focusing)
3) Adjust the shutter speed to achieve the appropriate exposure for the brightness
by turning the dial.
(The procedures above are for the Olympus E-3. The settings for the camera or the menu may vary
based on the camera model or due to a functional upgrade. Refer to the camera manual or contact
the camera manufacturer for detailed information.)
1. Component Names
Figure
(Nikon) (Canon)
① Mount ④ Distance scale ⑦ CPU (electronic contacts)
② Aperture adjustment ring ⑤ Focusing ring
③ Indicator mark ⑥ Hood
2. Attaching and Detaching
The 14mm F2.8 ED AS IF UMC lens mount is uniquely designed for Canon, Nikon
(Fujifilm) F, Pentax (Samsung GX) K, Sony α (Minolta), Canon M, Sony E, Fujifilm X,
Samsung NX, Four Thirds, and Micro Four Thirds cameras.
Attaching
Hold the lens hood gently and align the camera mount attachment point with the
attachment reference point or line on the lens. Push the lens into the camera and
gently rotate the lens in the attachment direction until it makes a clicking sound.
Konica Minolta (Minolta), DYNA Series Cameras
If this lens is used on some Konica Minolta (Minolta) or DYNA series cameras, the
release lock function (misuse prevention function) of the camera must be disabled. It
is required to disable the release lock function only on the first use, as below.
Disabling the release lock function
① Set the main switch of the camera to OFF.
② Detach the lens from the camera body and set the main switch of the camera to
ON by pressing the following two buttons.
9xi ... function button + AE lock button 303si ... AV button + self mode button
7xi ... function button + AE lock button 303si SUPER ... drive button + spot button
5xi ... function button + spot button 101si ... self-timer button + flash button
3xi ... Modification is required at a service 360si ... self-timer continuous shooting
center. button + screen select button
807si ... AEL button + shooting scene select α-Sweet ... self-timer continuous shooting
button button + spot button
707si ... card button + spot button α-Sweet S ... (set the function dial to multi
507si ... lens exchange button + ISO lock light exposure)
button P button + self-timer button
DYNAX3L ... shooting scene select button DYNAX30 ... self-timer button + turn the left
+ button dial on the main body away
from OFF.
α-Sweet II, II L ... Set the camera to custom function 14 and change selection number
from 1 to 2 (N.A).
α-7, -9, -Ti ... Set the camera to custom function 16 and change the selection number
from 1 to 2 (N.A).
α-Sweet digital ... Execute the following operation.
MENU ⇒ *2 ⇒ Release lock without the lens ⇒ To the right ⇒ N.A. ⇒ Execute ● ⇒ MENU
α-7 Digital - Execute the following operation.
MENU ⇒ *3 ⇒ Release lock without the lens ⇒ To the right ⇒ N.A. ⇒ Execute ● ⇒ MENU
※ If the release lock is disengaged in the above way, the state of disengagement is
maintained even though the main switch is turned off. If you want to enable the
release lock function, perform the above procedure again.
(The settings for the camera or the menu may vary based on the camera model or due to a
functional upgrade. Refer to the camera instruction manual or contact the camera manufacturer for
detailed information.)
Micro Four Thirds Mount
1) Set the camera mode dial to M.
2) Adjust the shutter speed by turning the dial to achieve the appropriate exposure
for the brightness.
※ For some Olympus (MFT) and Panasonic (MFT) cameras, if you set the camera
mode dial to A and set the brightness by turning the aperture adjustment ring on
the lens, the camera automatically changes the shutter speed. Therefore you don't
need to adjust the shutter speed as well, which is required in M mode.
(The procedures above are for the E-P2. The settings for the camera or the menu may vary based
on the camera model or due to a functional upgrade. Refer to the camera manual or contact the
camera manufacturer for detailed information.)
Detaching
Hold the lens hood gently and press the lens release button on the camera. Turn the
lens in the opposite direction of the attaching direction to detach the lens.
