O W N E R ' S M A N U A L
1. Read this manual carefully before starting assembly. Read each step completely before beginning
each step.
2. Some smaller parts may be shipped inside larger parts. Check inside all parts and cartons
before assembling or ordering parts.
3. To make assembly of your basketball system easier , use the Hardware Identifier on page 4 to
identify and sort all fasteners. Check all cartons for kits. All hardware is not located in one kit.
4. Do not tighten hardware until instructed to do so. If hardware is tightened too soon, mounting holes
may not align and parts may not easily fit together . Leave locknuts slightly loose until you are instructed to
tighten them.
5. An electric screwdriver is helpful in assembly. However, please set at low torque and use caution
because you could overtighten the hardware and strip the screws.
6. Save these instructions and your proof of purchase (receipt) in the event that the manufacturer
has to be contacted for replacement parts.
Please Do Not Return This Product T o The Store!
Contact Escalade
Phone:
1-888-USA-GOAL
Fax:
1-866-873-3536
E-mail:
basketball@escaladesports.com
Mailing Address (correspondence only):
Escalade Sports
PO Box 889
Evansville, IN 47706
Please visit our World Wide Web site at:
www.escaladesports.com
ON-LINE TROUBLE SHOOTING
ON-LINE PARTS REQUESTS
ADDITIONAL ESCALADE
Escalade
Sports products may be manufactured and/or licensed under the following patents:
®
6419596, 6179733, 5919102, 5071120, 4798381, 4424968, D326128, 7244046
Additional patents may be pending. One or more of the listed patents and/or pending patents may cover specific product.
Sports customer service department at:
®
SPORTS PRODUCT INFORMATION
®
Toll – Free!
Toll – Free!
TECHNICAL ASSISTANCE
FREQUENTLY ASKED QUESTIONS
MODEL NO.
B5400
SB54ig
BASKETBALL SYSTEM
ITEMS NEEDED (not included)
9-
50 lbs bags of concrete
(2-3 extra bags recommended)
Post hole digger (optional)
1-
Wheel barrow
1-
Garden hose
1-
1-
Level
1-
Tape Measure
6-
2X4's
2-
50 lbs sand bags
1-
Standard masonry block
9/16", 3/4" & adjustable wrench
1-
Cordless drill & 9/64" drill bit
1-
5/16" socket driver (for cordless drill)
1-
1-
Pair of Safety Glasses
1-
Phillips Screwdriver
1-
Ladder
1-
Piece of Plywood or Mdf
(see Figure 3 on Page 6)
©
2013 Escalade Sports
2L-7196-03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Silverback B5400 and is the answer not in the manual?

Questions and answers

Summary of Contents for ESCALADE Silverback B5400

  • Page 1 Sports products may be manufactured and/or licensed under the following patents: ® 6419596, 6179733, 5919102, 5071120, 4798381, 4424968, D326128, 7244046 Additional patents may be pending. One or more of the listed patents and/or pending patents may cover specific product. © 2013 Escalade Sports...
  • Page 2: Safety Instructions

