Summary of Contents for Sper scientific 800201
- Page 1 Thermal Imaging Camera 220 x 160 800201 Instruction Manual...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ..............3 FEATURES ................4 MATERIALS SUPPLIED ............ 4 FRONT PANEL DESCRIPTION ......... 5 LCD DISPLAY ..............6 SET UP ................7 MEASUREMENT PROCEDURES ........12 IMAGE DOWNLOADING ..........14 CARE AND MAINTENANCE ..........18 SPECIFICATIONS ............19 WARRANTY .............. -
Page 3: Introduction
INTRODUCTION This Sper Scientific Thermal Imaging Camera (model 800201) combines a high precision thermal image with a standard photo for maximum clarity. With the press of a button, the thermal image can be blended in increments of 25% on a beautiful 3.5” full color display. Five available... -
Page 4: Features
FEATURES • Separate IR and Visible light cameras • Attached flip-up lens cover for protection • User-defined crosshair pinpointing • Minimum and Maximum values • Adjustable emissivity • 0.5m focal length • Rechargeable Lithium ion battery MATERIALS SUPPLIED • Thermal Imaging Camera •... -
Page 5: Front Panel Description
FRONT PANEL DESCRIPTION POWER Button MENU Button SELECT Button ENTER Button RIGHT Arrow/ Visual Image Toggle DOWN Arrow LEFT Arrow UP Arrow/ MIN/MAX Toggle... -
Page 6: Lcd Display
LCD DISPLAY SETUP Current Temperature of Crosshair Minimum Temperature Location (Green Square) Maximum Temperature Location (Red Square) Current Maximum and Minimum Values Battery Level Indicator Emissivity Indicator Color Palette Indicator Crosshair Location Time... - Page 7 Before replacing the battery, turn the camera off. 1. Ensure the replacement battery is a direct replacement from Sper Scientific. This battery is custom made and substitutions can damage the camera. 2. Hold the camera firmly in your palm with the trigger facing up and away from your body.
- Page 8 6. Remove the battery body and gently pull the four-wire plug from the circuit board. 7. Plug the new battery into the pins of the exposed circuit board. Ensure the black wires align with the negative (-) pins and the red wires align with the positive (+) pins. 8.
- Page 9 12. Press SELECT in the first box to change the Year. 13. Use the ARROWs to change the Year. 14. Press ENTER to accept the Year. 15. Use the DOWN arrow to scroll to the Month. 16. Press SELECT to expand Month. 17.
- Page 10 SETTING THE EMISSIVITY 1. Turn the camera on. 2. Press MENU. 3. Press the DOWN arrow to highlight Emissivity. 4. Press the RIGHT arrow to expand Emissivity. 5. Press the DOWN arrow to highlight your choice. 6. Press ENTER to confirm your choice or SELECT to enter a custom value.
-
Page 11: Measurement Procedures
MEASUREMENT PROCEDURES Before using your Thermal Imaging Camera, there are some important things to be aware of. The following is true for ALL Thermal Imaging Cameras: • Thermal Imaging Cameras provide only the surface temperature. While the thermal image may appear as if it shows objects behind others, such as through a wall. - Page 12 TO BLEND VISUAL AND THERMAL IMAGES 1. Turn the Camera ON and Flip open the Lens cap. 2. Point the camera at the area of interest to be measured. 3. Note that the temperature of the square containing the crosshairs is the temperature displayed in the upper left-hand corner of the screen.
- Page 13 TO SAVE IMAGES 1. In normal Camera Mode, press the TRIGGER. 2. A box appears and asks if you want to save the image. 3. Press the TRIGGER again to save the image or SELECT to delete the image. 4. If you choose to delete the image, “no” will briefly highlight in the box before it disappears.
-
Page 14: Care And Maintenance
• Do not use abrasives, solvents or cleaning agents containing carbon, alcohol or benzenes on the meter. • Repairs or services not covered in this manual should be performed by qualified personnel only. Please contact Sper Scientific to speak with a technician. -
Page 15: Specifications
SPECIFICATIONS Infrared Image 220 x 160 Resolution Visible Image 35,200 Resolution Thermal Sensitivity ±0.07ºC (1.0ºF) Temperature Accuracy ±2.5°C (4ºF) or ±2.5%, whichever is greater Emissivity Range 0.1 – 0.99 Available Color Palettes Spectral rainbow, iron oxide, cool color, black and white, white and black Capture Frequency Focal Length... -
Page 16: Warranty
WARRANTY Sper Scientific warrants this product against defects in materials and workmanship for a period of two (2) year from the date of purchase, and agrees to repair or replace any defective unit without charge. If your model has since been discontinued, an equivalent Sper Scientific product will be substituted if available.
