Summary of Contents for Southern CM487200TX
- Page 1 CM487200TX Javu Wine Storage Console For assistance with assembly contact: Assembly Instructions Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com www.seifurniturestore.com Page 1...
-
Page 2: Parts List
Javu Wine Storage Console Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or a blanket. Check that you have all parts indicated. Call customer service if any hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures. - Page 3 Quantity Quantity Quantity of 2 of 2 of 2 Left Metal Tube Right Metal Tube Short Metal Tube Quantity Quantity Quantity of 6 of 1 of 2 Large Wood Shelf Panel Wood Shelf Panel Cup Holder Quantity Quantity Quantity of 2 of 3 of 5 Large Wicker Basket...
- Page 4 Quantity Quantity Quantity of 2 of 8 of 46 Short Bolt ：Ø1/4”×1/2” L Long Bolt ：Ø1/4”×1-1/4” L Bolt ：Ø1/4”×1” L Quantity Quantity Quantity of 1 of 14 of 2 Long Wood Screw ：4.0×1” L Allen Wrench Wood Screw: 4.0×1/2” L Quantity Quantity Quantity...
- Page 5 Javu Wine Storage Console Assembly Instructions Attach Back Frame (D) onto bothSide Frame (A & B). Insert 2pcs Long Bolt (1) through holes on Back Frame (D) to attach Back Frame (D) to both Side Frame (A & B), tighten by using Allen Wrench (4).
- Page 6 Slowly push 2pcs Iron Frame(H) to Back Frame (D) & Long Metal Tube(G) by hands Insert 4pcs Short Bolt (3) through holes on Iron Frame(H) to attach Iron Frame(H) to Back Frame (D) & Long Metal Tube(G) by Allen Wrench (4). Figure 3 Slowly push the Large Wood Shelf Panel (O) onto the Back Frame (D) &...
- Page 7 Push Cup Holders(N) onto Top Frame(E) by hands Insert 12pcs Short Bolt (3) through holes on 6pcs Cup Holders(N) to attach Cup Holders(N) to Top Frame(E) by Allen Wrench (4). Figure 5 Slowly push Top Frame(E) to bothSide Frame (A & B). Insert 4pcs Short Bolt (3) through holes on Top Frame(E) to attach Top Frame(E) to bothSide Frame (A &...
- Page 8 Slowly push 2pcs Short Metal Tube(M) to Long Metal Tube (G) & Top Frame(E) by hands Insert 4pcs Short Bolt (3) through holes on Short Metal Tube(M) to attach Short Metal Tube(M) to Long Metal Tube (G) & Top Frame(E) by Allen Wrench (4).
- Page 9 Slowly push Wine Frame(C) onto both Frame (E & F) by hands Insert 2pc Short Bolt (3) through holes on Wine Frame(C) to attach Wine Frame(C) to Top Frame (E) by Allen Wrench (4) Insert 2pc Bolt (2) through holes on Bottom Frame(F) to attach Wine Frame(C) to Bottom Frame (F), by Allen Wrench (4).
- Page 10 Slowly push Wine Frame(C) onto both Frame (E & F) by hands Insert 2pc Short Bolt (3) through holes on Wine Frame(C) to attach Wine Frame(C) to Top Frame (E) by Allen Wrench (4) Insert 2pc Bolt (2) through holes on Bottom Frame(F) to attach Wine Frame(C) to Bottom Frame (F) by Allen Wrench (4)
- Page 11 Slowly push 2pcs Metal Frame(J) to both Side Frame (B & C) and Wine Frame( C) by hands Insert 4pcs Bolt (1) through holes on Metal Frame(J) to attach Metal Frame(J) to both Side Frame (B & C) by Allen Wrench (4) Figure 11 Slowly push 2pcs Wood Shelf Panel (P) onto the Metal Frames (J) by...
- Page 12 Insert 6pcs Wood Screw (5) through holes on Back Frame (D) & Long Metal Tube(G) to attach Large Wood Shelf Panel (O) onto Back Frame (D) & Long Metal Tube(G) by Tool Required - No.2 Phillips Screwdriver (Not Included). Figure 13 Insert 4pcs Short Bolt (3) through holes on Right Metal Tube (L) to attach 2pcs Right Metal Tube (L) to...
- Page 13 Please slide one side of Basket Bottom Panel (S) all the way down into the bottom of Wicker Basket (Q) by hand. Figure 15 Then slowly push the other side of Basket Bottom Panel (S) into the bottom of Wicker Basket (Q) by hand.
- Page 14 Put the 2pcs complete baskets (Q) onto the Bottom Frame (F) as shown. Put the 3pcs complete Baskets (R) onto the Top Frame(E) as shown Figure 19 Find a desired location. Mark 2 locations for screws on wall One screw (for each unit) must be attached directly into a wall stud.
- Page 15 Insert Plastic Anchors (7) into the holes on wall as shown.(When doing this, you will need a hammer to help you) Figure 21 Using the Phillips head screwdriver, install Screw (6) through holes on Wall Brackets (8) into Wall Anchors to attach Wall Brackets (8) onto Wall Anchors (6).
- Page 16 Move this item close to the fastened wall brackets and tie in brackets and side frame with Plastic Straps (9) as shown in diagram. Check to make sure the strap is securely laced and locked to the brackets. Figure 23 Now your Javu Wine Storage Console is ready to use Figure 24...
- Page 17 90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
