Introduction

Dear Customer,

We thank for your wise decision to purchase the SODAX X1-X10, the Water-Soda

dispenser manufactured by the SODAX S.r.l. company in Italy.

Your SODAX X1-X10 dispenser contains the latest, most advanced technologies

utilized in the field of filtering and water purification in household/office water

dispensing systems.

In order to maximize your enjoyment and utility from this product, please read this

guide carefully; it contains the required safety information and will guide you, step by

step how to install, program and operate the dispenser's features. It will also show you

how to replace its consumable components, to ensure the continuous supply of

purified, filtered and tasty cold, warm, or hot water and of carbonated soda water (for

X1) .

Please comply with the warnings and safety precautions to prevent the risk of

accidental spillage of hot water. The child safety feature should always be activated

when applicable.

Please keep this guide handy for future reference.

Sincerely,

SODAX TEAM

Table of Contents

Need help?

Do you have a question about the X1-X10 and is the answer not in the manual?

Questions and answers

Summary of Contents for SODAX X1-X10

Page 1: Introduction
Introduction Dear Customer, We thank for your wise decision to purchase the SODAX X1-X10, the Water-Soda dispenser manufactured by the SODAX S.r.l. company in Italy. Your SODAX X1-X10 dispenser contains the latest, most advanced technologies utilized in the field of filtering and water purification in household/office water dispensing systems.
Page 2: Important Safeguards And Precautions
Important Safeguards and Precautions When using electrical appliances, basic safety precautions should always be followed, including the following: 1. Read all instructions. 2. Do not touch hot surfaces. Use handles or knobs. 3. To protect against fire, electric shock and injury to persons do not immerse cord, plugs, or appliance in water or other liquid.
Page 3: Instructions For Power Supply Connection
CAUTION This appliance is for household use only. Any servicing, other than cleaning and user maintenance, should be performed by an authorized service center. Do not immerse machine in water. To reduce the risk of fire or electric shock, do not disassemble the machine. There are no parts inside the machine serviceable by the user.
Page 4: Table Of Contents
Instructions for Power Supply connection ....................Safety instructions ....................Safety Precautions ....................... Overview Installing your SODAX X1 – X10 Water – Soda Dispenser ..........Preparing the SODAX X1 – X10 for operation ............................... Water Dispensing Display ....................The Settings Screen ...................
Page 5: Safety Instructions
• Do not make any modifications to the machine or its power cord. Only have repairs carried out by a service centre authorized by Sodax to avoid a hazard. • This machine is not intended for use by persons (including children) with reduced...
Page 6 CAUTION • The machine is for household use only. It is not intended for use in work environments. • Always put the machine on a flat and stable surface. • Do not place the machine on a hot plate, directly next to a hot oven, heater or similar source of heat.
Page 7: Safety Precautions
 DO NOT touch the power cord and/or the plug with wet hands. Locating the Dispenser:  Place the SODAX X1-X10 dispenser on a firm, smooth, horizontal surface such as the kitchen counter – away from heat generating sources (Grills, Ovens etc.) ...
Page 8: Overview
Overview Top cover Water reservoir UV lamp Main Display bottle (only X1) Water inlet port Water spout Filter housing opening handle Electric Cord Drip tray Filter housing Main fuse The Main Display (X1) Child Settings screen Protection icon Clock Active Boiling dispensing Water...
Page 9: Installing Your Sodax X1 - X10 Water - Soda Dispenser
Installing your SODAX X1- X10 Water – Soda Dispenser WARNING It is recommended that the connection of the SODAX X1-X10 dispenser to the household water supply system and the readying of the dispenser for use, will be accomplished by an authorized service person.
Page 10 3 bar.  An interception valve (ball type shut-off faucet) and a non-return valve must be installed between the SODAX X1-X10 dispenser water inlet and the water system. The faucet should be located in an easily accessible position. Fittings and pipes for connection to water mains must be certified for food compatibility. All the pipes and fittings provided have to comply with the above mentioned features.
Page 11: Preparing The Sodax X1-X10 For Operation
Preparing the SODAX X1-X10 for operation CAUTION The dispenser's heating & cooling systems will be enabled, ready to operate, only after the installation and sanitation procedures are completed. This is to insure the proper sanitation of the system before its first use (See page 14 for more details).
Page 12  Touch the NEXT screen button to confirm and continue. Selecting the water supply source mode  If the SODAX X1-X10 is to be fed by the household water system, touch the faucet icon.  If you chose to use the SODAX X1-X10 as...
Page 13 CAUTION Make sure the shutoff valve connecting the dispenser to the water supply system is CLOSED. Touch the NEXT screen button to continue. Make sure the faucet connecting the dispenser to the water supply system is OPEN. Touch the NEXT screen button Filling the built in water reservoir (standalone operating mode) Note:...
Page 14 The cleaning procedure cleanses the dispenser's internal system and the new filter by rinsing and washing away all possible foreign matter or residues. Preparing the SODAX X1-X10 for the cleaning procedure  Place a container (at least 3 liter capacity) under the dispenser's spout.