3. Focus Adjustment
You can adjust the focus by turning the focusing ring when using the 14mm F2.8 ED
AS IF UMC lens, as it is a Manual Focus (MF) adjustment lens.
Nikon (Fujifilm) F / Pentax (Samsung GX) K Mount
① To change the focus from a subject that is far away to a subject that is close,
turn the focusing ring to the left (∞ to 0.28 m) and focus on the clearest subject
by using the indication signal on the camera, or by checking visually.
② To change the focus from a subject that is close to a subject that is far away,
turn the focusing ring to the right (0.28 m to ∞) and focus on the clearest
subject by using the indication signal on the camera, or by checking visually.
Sony , E / Canon, Canon M / FT, MFT / Fujifilm X / Samsung NX Mount
① To change the focus from a subject that is far away to a subject that is close,
turn the focusing ring to the right (∞ to 0.28 m) and focus on the clearest
subject by using the indication signal on the camera, or by checking visually.
② To change the focus from a subject that is close to a subject that is far away,
turn the focusing ring to the left (0.28 m to ∞) and focus on the clearest subject
by using the indication signal on the camera, or by checking visually.
4. Brightness Control
You can set the depth of field and brightness by turning the aperture adjustment ring
when using the 14mm F2.8 ED AS IF UMC lens.
The F numbers can be set from 2.8 to 22.
5. About Photography
The 14mm F2.8 ED AS IF UMC lens is a wide-angle lens and captures a vivid wide
angle of view by minimizing image distortion. You can capture extensive panoramas,
which is very useful for landscape shooting.
Mirrorless Cameras (Canon M, Samsung NX, Sony E, Fujifilm X)
The diaphragms of the 14mm F2.8 ED AS IF UMC Canon M, Samsung NX, Sony E
and Fujifilm X mounts are not compatible with the cameras. If the brightness is set to
F8 or above, you may not be able to set the correct focus due to a difficulty in viewing
the subject through the camera viewfinder. Turn the aperture adjustment ring so it is
fully open when attaching the lens to the camera, and then set the depth of field and
brightness you want prior to shooting.
Canon M Mount
1) Set the exposure to manual exposure (M) and change the focus mode to MF.
(The procedures above are for the Canon M. The settings for the camera or the menu may vary
based on the camera model or due to a functional upgrade. Refer to the camera instruction manual
or contact the camera manufacturer for detailed information.)
7. Specifications
14mm
F2.8 ~ 22
24 X 36mm
35mm (1:1x) 115.7 ( diagonal)
(
APS-C (1:1.5x) 93.9 diagonal)
(
APS-C (1:1.6x) 89.9 diagonal)
(
Four-Thirds (1:2x) 76.2 diagonal)
to 0.28m(0.9ft)
None
87mm
14 elements in 10 groups (1 glass ASP & 1 hybrid ASP)
115.7 115.7 115.7 115.7
89.9 93.9 93.9 93.9 93.9 93.9 93.9 93.9 -
76.2 76.2
-
96.1 93.6 94.6 956 122 122.4 114.6 122.1 101.1 120.9
550g 530g 530g 530g 570g 575g 570g 570g 560g 570g
A / S/ M / P mode (NIKON AE)
6. Camera Settings
Some cameras require special settings when using this lens.
Please refer to the following and set the camera when necessary.
Canon Mount
The diaphragm of the 14mm F2.8 ED AS IF UMC Canon mount is not compatible with
the camera.
If the brightness is set to F8 or above, you may not be able to set the correct focus
due to a difficulty in viewing the subject through the camera viewfinder. Turn the
aperture adjustment ring so it is fully open when attaching the lens to the camera, and
then set the depth of field and brightness you want prior to shooting.
1) Set the camera mode dial to M.
2) Adjust the shutter speed to achieve the appropriate exposure for the
brightness.
