ViewSonic CDE3203 Quick Start Manual

Getting start
Main unit Power cable Stand
Plug types by country Screw: M4X10 x4, T4X12.5 x4
Connect to your Computer
Please find video output port on your PC. You can choose HDMI, DVI or D-SUB.
HDMI
HDMI
Step 1: Identify the connector on your PC. Step 2: Connect video signal with
appropriate connector cable.
Video Quality
HDMI
HDMI
HD Multimedia Interface
DVI
DVI
Step 1: Identify the connector on your PC. Step 2: Connect video signal with
appropriate connector cable.
Video Quality
DVI
DVI
Digital Video Input
D-SUB
D-SUB
Step 1: Identify the connector on your PC. Step 2: Connect video signal with
appropriate connector cable.
Video Quality
D-SUB
D-SUB
Required Cable Types for Connection
HDMI DVI-to-HDMI
Notes on Connection
• To enjoy an HD experience, please connect an HD source to this LCD display.
• When using a DVI-to-HDMI cable, please make sure to connect the DVI side first.
• Please contact ViewSonic Service team directly, if you have any questions on the Connection.
• Or call our service team: United States 1-800-688-6688 / Canada 1-866-463-4775
Remote Control with
Quick Start Guide
AAA batteriesx2
CDE3203
Quick Start Guide
HDMI
HDMI
Step 3: Connect audio signal with
appropriate connector cable.
DVI DVI PC AUDIO OUT
DVI DVI PC AUDIO IN
Step 3: Connect audio signal with
appropriate connector cable.
D-SUB D-SUB PC AUDIO OUT
PC AUDIO IN
VGA VGA
HD15 Mini-Pin Audio
UG CD disc
For Your Convenience
Write down your product serial number. _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
If you need any assistance, it will help you.
Please contact ViewSonic service team directly if you have questions on
the use of your LCD display.
Contact ViewSonic Service Team at:
http://www.ViewSonic.com
Or call our service team:
United States 1-800-688-6688
Canada 1-866-463-4775
Please Do Not Return this Product to the Store
For further information, please refer to the User Manual supplied with the LCD display.
Please keep this Quick Start Guide for your future reference.
LCD Display. The Door to High Definition
Step 1 : Register online at: http://www.ViewSonic.com/support
Step 2
: Check your accessory contents in packaging.
Step 3
: Install 2 AAA batteries (included in package) in your remote
control.
Enjoy FHD Experience:
Set up your ViewSonic LCD display by using proper connections to
an HD content source such as your HD cable or satellite box.
Connect your LCD display with other external devices
Power off your LCD display until you complete all the connections
Input Video Connector
HDMI
DVI
Component
AV
Connect your PC to your ViewSonic LCD Display
• For the D-Sub connection, you need to apply D-Sub cable and mini 3.5mm audio cable. • For the D-Sub connection, you need to apply D-Sub cable and mini 3.5mm audio cable.
• For the DVI connection, you must apply DVI or DVI-to-HDMI cable and additional audio cable. • For the DVI connection, you must apply DVI or DVI-to-HDMI cable and additional audio cable.
• Change the PC setting to display on LCD display. • Change the PC setting to display on LCD display.
• For detailed information, please refer to your User Manual. • For detailed information, please refer to your User Manual.
• Please contact ViewSonic Service Team if you had any problem on connection. • Please contact ViewSonic Service Team if you had any problem on connection.
CDE3203_QSG_ENG Rev.1a 12-22-15
ViewSonic
Full HD Professional LED Display
Quick Start Guide
Step 4 : Install your LCD display. If you want to hang the LCD
display on the wall, please refer the User Guide for
detailed instructions.
Screw: M4X10 x4
Audio Connector Supported Resolutions
No need for this input 1080p, 1080i, 720p, 480p, 480i, PC timing (Both HD and SD content)
1080p, 720p, 480p, PC timing (Both HD and SD content)
1080p, 1080i, 720p, 480p 480i (Both HD and SD content)
480i (SD content only)
Copyright © 2016 ViewSonic Corporation. All right reserved.
CDE3203
®
Screw: T4X12.5 x4
