WARNING: Before use, Please carefully read the User Operation/Technical Manual for the
EZY302 pulse oximeter.
Ⅰ Ⅰ Ⅰ Ⅰ Product Information
The EZY302 pulse oximeter is intended for the measurement of pulse oxygen saturation of arterial
hemoglobin (SpO2) and pulse rate. This oximeter can be used for adult, pediatric，and neonatal patients.
Ⅱ Ⅱ Ⅱ Ⅱ Installation and Use
1. Battery Installation
Pull back the battery access cover, put in four "NiMH AA"size batteries in the right direction, and then
put back the battery access cover (See Figure 1).
Figure 1: Battery Installation
NOTICE: Always fully charge your batteries before use. When you charge the batteries for the first time,
or if the batteries have been stored for a long time, it normally takes about 3 charge and
discharge cycles for the batteries to regain full capacity.
2. Sensor Installation
Plug the finger probe connector in the oximeter sensor port and attach the finger probe to the patient
(See Figure 2).
www.tristatesurgical.com
EZY302 Pulse Oximeter
QUICK OPERATOR'S GUIDE
800-899-8741
Figure 2: Sensor Installation
Advertisement
Table of Contents
Summary of Contents for EzYCheckPro EZY302
- Page 1 EZY302 pulse oximeter. Ⅰ Ⅰ Ⅰ Ⅰ Product Information The EZY302 pulse oximeter is intended for the measurement of pulse oxygen saturation of arterial hemoglobin (SpO2) and pulse rate. This oximeter can be used for adult, pediatric，and neonatal patients. Ⅱ Ⅱ Ⅱ Ⅱ Installation and Use 1.
- Page 2 www.tristatesurgical.com 800-899-8741 3. Displays and Controls Figure3: Displays and Controls Power On/Off key: Press the key to turn the pulse oximeter on or off (needs to hold for 2 seconds or more). Selection key: Press the key to switch to testing mode, power setting mode, SpO2 average time mode, etc.
