STEP 1
• Raise the top cover and open the base plate.
• Insert the end of the label roll inside the
dispenser. (labels should be facing up)
• Insert the roll into the axis of the label roll
holder and close the cover.
NOTE: Remove 6-7 labels to make loading easier.
STEP 2
• Turn the dispenser upside down.
• Pull the labels through the first slot of the
base plate, near the applicator roller. (see
picture at far right for more details)
• Pull about 9 cm of label roll ribbon through
the slot.
STEP 3
• Insert the label roll ribbon through the second
slot of the base plate.
• Close the base plate – it will "click".
STEP 4
• Begin to make the labels advance.
• After five or six dispenses, the labels should
dispense smoothly.
• Enjoy your new label dispenser!
SEE REVERSE SIDE FOR REPLACING INK ROLL & FOR SETTING PRINTHEAD >>
INSTRUCTION
base
>
plate
MANUAL
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Duraline Systems Labelex
- Page 1 INSTRUCTION MANUAL LOADING THE LABELS: STEP 1 • Raise the top cover and open the base plate. • Insert the end of the label roll inside the dispenser. (labels should be facing up) • Insert the roll into the axis of the label roll holder and close the cover. base > plate NOTE: Remove 6-7 labels to make loading easier. STEP 2 • Turn the dispenser upside down. • Pull the labels through the first slot of the base plate, near the applicator roller. (see picture at far right for more details) • Pull about 9 cm of label roll ribbon through the slot. STEP 3 • Insert the label roll ribbon through the second slot of the base plate.
- Page 2 Setting Printing Information To change the printing data (ie: sterilizer, load number, date): • Slide the dialing knobs out and turn backward or forward. • The bottom or top line can both be set to ‘not print’. Turn the knobs to a blank space – no data will print there. • Once printing data is set to your preference, slide knobs back in. Adjust Print Location on Label • Using a screwdriver, loosen the screw on the guide plate on both sides. • Move the printhead forwards or backwards to set print location higher or lower on the label. • Tighten screws on both sides. • Test print and adjust as needed. CONTACT YOUR LABELEX DEALER FOR FURTHER ASSISTANCE! Limited Lifetime Warranty Labelex honours a lifetime warranty under normal use conditions. If you find a material or manufacturing defect with the dispenser, please notify the company where you purchased the dispenser system. Labelex will repair or replace the dispenser entirely free of charge provided the damage has not been caused by misuse, negligence, accident, or abuse.
