Monsoon Series High Pressure Blaster
OPERATION & MAINTENANCE MANUAL
Covers:
Monsoon 200
Monsoon 300
Monsoon 300 Maxi
Monsoon 400
Monsoon 400 Maxi
Hurricane
Feb 2010
Aussie Monsoon & Hurricane ... Operation & Maintenance Manual
Aussie Eco-Clean
(Three Phase Models)
TO REDUCE RISK OF INJURY,
READ OPERATING INSTRUCTIONS
CAREFULLY BEFORE USING EQUIPMENT
Australian Pump Industries
IMPORTANT:
1
Advertisement
Table of Contents
Summary of Contents for AUSSIE ECO-CLEAN Monsoon 200
- Page 1 Australian Pump Industries Aussie Eco-Clean Monsoon Series High Pressure Blaster (Three Phase Models) OPERATION & MAINTENANCE MANUAL Covers: Monsoon 200 Monsoon 300 Monsoon 300 Maxi Monsoon 400 Monsoon 400 Maxi Hurricane Feb 2010 IMPORTANT: TO REDUCE RISK OF INJURY, READ OPERATING INSTRUCTIONS CAREFULLY BEFORE USING EQUIPMENT Aussie Monsoon &...
-
Page 2: Warranty Coverage
Australian Pump Industries AUSSIE ECO CLEAN BLASTER OPERATING AND MAINTENANCE INSTRUCTIONS * * W A R N I N G * * AUSSIE HEAVY DUTY WATER BLASTERS ARE DESIGNED FOR PROFESSIONAL OPERATORS ONLY IMPORTANT INSTRUCT OPERATORS IN CARE AND USE OF THE MACHINE BEFORE USE! Before attempting to operate your machine please read this Instruction Manual thoroughly following all directions carefully. -
Page 3: Safety Precautions - Important
Australian Pump Industries SAFETY PRECAUTIONS - IMPORTANT NEVER direct the spray jet at any person or animal. NEVER direct spray jet at any surface that may contain asbestos material. NEVER hold a finger over the high pressure nozzle. NEVER direct the spray jet at the machine itself or any electrical equipment. After use release the pressure in the high pressure hose by operating the pistol trigger. -
Page 4: Operation
HOT WATER APPLICATION Aussie Eco-clean Monsoon & Hurricane water blasters can be used in their standard configuration with cold or hot water up to 60 C. Using optional Hot Shot seals and valves the pumps can be modified to operate with water temperatures up to 80 C. -
Page 5: Care And Maintenance
OPTIONAL LANCES - A range of optional lances in stainless steel or zinc plated steel are available in lengths of up to 2 metres. ROTARY CLEANER - The Aussie Eco-Clean rotary cleaner allows flat surfaces to be cleaned in a fraction of the time normally taken. Ideal for contractors and professional users. -
Page 6: Troubleshooting Guide
Australian Pump Industries TROUBLE SHOOTING GUIDE FAULT CAUSE REMEDY Pump running normally Pump sucking air Check water supply and possibility of air but pressure low on ingress. installation Valves sticking Check and clean or replace if necessary Unloader valve seat faulty Check and replace Nozzle incorrectly sized Check and replace... -
Page 7: Parts Identification
PARTS IDENTIFICATION Use motor size & pump model to identify your machine: Model Motor Pump Model Pump Pressure Flow rate Pump (psi) (lpm) Monsoon 200 7.5HP, 5.5kW, IP56 TTV2015 3000 4785 1450 Monsoon 300 10HP, 7.5 kW, IP56 TTV2021 3000... - Page 8 Australian Pump Industries PUMP PARTS TTV 2015 2021 (Monsoon 200, 300) Kit No. Part No. Description B069872973 Oil Seal & Sight Glass Kit B069867973 Valve Kit B069839973 Seal Kit Minor B069836973 Seal Kit Major B069814973 Oil Seal Kit Aussie pressure test Aussie pressure test set includes gauge and fitting for testing pump output...
- Page 9 Australian Pump Industries PUMP PARTS KKV 2028 (Monsoon 300 Maxi) Kit No. Part No. Description B069842973 Oil seal & Sight Glass kit B069817973 Valve Kit B069840973 Seal Kit Minor B069837973 Seal Kit Major B069813973 Oil Seal Kit Aussie pressure test Aussie pressure test set includes gauge and fitting for testing pump output Aussie Monsoon &...
- Page 10 Australian Pump Industries PUMP PARTS KTV 3015, 3021 (Monsoon 400, 400 Maxi ) Kit No. Part No. Description B069842973 Oil seal & Sight Glass kit B069867973 Valve Kit B069839973 Seal Kit Minor B069836973 Seal Kit Major B069814973 Oil Seal Kit Aussie pressure test set includes gauge and fitting for testing pump output Aussie pressure test set pressure and Bertolini Pump Selection Guide...
- Page 11 Australian Pump Industries PUMP PARTS HDS 5057 (Hurricane) Kit No. Part No. Description B069842973 Oil seal & Sight Glass kit B069833973 Seal Kit Minor B069834973 Seal Kit Major B069813973 Oil Seal Kit B069829973 Valve Kit Aussie pressure test set includes gauge and fitting for testing pump output Aussie pressure test set pressure and Bertolini Pump Selection Guide Aussie Monsoon &...
-
Page 12: Three Monthly Regular Service
Australian Pump Industries WARNING OVERSPEEDING Do not operate machine at over maximum pump rpm. Over speeding can cause serious pump damage. EXCESSIVE BYPASS Do not run on excessive by-pass. Switch machine off within five minutes of ceasing operation as excessive by-pass can cause heat build up in pump and subsequent damage.