Page 15 (only X1). The next screen will advise that a few minutes are needed for the SODAX X1-X10 to heat and boil the water in its hot water reservoir.
Page 16: Water Dispensing Display
Water Dispensing Display (X10) Child protection disabled Child protection active Water Dispensing Display (X1) Child protection disabled Child protection active Dispensing water is accomplished by touching the desired icon. Touch the "COLD" or "SODA" icons briefly (soda only for X1), to dispense the set volume of cold or soda water which was determined using the SETTINGS display (see page 19).
Page 17: Dispensing Hot Water
Dispensing Hot Water WARNING DO NOT allow children under the age of 12 to use the boiling water feature of the dispenser. With small children present, keep the children safety feature activated at all times. Once installed, the dispenser maintains the hot water at a temperature range of 80C to 92C. In case no hot water is dispensed after 60 minutes the boiler goes automatically in standby mode, keeping the internal temperature at 60°C.
Page 18 Dispensing Soda Water (only for X1) Touch and hold the soda water icon to dispense the required volume. Automatic dispensing of a preset soda water volume is not available. When the soda water reservoir is empty, a warning will be displayed. Wait until the soda water reservoir is filled and the CO gas is injected into the reservoir.
Page 19: The Settings Screen
The Settings Screen Tech Support Setting the Sodax X1-X10 features The SETTINGS display screen contains six icons which represent the main functions that may be set and customized to meet your personal needs and preferences. Date & Volumes & Time...
Page 20 Child Safety In the SETTINGS display touch the icon. The Child Protection display will appear. Turning the child safety feature ON and OFF To prevent children from dispensing hot or boiling water from the dispenser, touch the Child Saftey ON icon. The icon will be highlighted and will be copied to the upper part of the Water Dispensing Display To disable the Child Safety feature, touch the...
Page 21 Setting the Times Touching this icon will enable you  To set the time indicated on the dispenser's display.  To set the Energy Saving feature.  To set the Sleep/Wake Up mode. Touch the TIME icon in the SETTINGS clock options display to access the set time options.
Page 22 Setting the Energy Saving Mode To access the Energy Savings mode display touch the icon in the SETTINGS = Clock Options screen. The Energy Saving mode is intended to save on electricity costs during periods when the dispenser is not in frequent use.The hot water temperature will be lowered to 60C. To return to the boiling water function, touch the EXTRA HOT icon and wait for the boiling to end.
Page 23 Setting the Sleep / Wake up Mode The SLEEP MODE is designed to saves electricity consumption during night time when dispenser is not in use. In this mode, the heating element is disabled, cancelling the automatic boiling and the display is darkened.
Page 24 Setting the dispensed Water Volumes and Temperatures This function, enables you to set the characteristics which suit the multiple users' personal preferences. The automatic water dispensing may be set in accordance with the glass volume and the desired temperature. You may also set the carbonation level ("strength") of the soda water (only for X1). You may set the exact water volume that will be dispensed into a glass by briefly touching the appropriate glass icon.
Page 25: Setting The Hot Water Temperature
The following display will appear Touch the icon to set the hot water volume.  Place a glass under the spout.  Touch and keep your finger on the icon during the dispensing.  When the glass is filled to the desired volume lift your finger off.
Page 26 Setting the MY CUP Feature Touch the icon on the SETTINGS display to access the volume and temperature of the MY CUP feature. Touch the MY CUP icon to access the setting of the personal preferences menu. You may set the volumes and temperatures for 4 persons including a baby's bottle.
Page 27 Setting the Water Volume for a Baby Bottle  Place a baby bottle under the spout and touch the bottle icon  Keep your finger on the icon while water is dispensed into it.  When the desired level is reached, lift your finger off the icon.
Page 28 Setting the Carbonation Level (only X1) You may select one of the tree available water carbonation levels ("Soda strength"): Light, Medium and Strong. The dispenser's soda water carbonation level default is "Medium". To select/change the carbonation level, access the SETTINGS display ...
Page 29 Setting the Cold Water Volume Touch the cold water icon in the SETTINGS = Cold display. To dispense a measured volume of water, you may select the measured volume of a drinking glass or of a water jug. To set the cold water volume to be dispensed into the glass touch the icon to access the menu.
Page 30 Setting the Volume of Cold Water in a Jug Touch the jug icon in the SETTINGS = Cold display to access the menu. To set the measured volume of cold water in a jug, Remuved the drop collector and insert it upside down Place the jug under the water spout.
Page 31 Changing the Display Language This feature is used to select/change the displays and menus language. To access the language select/change menu, touch the icon in the settings display. The language selection display will open.  Touch the flag icon representing the selected language.
Page 32 Changing the Dispenser's Water Supply Source During the dispenser's initial installation, a water supply source was selected. If you wish to change the present water supply source please contact the Service Department The change will have no effect the dispenser's performance. The changing of the water supply source is accomplished by using the SETTINGS display.
