JBL AC26-WH Technical Manual

Technical Manual
JBL AC26/-WH

SPECIFICATIONS

ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• Nominal Impediance:
• System Input Power Rating:
• Frequency Response:
• Frequency Range:
• System Sensitivity:
• Maximum SPL:
• Crossover Frequency:
SYSTEM COMPONENTS:
• Cabinet:
• Grille:
• Low Frequency
Transducer:
• DC Resistance:
• High Frequency
Transducer:
PACKAGE
JBL Incorporated, 8500 Balboa Boulevard, P.O. Box 2200, Northridge, California 91329 U.S.A.
8 Ohms
300W Continuous Pink Noise,
600W Program,1200W Peak
70 Hz - 18 kHz (±3 dB)
55 Hz - 20 kHz (–10 dB)
92 dB (1 Watt @ 1 Meter)
115 dB SPL Continuous
2.2 kHz
Enclosure (Not for Sale)
365014-001, 365014-101 (WH)
2 226J,165 mm (6.5 in.) Cone
Transducer
9.2 ohm
2414H, 25 mm (1 in.) Exit
Compression Driver
Warranty 59660
Specification Sheet
365229-001
Carton
365070-001
Filler (2)
365071-001
PKG,Microfoam (2)
49790P
20" X 18"
Sheets
SYSTEM COMPONENTS:
(CONT'D)
• DC Resistance:
• Crossover Network:
AURAL SWEEP TEST SPECIFICATIONS:
A. System Aural Sweep Test:
B. L.F. Aural Sweep Test:
C. H.F. Aural Sweep Test:
PHYSICAL SPECIFICATIONS:
• Enclosure Dimensions:
• Shipping Weight:
WARRANTY INFORMATION:
• Refer to Warranty Statement packed with each product.
WIRING DIAGRAM
Driver, Low Freq (2)
226J
(364706-002)
YEL/BLK
WHT/BLK
WHT
SEE NETWORK SCHEMATIC PAGE
NOTE: INDIVIDUAL PARTS FOR THE ABOVE CROSSOVER ARE NOT AVAILABLE.
A COMPLETE REPLACEMENT ASSEMBLY SHOULD BE ORDERED.
3.60 ohms ±0.2 ohms
365062-001
5.0V Input, 20 Hz to 20 kHz
5.0V Input, 20 Hz to 2 kHz
0.75V Input, 500 Hz to 1.5 kHz
539.8 x 199.4 x 226.1 mm D
(21.3 x 7.8 x 8.9 in.D.)
24.3 lb (11.0 kg.)
Driver, High Freq
2414H
(342423-002X)
YEL
Network
GRN
365062-001
GRN/BLK
04-10
