BIO RAD gs-800 User Manual

BIO RAD gs-800 User Manual

Calibrated imaging densitometer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Model GS-800
™
Calibrated Imaging
Densitometer
User's Guide
For Catalog Numbers
170-7980 GS-800 Densitometer, PC
170-7981 GS-800 Densitometer, Mac
For Technical Service
Call Your Local Bio-Rad Office or
In the U.S. Call 1-800-4BIORAD
(1-800-424-6723)
WWW.BIO-RAD.COM
4000188 Rev. A
Copyright 2002 Bio-Rad Laboratories Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the gs-800 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BIO RAD gs-800

Summary of Contents for BIO RAD gs-800

  • Page 1 Model GS-800 ™ Calibrated Imaging Densitometer User's Guide For Catalog Numbers 170-7980 GS-800 Densitometer, PC 170-7981 GS-800 Densitometer, Mac For Technical Service Call Your Local Bio-Rad Office or In the U.S. Call 1-800-4BIORAD (1-800-424-6723) WWW.BIO-RAD.COM 4000188 Rev. A Copyright 2002 Bio-Rad Laboratories Inc.
  • Page 3 Bio-Rad shall not be liable for any incidental, special or consequential loss, damage, or expense directly or indirectly arising from the use of the Model GS-800 Calibrated Imaging Densitometer. Bio-Rad makes no warranty whatsoever in regard to products or parts furnished by third parties, such being subject to the warranty of their respective manufacturers.

  • Page 5: Table Of Contents

    Table of Contents Section 1 General Information ....................... 6 1.1 Introduction ..........................6 1.2 Installation Qualification and Operational Qualification( IQ/OQ )..………………..6 1.3 Safety…………………………........…………………………………...…..7 1.4 Regulatory Compliance ......................7 Section 2 Setting Up......................... 8 2.1 Checking the Contents ......................8 2.2 Unpacking the Contents .......................

  • Page 7: Section 1 General Information

    1.2 Installation Qualification and Operational Qualification ( IQ/OQ ) The calibration of the Model GS-800 Calibrated Imaging Densitometer can be validated by following the GS-800 Calibrated Densitometer Installation Qualification and Operational Qualification protocols. These protocols are available as an accessory to the GS-800 Calibrated Imaging Densitometer ( Catalog number 170-7956 ).

  • Page 8: Safety

    The Model GS-800 Calibrated Imaging Densitometer system uses high voltage and high current and should be operated with care at all times. To avoid shock, set up the GS-800 Densitometer in a dry area. Immediately wipe up any spilled solutions.

  • Page 9: Section 2 Setting Up

    1. Carefully lift the Model GS-800 Calibrated Imaging Densitometer out of the shipping carton and place it on a stable, dry, flat surface. The chassis of the Model GS-800 Calibrated Imaging Densitometer attempts to conform to any uneven surface. This may result in a poor-quality scan.

  • Page 10: Unlocking The Densitometer And The Transparency Module

    4. The Model GS-800 Calibrated Imaging Densitometer can operate with 100V AC to 264V AC. Check the power cord to insure that it is suitable for your area. Caution: The power cord plug provided has a third grounding pin. This plug fits in a grounding-type outlet only.

  • Page 11: Locking The Densitometer And The Transparency Module

    2.5 Taking a Closer Look Now that you have the Model GS-800 Calibrated Imaging Densitometer out of the box, take a closer look to familiarize yourself with the parts. Figures 2.2 and 2.3 illustrate the locations of the different parts of your Model GS-800 Calibrated Imaging Densitometer.
  • Page 12 50-pin SCSI 25-pin Power Cord SCSI Termination SCSI ID SCSI Connector connector Switch Switch connector Fig. 2.3 The back of the Model GS-800 Calibrated Imaging Densitometer.

  • Page 13: Section 3 Installation

    Section 3 Installation 3.1 About SCSI Devices The Model GS-800 Calibrated Imaging Densitometer is a Small Computer System Interface (SCSI) device. It communicates with your computer by using the SCSI-2 standard. The SCSI communication standard allows you to connect more than one peripheral device to the same port of your computer in chain fashion.