※ For some Canon cameras, if you set the camera mode dial to Av and set the
brightness by turning the aperture adjustment ring on the lens, the camera
automatically changes the shutter speed. Therefore you don't need to adjust the
shutter speed as well, which is required in M mode.
(The procedures above are for the 40D. The settings for the camera or the menu may vary based
on the model or due to a functional upgrade. Refer to the camera instruction manual or contact the
camera manufacturer for detailed information.)
Fujifilm X Mount
1) Set the focus mode to M.
2) Press the MENU/OK button, and select ON at 'Shoot without lens' in the
shooting menu.
(The procedures above are for the X-Pro1. The settings for the camera or the menu may vary based
on the camera model or due to a functional upgrade. Refer to the camera instruction manual or
contact the camera manufacturer for detailed information.)
Samsung NX Mount
1) Set the camera mode dial to M.
2) Adjust the shutter speed by turning the dial to achieve the appropriate exposure
for the brightness.
※ For some Samsung NX cameras, if you set the camera mode dial to A and set the
brightness by turning the aperture adjustment ring on the lens, the camera
automatically changes the shutter speed. Therefore you don't need to adjust the
shutter speed as well, which is required in M mode.
(The procedures above are for the NX200. The settings for the camera or the menu may vary based
on the camera model or due to a functional upgrade. Therefore refer to the camera manual or
contact the camera manufacturer for detailed information.)
8. Troubleshooting
Issue Causes Corrective Action
The attachment reference point on the lens Align the attachment reference point on the
A lens cannot be attached to
is not aligned with the lens attachment lens with the lens attachment reference
the camera.
reference point on the camera. point on the camera.
Press the lens release button on the
Incorrect rotation direction for detaching the
camera, and gently turn the lens to the lens
A lens cannot be detached
lens.
attaching/detaching reference points, in the
from the camera. If you turn the lens while holding the
direction as marked on the camera, and
camera, it may cause damage to the lens.
then pull the lens forward.
Turn the focusing ring while checking the
indication or checking an object visually, set
Incorrect focusing
the focus until it becomes clear, and then
Blurry images
Insufficient shutter speed or camera shake. press the shutter.
Steady the camera and take a photograph
at a shutter speed of 1/125 secs.
The aperture adjustment ring on the lens is Turn the aperture adjustment ring to set it to
EE (blinking)
F
not set to the minimum aperture value. the minimum aperture value. (F22)
Automatic focusing does not
A manual focusing lens has trouble with
Use the focusing ring to adjust the focus.
work properly.
automatic focusing.
Adjust the aperture adjustment ring
Dark or too bright pictures Inappropriate exposure
accordingly.
The non-CPU lens may not be compatible,
See the camera manual.
depending on the camera.
The camera flash is not
functioning.
See the camera manual or flash manual.
This lens corresponds to the Nikon AI-P
This lens is not a "D-type" lens (which
lens.
relays distance information to the camera).
The camera finder indication
This lens does not have an electric contact
or the display does not signal, so there is no communication with No problem with shooting
display. the camera through electric signals.
Zooming failure This lens is a single lens.
This lens cannot be mounted
This lens is designed for its own mount. Purchase the designated lens mount.
on other cameras.
Our converter is designed for the T (M42
Use each company's own mount converter.
You want to attach our 2X or
screw) mount only. Therefore it cannot be
However, be aware that auto focusing is
1.4X converter lens. used with the 16 mm F2.0 ED AS UMC CS
unavailable.
lens.
Nikon (Fujifilm) Mount
Your Nikon mount has electronic contacts that allow it to communicate with Nikon AF
cameras. These contacts enable the A, S, and P modes of the camera. When a
subject is correctly in focus, the camera emits a beep or an indicator light comes on.
Pentax (Samsung GX) K Mount
The 14mm F2.8 ED AS IF UMC Pentax (Samsung GX) K Mount supports Av mode.
