Crest Electronics CCA-7910WF-21 User Manual

Specification

CCA-7910WF-21
Model
1/4" Aptina 1.0MP CMOS Sensor
Pick up Element
Effective Picture Elements
NTSC:976(H)×494(V)
(H×V)
Horizontal Resolution 720 TV Line
Minimum Illumination 0.001 Lux/F1.2
S/N Ratio More than 50dB
Scanning System 2:1 interface
Internal, Negative sync.
Synchronous System
NTSC: 1/60s~1/100,000s
Auto Electronic Shutter
Gama Characteristic 0.45
65 Feet (with ￠5X24 PCS Infrared LED)
IR Distance
Video Output 1Vpp, 75Ω
Auto
Auto Gain Control
Power/Current DC12V(+/-10%)/500mA
Lens Board Lens 3.6mm/F2.0
Dimension (in) 6.7(W) x 2.9(H) x 2.6(D)
Weight (lb) 1.1
Storage Temperature -22°F~140°F RH95% MAX
14°F~122°F RH95% MAX
Operating Temperature

Packing List

No
Name
1.
Weatherproof IR Color Camera
CCA-7910WF-21
2.
CCA-7910WF-21
User Guide
Model Number
1
1
ALLIANCE
DRIVE
GREENSBORO, NC
-
- -CREST/ - -
FAX:
- -
www.crestelectro ics.co
CCA-7910WF-21 Color Camera
Weatherproof IR Color Camera
AHD/960H Analog
NOTE
Please read this guide
BEFORE installing
