WELCOME

Thank you for choosing First Alert for your security needs!
For more than half a century, First Alert has made the home-safety and security products that make your job easier. Our products are built to the
highest standard which has earned us a leadership role in the home-safety and security product categories. We are committed to serving our
customers, from the professionals who install our products, to the families and businesses who count on them. First Alert has been helping families
and businesses stay safe for over 50 years. By having a First Alert Security System, you're taking the rst step in protecting your home or business
from damage or theft. We're watching, even when you're not.
This manual is written for the SmartBridge ™ NVR04–360H, NVR08–360H, and NVR16–360H. It was accurate at the time it was completed. However,
because of our ongoing effort to constantly improve our products, additional features and functions may have been added since that time and
on-screen displays may change. We encourage you to visit our website at www. rstalert.com to check for the latest manuals (English and Spanish),
rmware updates, downloads, other security camera products and announcements.
WHAT'S IN THE BOX?
Installation Software & Manual IR Bullet Camera 360° Camera
IR Remote Control Brackets Screws & Mounting Parts
You Will Need...
• Monitor or Television with
NVR Device
HDMI or VGA inputs
• VGA cable (If not using
included HDMI cable)
Power Cord for NVR USB Mouse Ethernet Cable
HDMI Cable Quick Start Guide SATA Cable

PRODUCT OVERVIEW

FRONT PANEL
1
RS-232
eSATA
8 10
POE
REAR PANEL
9
Item Function Description
USB Port
1 USB port for additional devices such as USB Mouse
2 Eject Button To be used when an Internal DVR burner is installed. See manual for more details.
Cycle through channels when in LIVE view
3 Outer Jog Shuttle Control
Jump 30 seconds forward / back in PLAYBACK mode
Cycle through channels when in LIVE view
4 Inner Jog Shuttle Control
Jump 30 seconds forward / back in PLAYBACK mode
Speed up / slow down in PLAYBACK mode
5 Control Buttons Jump 30 seconds forward / back in PLAYBACK mode
Play / pause in PLAYBACK mode
6 Status Indicator See Full Instructions Guide for Status Indicator Light descriptions
Power On / Off
7 Power on / off button
eSata
8 Connect to a eSata drive
2 3 4
VGA SW RS-485 KB ALARM IN ALARM OUT
T+T-R+R- GG D+D- 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 1 G 2 G 3 G 4 G
ON
VIDEO LINE
OUT IN
11
HDMI
AUDIO LAN
12 13 14 15 16 17
Item Function Description
9 Camera Network Interfaces
Network Interfaces provide Power-Over-Ethernet to cameras
10 VGA Output Connect to VGA monitor to display video
Item Description
Function
BNC Video In / Out
11 Video Connection
Audio In / Out
12 Audio connection
13 HDMI Video Output
Connect to HDMI monitor to display video
14 USB Port USB port for additional devices such as USB Flash drive up to 32GB
LAN Port
15 Connect Ethernet cable to PC or router
PTZ / Alarm Block
16 PTZ / Alarm Block
17 Ground Connection Ground Connection
18 Power Toggle Switch Power on / off switch
Power Supply
19 Connect power cord to device
5 6 7
18 19