    SAFETY INSTRUCTIONS FAILURE TO FOLLOW THESE WARNINGS MAY RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. Owner must ensure that all players know and follow these rules for safe operation of the system. WARNING FAILURE TO FOLLOW THESE WARNINGS MAY RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE.
  • Page 3 WARNING DO NOT DUNK ON THIS UNIT . DO NOT HANG FROM ANY PART OF THIS UNIT , INCLUDING THE BACKBOARD, RIM, SUPPORT BRACES OR NET. 4L-8152-01 (Affixed to Top Post) Bottom of upper pole must cover the above orange portion of this sticker (6”...
  • Page 4 3/8-16” Lock Nut (14 pieces) 3/8 - 16 X 1 3/4 Hex Bolt (4 Pieces) (2 Pieces) 1/2”-13 Lock Nut (1 piece) #10 X 1 (10 Pieces)
  • Page 5 INSTALLATION TIMELINE 1. Prior to pole installation and goal assembly, call utility services for location of underground utility lines before you dig. 2. Vertical main post assembly is a two part process. PART 1 PART 2 Day 1. Post assembly, pour concrete, set post and Day 3.
  • Page 6 INSTRUCTIONS POST ASSEMBLY Before putting any of the poles tubes together, make sure that the orange area of the Warning Sticker on Pole (#2) is 6 inches from the top end. Be sure that Be sure to match up both the “Back Side”...
  • Page 7 SCREWS (#42) MUST BE INSTALLED TO POLE AS DESCRIBED IN STEP 3. FAILURE TO INSTALL SCREWS COULD RESULT IN SERIOUS INJURY OR PROPERTY DAMAGE. NOTE: Cordless drill required for screw installation. Do not over tighten screws causing screws to strip. Once Screw heads touch pole, STOP! Overtightening will cause Pole to Warp and damage system.
  • Page 8 *Tip: It is always a good idea to purchase two or three extra bags of concrete, just in case you need them. If IMPORTANT extra bags are not used you can return them to the store. THE FOLLOWING STEPS WILL REQUIRE Mix concrete per the instructions on concrete bag.
  • Page 9 Note: Periodically check pole with level to ensure that pole is vertical. Stabilize the pole by using six 2X4’s and placing two 50 lbs. bags of sand on top to keep pole from shifting, periodically check the pole with level to ensure that pole is vertical.
  • Page 10 ASSEMBLY INSTRUCTIONS (Day 3) IMPORTANT! BE SURE CONCRETE HAS BEEN ALLOWED TO CURE FOR AT LEAST 2 DAYS. Figure 7 Attach Post Ears (#30) to holes near the bottom of the Top Post (#3) using two hex bolts (#25) four washers (#18) and two lock nuts (#4). Do not tighten nuts (#4) completely until instructed to do so.
  • Page 11 IMPORTANT! Nylon washers (#5) adequately space painted parts at all pivot points. Neglecting the use of these washers will result in rusted parts. NOTE: All board arms are made of rectangular tubing. Tightening hardware too tight may damage tubing and make adjustment of system difficult. 13.
  • Page 12 Attach of Upper Arms (#6) to Top Pole (#3), as shown Figure 11, using a bolt (#7), two flat washers (#18), two spacers (#8) and one lock nut (#4). Note: Tighten bolts snug but, do not over tighten. Board Arms must pivot freely Figure 11 Stop Spacer (#10)
  • Page 13 Figure 13 HANDLE BACKBOARD WITH CARE, IT IS A GLASS ATTACHING BA CKBOARD T O BO ARD ARMS PRODUCT. ALWAYS WEAR SAFETY GLASSES AND REQUIRES AT LEAST THREE CAPABLE ADULTS. GLOVES WHEN HANDLING GLASS. 18. With at least two capable people, raise the backboard assembly up and have the third attach Lower Board Arms to lower mounting tubes on backboard using two bolts (#24), two plastic washers (#5), four washers (#18) and two lock nuts (#4).
  • Page 14 Mount Goal Assembly (#28) and Rim Pad (#27) to Backboard, as shown in Figure 14, using four bolts (#41), four washers (#26), and four locknuts (#4). Tighten fasteners, but leave them loose enough to level rim. Note: Make sure (#27) Rim Pad is installed between Rim (#28) and Backboard (#23) 21.
  • Page 15 Raise Backboard to 10 FT. regulation playing height. Measure from top of rim straight down to the playing surface. Using tape - mark the side of the steel actuator (#16) just under the plastic actuator sleeve (#15) at this 10 ft rim height. See Figure 15. Lower backboard all the way down.
  • Page 16 Secure Post Pad (#39) to front of pole by wrapping straps around pole and sticking to velcro on opposite side of Pad. Figure 18 Post Pad should cover Post Screws but remain below Warning Label on front of the Pole. See Figure 18. Make NOTE: Top of Pole Pad #48 should cover Post Screws but remain sure to reposition Pole Pad if Sliding occurs.
  • Page 17 OR OTHER CAUSES NOT ARISING OUT OF DEFECTS IN MATERIAL OR WORKMANSHIP . ® Subject to proper installation and normal Residential use, Escalade Sports warrants, subject to the limitations below, to the original retail ® purchaser all structural components of the Silverback System to be free of defects in material and workmanship for a period of Seven (7) years from the original purchase.
  • Page 18 SILVERBACK CARE INFORMATION - BACKBOARD - Items needed to clean backboard: 100% cotton soft cloth, (only) Glass Cleaner Clean backboard using a 100% Cotton soft cloth and glass cleaner. Clean glass as you would household windows. Strong cleansers will damage backboard and void warranty.
  • Page 19 (Pre-Installed) (Pre-Installed) (Pre-Installed) (Pre-Installed) (Pre-Installed) (Pre-Installed) , IN 2L-7196-03...
