P/N 126647-01 Rev. E 02/2018
Ce manuel est disponible en francais, simplement
en faire la demande. Numéro de la pièce 126647-02.
P126647 01
This book is valuable. In addition to instructing you on how to install and maintain your appliance, it also
contains information that will enable you to obtain replacement parts or accessory items when needed. Keep
it with your other important papers.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
This wood burning fireplace complies with UL127
CAN/ULC-S610-M87 standard as a FACTORY
BUILT FIREPLACE.
This fireplace is approved for use as a wood burning fireplace or for use with a vented gas log approved to
ANS Z21.60, Z21.84 standards or for use with a vent-free gas log heater approved to ANS Z21.11.2 standard.
An INNOVATIVE HEARTH PRODUCTS, LLC hood must be installed when using a vent-free log heater (see Ac-
cessories, page 17).
FOR CANADA: The authority having jurisdiction
(such as the municipal building department, fire
department, etc.) should be contacted before
installation to determine the need to obtain a permit.
This installation manual will enable you to obtain a safe, efficient and dependable installation of your fireplace
system. Please read and understand these instructions before beginning your installation.
Do not alter or modify the fireplace or its components under any circumstances. Any modification or alteration of
the fireplace system, including but not limited to the fireplace, chimney components and accessories, may void the
warranty, listings and approvals of this system and could result in an unsafe and potentially dangerous installation.
IMPORTANT! TO ASSURE PROPER ALIGNMENT OF GLASS DOORS: INSTALL THIS FIREPLACE IN A SQUARE
AND PLUMB CONDITION, USING SHIMS AS NECESSARY AT SIDES AND/OR BOTTOM.
PFS
C
REPORT NO. 09-146
SAVE THIS BOOK
NOTE: DIAGRAMS AND ILLUSTRATIONS THROUGHOUT THE MANUAL ARE NOT TO SCALE.
INSTALLATION AND OPERATION
Astria® Multi-Sided
Wood burning Fireplaces
®
US
Installateur : Laissez cette notice avec l'appareil.
Consommateur : Conservez cette notice pour consultation ultérieure.
Ce foyer au bois est conforme aux UL 127 CAN/ULC-
S610-M87 norme comme une USINE CONSTRUITE
CHEMINÉE.
POUR LE CANADA: L'autorité compétente (comme le
service municipal du bâtiment, les pompiers, etc.) doit
être contacté avant l'installation afin de déterminer la
nécessité d'obtenir un permis.
INSTRUCTIONS
MODELS
Inglenook CRP2
Inglenook CLP2
Advertisement
Table of Contents
Summary of Contents for Astria Fireplaces Inglenook CRP2
- Page 1 Astria® Multi-Sided Wood burning Fireplaces P/N 126647-01 Rev. E 02/2018 Ce manuel est disponible en francais, simplement MODELS en faire la demande. Numéro de la pièce 126647-02. Inglenook CRP2 ® Inglenook CLP2 P126647 01 REPORT NO. 09-146 SAVE THIS BOOK This book is valuable.
-
Page 2: Table Of Contents
Thank you for your purchase. We appreciate your TABLE OF CONTENTS business! Safety .....................2 Please carefully read and follow all instructions in this manual. Pay Dimensions ..................4 special attention to all warnings and safety information. Fireplace Installation ..............5 Following these safety, care, and operation instructions will help Venting Installation ................7 ensure many years of dependable and enjoyable service from your Optional Gas Line Installation ............13... - Page 3 SAFETY Continued WARNING: CONTINUED OVERFIRING CAN PER- WARNING: BURNING IMPROPER FUEL (I.E. MANENTLY DAMAGE YOUR FIREPLACE SYSTEM. CHARCOAL) CAN RESULT IN CARBON MONOXIDE SOME EXAMPLES OF CONDITIONS THAT COULD POISONING, WHICH MAY LEAD TO DEATH! CAUSE OVERFIRING ARE: Carbon Monoxide Poisoning – Early signs of carbon monoxide poisoning resemble the flu with headaches, •...
-
Page 4: Dimensions
8" (204 mm) 8-3/4" (223 mm) 10-1/2" 12" (305 mm) (667 mm) 16-1/4" (413 mm) MODEL CATALOG NO. Inglenook CRP2 F0698 Inglenook CLP2 F0699 20" (508 mm) 20" (508 mm) Inglenook CRP2 F0700 Inglenook CLP2 F0701 Figure 1 - Dimensions Astria.us.com... -
Page 5: Fireplace Installation
FIREPLACE INSTALLATION GLOSSARY Flush Installation - type of installation where front face of fireplace is even or level with wall. Chase Installation - type of installation where chimney is enclosed. Perpendicular Side Wall - applies to minimum clearance between " "... - Page 6 FIREPLACE INSTALLATION Continued HEARTH EXTENSION Combustible " Material A hearth extension projecting a minimum of 20" in front of and a (312 mm) Ref. minimum of 12" beyond each side of fireplace opening is required to protect combustible floor construction in front of fireplace. Fab- Safe Zone for ricate a hearth extension using a material which meets the following Projection of...
-
Page 7: Venting Installation
Outside air handle is located on left-hand side of fireplace refractory end up. Press down on each pipe section until lances securely engage (see Figure 9, Model Inglenook CRP2 shown). To close, pull down; hem on fireplace starter. The wire will assure proper spacing between to open, push up. - Page 8 8" Stainless " " Inner Pipe 33" " " 78" " 82" LINEAL GAIN PART NO. DESCRIPTION GAIN " " Inglenook CRP2/CLP2 Fireplace 42" " " 12-8DM Pipe Section " " " 18-8DM Pipe Section " 24-8DM Pipe Section "...