Page 33 If the dispenser's built in water reservoir was selected as the water supply source (the Standalone mode) please ensure the water faucet is closed. Touch the NEXT screen button to continue. Filling the Water Reservoir Following the selection of the built in water reservoir as the water source, the following display will appear: ...
Page 34: Replacement Of Consumables
Replacing the UV Lamp: When the year is over, a warning will display indicating that the service life of the lamp has ended and that the purification level of the water delivered by the SODAX X1-X10 is below the specified level.
Page 35: Replacing The Filter
Replacing The Filter The Sodax filter has been tested for high efficacy chlorine reduction and for high performance particle reduction. To ensure the supply of filtered drinking water per the specifications and to ensure the efficient filtering by the filter, the filter must be replaced every 6 months.
Page 36  Remove the used filter.  Unwrap the new filter and insert it into the filter housing so that the SODAX icon embossed on the filter will face upward and forward.  Using one hand, press the filter housing while using the other hand to lock the handle.
Page 37 Rinsing (sanitizing) the filter  Touch the NEXT screen button to start the initial rinsing process. The rinsing process will last approximately 2 minutes. Water (slightly darkened), will pour out of the dispenser into the water container. This water contains minute carbon particles embedded in the filter.
Page 38: Replacing The Co 2 Bottle
Replacing The CO Bottle (X1) An empty CO bottle Indication is displayed by a yellow circle on the Soda Water glass icon. The yellow circle will disappear only after a new CO bottle has been installed in the dispenser and the soda glass icon will be touched.
Page 39: The Technical Settings Screen
The Technical Settings Screen To access the technical settings screen touch the Technical Screen icon .on the SETTINGS display. The technical settings screen enables you to carry out routine maintenance of the dispenser. To prevent problems stemming from stone buildup, periodically clean and rinse the reservoirs and the internal system parts that come in touch with the water.
Page 40 Descaling The lime scale building up is a natural consequence of the use of the machine. About once every 6 months, it is required to descale the boiler and the heating element with descaling solution. In some special cases, if the tap water could be found “hard” (with a high content of calcium carbonate) it could be necessary to proceed with the descaling cycles more frequently, without the machine shows the warning screen.
Page 41 Pour a single dose of lime scale (100ml) into the reservoir and press NEXT. WARNING Never drink the Descaling solution or any products dispensed until the cycle has been carried out to the end. Never use vinegar as a descaler. Place a large container (3 lt) under the dispenser spout.
Page 42 After the filling process of the boiler, wait for few minutes to bring the water to boiling temperature. WARNING The machine will dispense very hot water. Press NEXT to continue the procedure. Please wait while machine is under descaling process. It will take few minutes.
Page 43 Pull the handle. Remove by-pass filter and insert standard filter and than press NEXT Only when the standard filter is inserted back in place, it will appear the screen : The descaling process is successfully finished. Dispensing screen (X1) Once the descaling process is finished, the dispenser will show the main dispensing screen Dispensing screen (X10)
Page 44 Periodic cleaning Once every few months or if the dispenser was not used during the preceding 72 hours, we recommend to rinse and sanitize the internal tanks and piping of the dispenser. Touch the Technical Screen icon in the Settings screen. Touch the cleaning icon on the Technical Screen to activate the dispenser's rinsing...
Page 45 The Serviceman's screen In the Technical Settings Screen, the serviceman will touch the technician's icon Only the serviceman is allowed to access this technical settings screen by using a personal user code. Cleaning the Dispenser's Exterior CAUTION Do not spray water or cleaning fluid on the dispenser to clean it. Disconnect the electric power cord.
Page 46: In Case Of A Problem
In Case of a Problem The problem Possible Cause Solution The screen is not lit The dispenser in not connected Plug the power cord into the walll to the electrical system socket The fuse is burned Replace the fuse (10 Amp) Wait for the renewal of the power Power shortage supply...
Page 47 Keep it protected from dust and dirt. Store above 2°C room temperature. WARNING The manufacturer will not be liable for any damage or fault caused to the Sodax X1-X10 dispenser as a result of any of the following incorrect use of the dispenser – not in accordance with the intended purposes, or not in accordance to the User Guide: ...
Page 48: Technical Specifications Sodax X1-X10 Dispenser
Weight 18 Kg. (*) Connect the Sodax X1-X10 dispenser to the electrical system only via a residual current circuit breaker (not higher than 30 milliamps) (**) Standard glass volume 200 ml. (***)Chlorine reduction and filtration level have been specified using a genuine Sodax filter cartridge consumables and thus represent a standard level.
Page 49: Machine Disposal
Machine disposal Disposal Do not throw away the machine with the normal household waste at the end of its life, but hand it in at an official collection point for recycling. By doing this, you help to preserve the environment. - The packing materials can be recycled.
