IX32 Wireless Ceiling PIR Detector User Guide
Ⅰ.
Introduction
IX 32 Wireless Ceiling PIR Intrusion Detector, employs digital micro-control
Energy collected process and dynamic random time division technology.
By use of high precision cylindrical Fresnel lens, increase its energy
received efficiency. High sensitivity and accuracy combined with advanced
software technology, make it more effectively detect true invader, or other
competitors that may cause false alarm. Excellent detective and false-less
performance, optional pulse count, completely meets various environments,
reduce potential false alarm possibly, high performance compared to other
competitors, large capacity internal battery. Exclusive power saved solution,
it supports at least 2 years.
Ⅱ.
Specification
Type: IX32
：
Detection Distance 6 m @ 25
：
RF Range 120m
：
Input Voltage 3 VDC(2PCS LR 6 1.5V AA Battery)
：≤1 μ （
Current 5 A Standby
Detection Range:(as diagram )
Optional lens data
Infrared Area：12+12+6
Max. Detection Square：6 m
RF Frequency: 433.92MHz (Default)/868MHz
Alarm Output: LED indicator turns on >3s
Ⅲ .
Installation
3.1 Installation Guide
X
Don't face hot/cold source
3.2 Installation Procedure
Screw
Expansive Tube
#5 Battery
1.Take the screw, expansive 2.Turn over the alarm, anti-clockwisely
tube and 2 pcs #5 battery. rotate the hanging panel,
and remove it.
Side looking
℃
） ≤1 （ ）
5mA Alarm
Down looking
360
diameter
X
Avoid direct sunshine
3. Insert 2 pcs #5 battery in right
polarity.
LED Indicator
Infrared Lens
Back Shell
Picture 1 External View
-
2.5~4.0m
Max.6m
-
Detection Range
Wired detector should be away
from high-pressure cable
(1)Underline
and make hole
(2) Insert tubes
(3)Fix the panel
4.Make location hole as picture indicates,
knock the expansive tube in it, use screw
knife to make the screws entering, then
the panel can fix on the wall.
- -
1
Tamper Switch
Jumper Setting
Battery Box
Installing Location
(2PCS)
Front Case
Picture 2 Internal Structure
Installing Method: Ceiling Mounted
Mounting Height 2 5~4m : .
Operating Temperature: -20
Storage Temperature: -20
Dimension: (L*W*H)100*100*33.5mm
X
Installation base should
be stable
(2)Clockwisely Rotation
(1)Upward Installation
5.Hold the device in ordinary grip, let the back
hole face to raisedpart of the panel to install,
then clock wisely whirl it the bottom, so the
device can be fixed.
Hanging Panel
℃ ℃
~50
℃ ℃
~60