- Page 9 VENTING INSTALLATION Continued Return Return Elbow Elbow Return Elbow Offset Offset Elbow Elbow 6' (1.88 m) 6' (1.88 m) Max. Max. Ceiling Support Return 6' (1.88 m) Pipe 12S-8DM Elbow Max. 6' (1.88 m) Return Max. Offset Offset Elbow Elbow 6' (1.88 m) Offset Elbow...
- Page 10 VENTING INSTALLATION Continued Thimble 38FST or 12S-8DM FST30 Support Firestop 20 FT. 20 FT. (6.10 m) (6.10 m) Figure 15a - Firestop Thimble Return Elbow SUPPORT SECTIONS (12S-8DM) The chimney support section is a 4-strap 12" length of pipe. The height of a vertical chimney pipe supported ONLY by the fireplace, must not exceed 20 feet.
- Page 11 VENTING INSTALLATION Continued FLASHING INSTALLATION PENETRATING ROOF Determine flashing to be used with roof opening chart. Slide flashing To maintain a 2" clearance to pipe on a roof with a pitch, a rectangular over pipe until base is flat against roof. Replace as many shingles as opening must be cut.
- Page 12 VENTING INSTALLATION Continued 10 FOOT RULE CAUTION: Do not seal openings on the rooftop All chimney terminations must extend a minimum of 3' above the flashing. Follow the installation instructions provided highest point where it passes through the roof and must be at least with the termination being used.
-
Page 13: Optional Gas Line Installation
OPTIONAL GAS LINE INSTALLATION If you install a decorative gas appliance (vented gas log), decorative WARNING: A qualified service person must con- gas appliance must comply with the Standard for Decorative Gas nect fireplace to gas supply. Follow all local codes. Appliance for Installation in Solid Fuel Burning Fireplaces, ANSI Z21.60/CSA 2.26 or Z21.84 and shall also be installed in accordance A gas line may be installed for the purpose of installing a vented... -
Page 14: Operation And Maintenance Guidelines
OPERATION AND MAINTENANCE GUIDELINES VENT-FREE GAS LOG INSTALLATION Chimney Flashing Only unvented gas log sets that comply with the standard for un- Termination vented room heaters, ANS Z21.11.2, can be installed in this fireplace. Chimney Note: An appropriate IHP PRODUCTS, LLC hood (see Replacement Sections Parts and Accessories, pages 15 and 16) must be installed when using an unvented gas log set. -
Page 15: Replacement Parts
OPERATION AND MAINTENANCE GUIDELINES Continued GLASS DOORS Cleaning Glass Bi-fold glass doors are optional with this fireplace. Check with your Clean glass with any commercial glass cleaner or soap and water. local distributor for availability. Do not use any abrasive material to clean glass. Do not clean glass with any cool water if glass is still hot from the fire. -
Page 16: Fireplace Accessories
FIREPLACE ACCESSORIES CAT NO. MODEL DESCRIPTION REFRACTORY (36" Left Side Shown) J7010 Refractory, Back 36L/R/LS/RS J7011 Refractory, Side 36L/R/LS/RS J6908 Refractory, Bottom J6909 Refractory, Bottom GRATE J4518 Grate 36" L 36LGR J4519 Grate 36" R 36RGR SCREEN ASSEMBLY J7653 Screen 23X21 (Not Shown) J4956 Nut Push-On.765X.445X.011 Black... - Page 17 INSTALLATION ACCESSORIES Continued FIRESTOP SPACER F0907 3600FS-8DM-1 1" Clearance Firestop Spacer ( 1ea.) F0904 FS-8DM 2" Clearance Firestop Spacer (1 ea.) ROOF FLASHING F0909 V6F-8DM Roof Flashing 0 to 6/12 Pitch (30" Base) F0910 V12F-8DM Roof Flashing 6/12 to12/12 Pitch ANTI-DRAFT SHIELD (Round Top Termination Only) F0927 ADS-8DM...
-
Page 18: Important Notices - Canada
IMPORTANT NOTICES IMPORTANT NOTICE NOTICE: The firebox canopy (hood) Canadian code CAN/ULC-S610-M87 and other pertinent A manufactured shroud which codes require stainless steel chimney for the installation must not be modified or replaced with of this fireplace. A Cold Air Climate Kit is also required has been approved by a na- a canopy that may be provided with in Canada and is recommended for cooler regions in the... -
Page 19: Draft Smoke Guidelines
APPENDIX A Draft Requirements take into account all variables within the installation and install the appliance in such a manner that satisfies the draft requirements of Your wood-burning appliance is dependent upon a properly func- the appliance. See Chimney Guidelines to assist you in selecting the tioning chimney for optimum performance. - Page 20 APPENDIX A Continued Smoking – Causes And Troubleshooting Location Recommended To reduce the likelihood of smoking when opening the door, open Marginal Location the combustion air control or damper before opening the door. Wind Direction Your appliance has been designed and tested to provide smoke free Tree operation.
- Page 21 NOTES ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ 126647-01_E Astria.us.com...
- Page 22 NOTES ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ Astria.us.com 126647-01_E...
-
Page 23: Warranty
Innovative Hearth Products Astria Brand Wood-Burning Fireplace ® 20 Year Limited Warranty THE WARRANTY Innovative Hearth Products ("IHP") 20 Year Limited Warranty warrants your Astria ® brand wood burning fireplace ("Product") to be free from defects in materials and work- manship at the time of manufacture. - Page 24 Astria.us.com Record the following important information about your fireplace: Fireplace model number Fireplace serial number Date fireplace was Installed Dealer name P126647 01 Innovative Hearth Products reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products. Consult your local distributor for fireplace code information.
