Talius Habitat Screen
Installation Guide
TM
Habitat Screen Installation Guide
If nothing else, at least read this page
Talius has been producing retractable screens since 1998 and in that time we have found that most issues
experienced are related to the product installation. It is essential to follow the installation guidelines. We urge
installers to take the time now to read the instructions and avoid costly, time-consuming problems later. It is
only necessary to read through a small fraction of this booklet as it covers all types of Habitat Screen installations.
At the beginning of each section the booklet will point out if the section can be skipped.
Habitat Screens ship with the screen curtain inside the panel box. This is to facilitate simple installation and save
time. We hope that this installation guide is easy to use. Should you discover an error or an omission please
tell us about it. Parts and options change continually so we are updating all the time.
Should you require any support or have any questions, please call us from site: 800-665-5550
(M-F 8am to 4:30pm PST)
We thank you for putting your trust in us.
Sincerely,
Your Talius Customer Service Team
Version 2018.1, 1
©TALIUS

Advertisement

Table of Contents
loading

Summary of Contents for Talius Habitat Screen

  • Page 1 It is only necessary to read through a small fraction of this booklet as it covers all types of Habitat Screen installations. At the beginning of each section the booklet will point out if the section can be skipped.
  • Page 2 RECOMMENDED INSTALLATION TOOLS AND MATERIALS Each Habitat Screen installation requires a minimum of 2 installers. Not all installations are the same. While the following items will not be required on every installation, this is a list of minimum requirements that we recommend for the majority of Habitat Screen installations.
  • Page 3: Parts Overview

    Talius Habitat Screen Installation Guide PARTS OVERVIEW Version 2018.1, 3 ©TALIUS...
  • Page 4: Section One: Opening Criteria

    4’ or longer level should be used to confirm this. If the shaft is not level the Habitat Screen will experience tracking problems and the curtain may appear to have excessive wrinkles. Note that the shaft is not necessarily aligned perfectly with the panel box so it’s best to level the unit based upon the shaft.
  • Page 5 2.1a) Face of Wall Mount: Hold the unit against the opening and determine the future fit. It is important to ensure that there is an even plane on which to mount the Habitat Screen. Face of Wall mounted Habitat Screens come with 7/8”...
  • Page 6: Section Three: Preparation For Through Wall Operator Applications

    The prime concern will be to ensure that the habitat screen is level, plum and true. Many openings are not true and level so it may be necessary to fill any gaps with wood shims or alternative filler materials.
  • Page 7: Section Four: Pre-Drilling Guide Rails

    4.1a) Face of Wall Applications: The guide rails are the main supports that hold up a Habitat Screen unit and will later need to be fastened securely. When drilling through two layers of aluminum, the hole through the outer layer must be Ø8.5mm (Ø11/32") precisely for the screw caps, or Ø10mm (Ø3/8") for screw caps for...
  • Page 8: Section Five: Mounting Rails And Panel Box

    Talius Habitat Screen Installation Guide SECTION FIVE: MOUNTING RAILS AND PANEL BOX In this section the framework will be attached to the opening. Note for this section the panel box will need to be fitted into the rails when it’s lifted into place.
  • Page 9: Section Six: Installing The Operator

    Talius Habitat Screen Installation Guide SECTION SIX: INSTALLING THE OPERATOR In this section the operator will be installed. Refer only to the section that applies. 6.1a) Crank Rod Operator: If the operator runs through a wall, insert the universal with the connector through the hole in the wall and ensure that the square connector inserts into the matching slot inside the gear.
  • Page 10: Motor Operator

    If the panel box endplate is fitted with a metal retainer plate, slide the retainer plate away to allow for clear access to the motor. If the Habitat screen has been outfitted with a Standard Limit motor, tester cables are best used for adjusting the limits or stop points.
  • Page 11: Section Seven: Limit Setting

    Section 8 7.1a) Somfy RTS Motors: When you receive your Habitat Screen with a Somfy RTS motor the unit will come with a pre-program transmitter in user mode. To adjust the limits follow the simple steps below. If you have a multi-channel transmitter, select the channel corresponding to the unit that you are adjusting and follow these steps.
  • Page 12: Down Limit

    General: Electrical Habitat Screen units are operated by tubular motors housed inside the unit's shaft at one end. The motor can be located by looking for the wires leading to the Habitat Screen unit. Each motor has two internal limit switches. The function of the "upper" limit switch is to cut off power to the motor when the unit has reached the completely rolled-up position.
  • Page 13 * image of limit brackets 7.2) General Notes For All Motor Types: Run the Habitat Screen up and down at least twice. Since the curtain is made of fabric, the curtain may take a few operations to fully settle into place. As such, the limits may need to be readjusted again slightly.
  • Page 14: Section Eight: Securing The Panel Box

    This permits the Habitat Screen to track side-to-side and find its best operating position. Roll the Habitat Screen up and down a few times. This will allow the curtain and zippered edges to adjust in their tracking and achieve proper alignment and tension on the roll.
  • Page 15: Section Ten: Finishing

    9.3) Bottom Stops: For specific Habitat Screen applications, install a bottom stop into each guide rail. 9.3) Caulking: Caulking around the top of the panel box and guild rails will help to prevent water from penetrating behind the Habitat Screen and to ensure a clean finished appearance.
  • Page 16: Section 1: Screen Coming Out Of The Guide Rails

    K. Check the gap of the retention inserts with feeler gauges that can be purchased at any automotive parts supply store. The gap should be 0.035” to 0.040”. (or about 0.9mm to 1.0mm) NEED SUPPORT: If you are not able to resolve the performance issue, contact Talius’ Inside Sales team for support at 1-800-665-5550.
  • Page 17: Section 2: Screen Hanging Up In The Guide Rails

    Please note: Do not lubricate the retention system as it is not designed for this, nor should it ever need it. NEED SUPPORT: If you are not able to resolve the performance issue, contact Talius’ Inside Sales team for support at 1-800-665-5550.
