Mooer Macro Power 512 Owner's Manual

Professional Pedalboard Power Supply

PRECAUTIONS

* PLEASE READ CAREFULLY BEFORE PROCEEDING *
Please read the following set up instructions carefully to ensure
that the input power is correct and it is in accordance with the
requirements of your country before using the MACRO POWER S12.
Improper set up will result in severe damage to the device itself.
Ensure you have set the power selection switch to the AC voltage
which corresponds with that of your AC outlet (220V-240V / 110V-120V).
Connect the power cord provided to begin using MACRO POWER

MAIN FEATURES

Dual toroidal transformers and enhanced filtering provide clean,
quiet power
12 isolated and truly independent 9V DC outputs
2 x 500mA
4 x 300mA (one with selectable Voltage)
6 x 200mA
A total of 3400mA output
Convenient switch to change the input A/C voltage for use in
different countries

ACCESSORIES

6 x 460mm power cables
6 x 610mm power cables
1 x 200mm Polarity conversion cable (RED Connectors)
AC Power Cord
Velcro tape
Owner's Manual
* Disclaimer: Any specification's update won't be amended in this
manual.
