ttaching the Satellite ntenna
Attach the Antenna
ttach the antenna
1.
in the down position.
Press and hold
2.
the button in at the top of the phone.
Push the antenna until it clicks
3.
into place and release the button.
Remove the ntenna
You may want to remove the satellite antenna to attach and auxiliary antenna.
Remove the antenna
1.
in the down position.
Press in the button
2.
at the top of the phone.
Remove
3.
the antenna.
CAUTION:
Care should be taken when removing and attaching the antenna. Incorrect
fitting or damage could result in failure to register with the network.
Iridium 9505A
Hire Fleet User Guide
Satellite Hire Australia Pty Ltd
Satellite Antenna
Lock Release
Button
Signal Strength
Indicator
Display and
Status Indicators
Message Key
Alphanumeric
Keypad
Charging
Jack
satellitehire.com.au
hire@satellitehire.com.au
1800 SATELLITE (1800 728 355)
Status
Indicator
Satellite Antenna
arpiece
Real-Time
Clock
Battery Charge
Indicator
Display
Scoll Bar
Headset Jack
Microphone
Advertisement
Summary of Contents for Satellite Hire Iridium 9505A
- Page 1 Iridium 9505A ttaching the Satellite ntenna Hire Fleet User Guide Attach the Antenna ttach the antenna 1. in the down position. Satellite Hire Australia Pty Ltd Press and hold 2. the button in at the top of the phone. Push the antenna until it clicks satellitehire.com.au 3. into place and release the button. hire@satellitehire.com.au 1800 SATELLITE (1800 728 355) Satellite Antenna Lock Release Status Button Indicator Satellite Antenna arpiece Signal Strength Real-Time Indicator Clock Remove the ...
- Page 3 Placing Calls Helpful Hints To place a call, the antenna must be fully extended and rotated upwards with a clear • Need clear view of sky, outdoors, away from buildings and tall structures. view of the sky, the phone must be on and registered with the Satellite. Rotate and fully extend antenna into a vertical position. • Wait until registration is complete (you will see registered and the ý 1. Enter the phone number using the digit keys. and indicators). If no registration To call a fixed line - enter area code and number. ( missing), press To call a mobile - enter mobile number. • To dial, enter area code and number, + OK. 2. Press .You will see “Calling” followed by the number you are dialling. If the or a mobile enter number + OK. call connects and is answered, “Connected” will appear on the screen for a few • Talk with antenna above your head and vertical to the ground. seconds, followed by “End Call?” If the call does not connect, you may see one of the following messages. Holding the Phone Message Description Rotate Antenna Make sure the antenna is fully extended and rotated upwards and has a clear view of the sky. Call ailed System The phone is unable to access the network. 1. Rotate the antenna 2. Extend the antenna 3. Make sure the antenna Busy Weak Signal Try again in a few minutes. to either the left or by pulling out on has a clear view of sky. right detent. The the end of it.
