Bastl KASTLE v 1.5 Manual

INSTRUCTIONS
Kastle is a mini modular synth and as in every
modular synth the sounds are programmed by connecting outputs to inputs. Outputs
are labeled by a silver outline around the patch points. Inputs don't have the silver
14 0 1
outline. Feel free to also connect inputs with inputs and outputs with outputs. Nothing
bad will happen. And sometimes something interesting can happen with strange
connections!
0
I / O USB POWER OUT
Find a microUSB cable or go to your nearest store and buy 3 AA batteries. You can
2 0 2
catch Pokemons on the way, though you don't have to, but the important thing is that
USB
BATT on average you will burn 50 calories. Also, not shipping the batteries to you from us is
PITCH MOD OSC PITCH
environmentally friendly.
Connect the USB cable to a powered 5V USB socket or insert the batteries to the
battery compartment the right way - as indicated on the battery holder.
3 I / O 3
14 5
L R WAVESHAPE Flip the power switch to the USB or BATT position based on which power source you
are using. There is a LED close to the LFO RATE knob which should light up. If it doesn't
TIMBRE MOD 8 OSC OUT OSC TIMBRE
4 it means the USB socket is not powered or you connected the batteries in a wrong
7 6 OSC
MODE
way or they are completely depleted.
9 2 11 LFO
1
3 12 10 9 LFO
Use the OUT jack to connect your headphones or an audio cable from your
RATE MOD LFO RATE
9 13 speaker system. The main output of the complex oscillator is routed to the OUT jack.
LFO BIT IN
RST STEPPED
2
patched to the OSC OUT socket to mix with the main waveform or it can be output
Turn the OSC PITCH knob to adjust the PITCH of the main oscillator. A modulation
separately via the I/O jack.
signal can be connected to the PITCH MOD socket and the PITCH MOD knob controls
7
the amount of the modulation.
The MODE socket lets you select the synthesis mode. The synthesis mode affects
3
both the OSC OUT and the SECONDARY OSC OUT.
Turn the OSC TIMBRE knob to adjust the PITCH of the modulating oscillator.
When nothing is connected the synthesis mode at OSC OUT is phase modulation
A modulation signal can be connected to the TIMBRE MOD socket and the TIMBRE
and at SECONDARY OSC OUT is phase distortion.
MOD knob sets the amount of the modulation.
When a modulation signal plugged into this jack is high (or just patched to "+"
4
socket) the synthesis mode becomes track & hold modulation on the OSC OUT and
Turn the WAVESHAPE knob to adjust the 3rd parameter of the sound. A modulation
formant synthesis on the SECONDARY OSC OUT.
signal can be connected to the WAVESHAPE socket to modulate this parameter. The
When the signal connected here is low (or just patched to "–" socket) you are
WAVESHAPE also sets the pulse width of the OSC PULSE output.
in dual noise mode with more tonal character at the SECONDARY OSC OUT.
5
See the Synthesis Types section for more information.
This patch point on the device can be either used as another signal for your patch
or when any other output is connected to this output it will be passively mixed with 8
To set the MODE socket statically to specific synth mode use the low = "–" or high
the oscillator output and will go to the OUT jack. This is most useful for adding more
power by connecting the SECONDARY OSC OUT. = "+" patch sockets. These patch points can be also useful to set the BIT IN pin. "+"
can be used to offset any modulation signal and "–" connects directly to ground so it
6
The SECONDARY OSC OUT provides alternative waveform based on the second- can be used to connect grounds between several instruments.
ary modulating oscillator and the waveform can be adjusted by the WAVESHAPE
9
parameter. It can be either used to modulate parameters within the Kastle synth or The LFO RATE sets the speed of the modulation. The modulation is displayed by
an LED close to the LFO RATE knob. A modulation signal can be connected to the current state of 3 bits of internal binary 8 bit shift register. The shift register is shifted
RATE MOD socket and the RATE MOD knob sets the amount of the modulation. This is with every new voltage generated. When this happens - based on the signal at the BIT
especially useful when creating more complex modulation curves. See Tips & Tricks IN socket - the new bit arriving to the shift register remains the same (BIT IN is low), is
section for more info. inverted (BIT IN is not connected) or is generated randomly (BIT IN is high). It means
that when BIT IN is not connected the STEPPED output generates a 16 step pattern.
10
When it is low it generates an 8 step pattern. When it is high it keeps generating
The LFO TRIANGLE socket outputs simple triangle waveform, but it can be
a random pattern and when it is altering it generates a semi-random pattern. The
altered by modulating the LFO RATE or triggering the LFO RST to get some complex
STEPPED output is very useful for modulating every parameter in the Kastle synth
modulation shapes.
or any external device with the I/O port.
11
The LFO PULSE socket outputs PULSE wave in sync with the TRIANGLE wave.
14
The I/O CV port enables you to connect up to 2 modulation/audio/clock
When the TRIANGLE wave is rising the PULSE output is high and when it is falling the
signals from Kastle to external gear or to connect any external signal to modulate
output is low. This signal can be used for synchronising external equipment.
the Kastle synth. The signals are output with a stereo jack and the patch points
12
L and R connect either to the left or right channel. To use both channels with a
The LFO RST resets the phase of the LFO to the highest point of the triangle and
modular synth you can use stereo to mono splitter adapter or you can just use one
then the triangle begins to fall. This is very useful for creating complex modulation
channel (L) with a mono cable connected to the I/O jack. When connecting external
curves or for synchronising with external clock.
modulation to Kastle please note that the signal will be rectified and Kastle will
13
respond only to signals 0-5V.
The STEPPED generator is inspired by the Rungler circuit by Rob Hordijk. It can
produce 8 different voltages. It generates new voltage twice per period of the LFO
(every time the direction changes from rising to falling). The voltage is based on the SEE WWW.BASTL-INSTRUMENTS.COM FOR MORE INFORMATION.
FEATURES v 1.5
© complex oscillator
© 3 synthesis modes on the main output: phase modulation, noise mode,
track & hold modulation
© 3 more modes on the secondary OSC output: phase distortion, tonal noise mode,
formant synthesis
© PITCH control with offset and CV input with attenuator
© TIMBRE control with offset and CV input with attenuator
© WAVESHAPE control with offset and CV input
© voltage controllable LFO with triangle and square outputs and reset input
© stepped voltage generator with random, 8 step and 16 step loop mode
© 2 I/O CV ports that can be routed to any patch point
© the main output can drive headphones
© 3x AA battery operation or USB power selectable by a switch
© open source
© possibility of exchanging different LFO and OSC chips
© durable black & silver PCB enclosure
WHAT IS IN THE BOX
© kastle synth ©10 patch cables © sticker
© for environmental reasons we are excluding the batteries in the package