1) Align the A mode indicator to the distance scale indicator mark by pressing the
A button on the aperture adjustment ring of the lens.
2) Set the mode dial of the camera to Av.
3) Set the focus adjustment lever of the camera to MF.
4) Camera Settings
The user sets the menu. ► The aperture ring is used. ► Not allowed.
5) Adjust the brightness by turning the dial at the back of the camera.
(The procedures above are for the K20D. The settings for the camera or the menu may vary based
on the model or due to a functional upgrade. Refer to the camera instruction manual or contact the
camera manufacturer for detailed information.)
Sony E Mount
1) Set the camera mode dial to M.
2) Adjust the shutter speed by turning the dial to achieve the appropriate exposure
for the brightness.
※ For some Sony E cameras, if you set the camera mode dial to A and set the
brightness by turning the aperture adjustment ring on the lens, the camera
automatically changes the shutter speed. Therefore you don't need to adjust the
shutter speed as well, which is required in M mode.
(The procedures above are for the NEX-5. The settings for the camera or the menu may vary based
on the model or due to a functional upgrade. Refer to the camera manual or contact the camera
manufacturer for detailed information.)
Four Thirds, Micro Four Thirds
The diaphragms of the 14mm F2.8 ED AS IF UMC Four Thirds and Micro Four Thirds
mounts are not compatible with the cameras. If the brightness is set to F8 or above,
you may not be able to set the correct focus due to a difficulty in viewing the subject
through the camera viewfinder. Turn the aperture adjustment ring so it is fully open
when attaching the lens to the camera, and then set the depth of field and brightness
you want prior to shooting.
Four Thirds Mount
1) Hold down the MODE button and turn the dial until it is set to M. (shooting conditions)
MODE + control dial ▶ M mode setting (manual shooting)
9. Safety Precautions
The following precautions are divided into two types
The following pictograms are used in the below precautions:
according to the level of danger.
Requires caution. Inside the pictogram it shows contents of precautions.
WARNING CAUTION
(It shows outbreak of fire in the pictogram on the left.)
If this instruction is not Shows prohibition. Inside the pictogram it shows contents of prohibition.
If this instruction is not
(It shows prohibition of dismantling in the pictogram on the left.)
followed, it may cause death
followed, it may cause death
or severe injury to the user. or severe injury to the user. Shows instruction. Inside the pictogram it shows contents of instructions.
(It shows instruction of precaution in the pictogram on the left.)
WARNING CAUTION
Ensure that the camera
Don't look at the sun Attach the lens to the Don't put excessive pressure
operates properly by
through the lens. It may camera correctly and on the lens attached to the
camera; otherwise it may checking the lens beforehand or by
cause blindness. ensure the lens is held in place
test shooting for important events
properly; otherwise the lens may cause damage to the lens or
such as a
not be removable, or may to the camera mount. Be sure to
hold the lens when operating or wedding
become loose and cause an
accident. moving. ceremony
and an
overseas
trip.
Don't attempt to modify or
Don't leave the lens within Don't leave the lens in Don't look at the sun
reach of babies, as it may alter the lens. It may lead direct sunlight. It may
directly through a camera
cause injury to the baby if the to failure of the camera. Modified cause a fire, depending on with a lens attached. It may
or altered lenses may not be
lens falls or is dropped. lenses that concentrate cause damage to
repaired. light on a close object.
one's eyesight.
WARNING!
Do not wet this product or expose it to a moist environment. It may cause a
fire or electric shock.
CAUTION!
Do not use this product or store it close to devices that generate heat i.e.,
heaters, thermal regulators, stoves or stereo amplifiers.
Do not leave the lens in conditions where drastic temperature changes can
occur.
Do not touch the surface of the lens by hand, and avoid making contact with
sharp objects.
Avoid dropping the lens.
Do not soak the lens in water, and avoid water splashing onto the lens.
If there are foreign bodies on the lens, use a lens cleaning kit only.
