- Page 1 HiArc S 400R, 400A Operating manual Manual de instrucciones Manuel d’utilisation Manual de utilização Инструкции по эксплуатации...
- Page 3 Operating manual english...
-
Page 4: Table Of Contents
3.2.2 Control panel and SETUP functions, HiArc S 400R ............ -
Page 5: Introduction
This operating manual contains important information on the use, maintenance and safety of your Kemppi product. The technical specifications of the device can be found at the end of the manual. Please read the operating manual and the safety instructions booklet carefully before using the equipment for the first time. -
Page 6: Machine Introduction
Negative (-) pole connection socket (earth return cable) Positive (+) pole connection socket (welding cable) Main switch (ON/OFF) Mains power cable Hiarc s 400a Power on pilot lamp Overheating pilot lamp Amperage/voltage meter display Amperage/voltage meter display selection button ArcForce HotStart HiArc S 400R, 400A... -
Page 7: Installation
The machine is not allowed to be operated in the rain as the protection class of the machine, IP23S, allows preserving and storing outside only. Never aim the spray of sparks from a grinding machine toward the equipment. NOTE! © Kemppi Oy / 1418... -
Page 8: Distribution Network
Always switch the machine on and off from main switch. Do not use the mains plug for NOTE! switching! Never watch the arc without a proper face shield designed for arc welding! Protect yourself NOTE! and the surroundings against welding arc and hot spatters! HiArc S 400R, 400A... -
Page 9: Control Panel And Setup Functions, Hiarc S 400R
3.2.2 Control panel and setup functions, Hiarc s 400r Welddata After welding has finished, the display shows the measured average current of the last weld. This weld data is only displayed if the welding cycle lasts for 5 seconds or more. -
Page 10: Control Panel And Setup Functions, Hiarc S 400A
HotStart. Factory setting in the middle. Adjust to value 0 = no HotStart, adjust to 10 = HotStartMax Welding Mode. Press to select TIG or MMA mode. Light indicates the selection. 10. Remote Control. Press to select remote or panel control. Light indicates remote control. HiArc S 400R, 400A... -
Page 11: Activation And Setup Parameter Adjustment, Hiarc S 400A
35 V. This reduces the risk of electric shock in particularly dangerous environments, such as closed or damp spaces. VRD is activated through the setup menu. VRD is a feature of HiArc S 400A model, not available on the R model. © Kemppi Oy / 1418... -
Page 12: Mma Welding
When removing the slag coating, ensure you protect your eyes and face with suitable equipment. For more info, visit www.kemppi.com > Welding ABC. 3.3.1 Filler materials and equipment HiArc S series can be used with most of the common electrode types for DC welding. For welding with cellulosic electrodes, the optional kit should be fitted. -
Page 13: Electrode Welding Parameter Table
Ensure that the power source current setting is correct for the electrode size selected. Draw the welding face shield over your eyes. (Electronic welding face shields like Kemppi Beta 90X allow you to see the welding start point more accurately and better concentrate on the welding process. -
Page 14: Tig Welding
To stop welding, quickly pull the electrode away from the work piece. < 1.0 s Order information for the additional equipment (TIG torch) required for TIG welding can be found in 'Ordering codes' section later in this manual. HiArc S 400R, 400A... -
Page 15: Carbon Arc Gouging
Only authorised and trained personnel can carry out maintenance and repair processes. service contract Kemppi service workshops make special service contracts with customers about regular maintenance. All parts are cleaned, checked and if necessary, repaired. Also the operation of welding machine is tested. -
Page 16: Disposal Of The Machine
The owner of the equipment is obliged to deliver a decommissioned unit to a regional collection centre, as per the instructions of local authorities or a Kemppi representative. By applying this you will improve the environment and human health. -
Page 17: Control Panel Error Codes
70 mm², 5 m 6184701H Earth return cable 50 mm², 5 m 6184511H 70 mm², 5 m 6184711H Display cover SP006989 Slide bars SP007023 R10H remote control for HiArc S 400A 6185431H TTM 15 V BC 627143201 © Kemppi Oy / 1418... -
Page 18: Technical Data
Efficiency at 100 % 0.89 0.89 Degree of protection IP23S IP23S EMC class External dimensions L x W x H 570 x 270 x 340 mm 570 x 270 x 340 mm Weight 19.5 kg 20 kg HiArc S 400R, 400A... - Page 20 KEMPPI OY KEMPPI, TRADING (BEIJING) COMPANY LTD Telefax +44 (0)845 6444202 Kempinkatu 1 sales.uk@kemppi.com Room 420, 3 Zone, Building B, PL 13 No.12 Hongda North Street, KEMPPI FRANCE S.A.S. FIN-15801 LAHTI Beijing Economic Development Zone, 65 Avenue de la Couronne des Prés...