  • Page 14: Checking The Terminators

    There should be two terminators in a SCSI chain. It is best to place the terminators at each end of the SCSI chain. The GS-800 Calibrated Densitometer has a built-in active terminator switch for you to turn on and off. Number 1 represents active terminator and number 2 represents terminator power.

  • Page 15: Installation For The Macintosh Or Pc Computer

    Densitometer to your computer, and lastly test the connection. SCSI Adapter Card The Model GS-800 Calibrated Imaging Densitometer requires a SCSI adapter card to work with your computer. The Densitometer driver software supplied with the Densitometer supports most Adaptec adapter cards.

  • Page 16: Testing The Densitometer

    Connect the Densitometer to the Computer With settings on the Densitometer and card correctly set and the interface card properly installed in your computer, you can now connect the Densitometer and the computer, as follows: 1. Ensure that the Densitometer’s SCSI ID is properly set. Determine which SCSI ID numbers are already assigned and which numbers are free.

  • Page 17: Section 4 Operation

    Transparency Module The Transparency Module (Figure 2.2) is secured to the Model GS-800 Calibrated Imaging Densitometer by two elongated hinges at the rear of the Densitometer. This Transparency Module should be lowered onto the Densitometer base for reflectance and transmittance scanning.
  • Page 18 Indicator Lights The indicator lights (Figure 2.2) are located on the front left side of the Model GS-800 Calibrated Imaging Densitometer cabinet. This panel consists of two lights that indicate the status of the unit.

  • Page 19: Start-Up

    For optimum performance, allow the Densitometer to warm up for five minutes after power-up. The Model GS-800 Calibrated Imaging Densitometer is now ready for use. 4.3 Reflective Scanning To scan a reflective sample: 1. Raise the Transparency Module.
  • Page 20 For more information about scanning operations and options, refer to the Quantity One software manual. Note: The OD values for the Transparency step tablet are included on a separate sheet with this Manual and are also on the Decal pasted on the right side of the instrument. If for any reason these values are lost contact Bio-Rad Technical Service.

  • Page 21: Section 5 Maintenance

    Model GS- 800 Imaging Densitometer. Caution: Do not use ammonia-based cleaning products to clean the Model GS-800 Imaging Densitometer. Do not disassemble the Model GS-800 Calibrated Imaging Densitometer or lubricate any parts.

  • Page 22: Section 6 Troubleshooting

    Section 6 Troubleshooting Though the Model GS-800 Calibrated Imaging Densitometer is very reliable, problems can occur during operation. This section lists some problems and the recommended corrective actions. Most problems are easily remedied. 6.1 Troubleshooting Electronic Failure Call Bio-Rad Technical Service.
  • Page 23 2. Make sure the calibration windows are clean and free of dust, dirt, fluid, and other contaminants that can obstruct the path of light. 3. Check for correct offset value. For the GS-800 Calibrated Imaging Densitometer the correct offset value is 00 for transmissive scanning and 0.05 for reflectance scanning.

  • Page 24: Technical Service

    6.2 Technical Service Bio-Rad provides complete technical support on all features of the GS-800 Calibrated Imaging Densitometer system, including all hardware, software, or spare parts issues. If you have any problems or any questions on the use of the features, contact your local Bio-...

  • Page 25: Section 7 Technical Specifications

    5°C to 40° C (40° F to 104° F) Relative Humidity 20% to 85% Surrounding space 15 cm on each side GS-800 and Quantity One are trademarks of Bio-Rad Laboratories. Macintosh is a trademark of Apple Computer, Inc. Windows is a trademark of Microsoft Corporation.
  • Page 27 Bio-Rad Laboratories, Inc. Life Science Web site www.bio-rad.com USA (800) 4BIORAD Australia 02 9914 2800 Austria (01)-877 89 01 Belgium 09-385 55 11 Brazil 55 21 507 6191 Canada (905) 712-2771 China (86-21) 63052255 Denmark 45 44 52-1000 Finland 358 (0)9 804 2200 France 01 47 95 69 65 Germany 089 318 84-177 Group Hong Kong 852-2789-3300 India (91-124) 6398112/113/114, 6450092/93 Israel 03 951 4127 Italy 39 02 216091 Japan 03-5811-6270 Korea 82-2-3473-4460 Latin America 305-894-5950 Mexico 52 5 534 2552 to 54 The Netherlands 0318-540666 New Zealand 64-9-4152280...
