REMOS GX
Pilot Operating Handbook
Airplane Registration Number
Airplane Serial Number
REMOS Order No.
nXES
______________________
______________________
104178, dated December 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the REMOS GX nXES and is the answer not in the manual?

Questions and answers

Summary of Contents for Remos REMOS GX nXES

  • Page 1 REMOS GX nXES Pilot Operating Handbook Airplane Registration Number ______________________ Airplane Serial Number ______________________ REMOS Order No. 104178, dated December 2017...
  • Page 2 G3-8 MA FM 6200 – R03 Introduction Light Sport Aircraft REMOS GX The REMOS GX was manufactured in accordance with the Light Sport Aircraft airworthiness standards and does not conform to standard category airworthiness requirements. The standards to be used for certification are given by FAA and can be obtained from the FAA’s website.
  • Page 3 G3-8 MA FM 1210 Banner Towing G3-8 MA FM 1211 Continued Airworthiness G3-8 MA FM 1212 Abbreviated Checklists G3-8 MA FM 1213 This POH may only be used for aircraft SN429 or higher with REMOS notification NOT-014 NOTE implemented. Introduction...
  • Page 4 G3-8 MA FM 6200 – R03 Introduction Remarks and Alterations Please make a notation below if any changes have been made to this manual or to the plane. This manual is an important document for the pilot in command to ensure safe operation of the aircraft. Therefore it is recommended to keep this Operating Handbook updated with the newest information available.

  • Page 5: Table Of Contents

    G3-8 MA FM 5201 - R01 General Information Table of Contents sect. description page Introduction Certification Continued Airworthiness Quick Reference Technical Specifications Views Performance Engine Fuel 1.10 1.11 Propeller 1.12 ICAO Designator 1.13 Noise Certification General Information 1 - 1...

  • Page 6: Introduction

    Introduction This Operating Handbook is designed to help enable a safe and successful completion of each flight with the REMOS GX. It provides you with all necessary information for regular maintenance and operation of the aircraft. Therefore we recommend that the pilot keep this Operating Handbook updated with the newest information available.

  • Page 7: Quick Reference

    G3-8 MA FM 5201 - R01 General Information Quick Reference Type: Full composite carbon fiber aircraft with two seats. Design: High wing design with struts, front mounted engine propeller, traditional stabilizer concept, differential ailerons. Electrically operated flaps (0° to 40°), electric elevator trim, three-wheel landing gear with steerable nose wheel.

  • Page 8: Views

    G3-8 MA FM 5201 - R01 General Information Views Wingspan 9.32 m = 30.6 ft Overall Length 6.48 m = 21.3 ft General Information 1 - 4...

  • Page 9: Performance

    G3-8 MA FM 5201 - R01 General Information Performance This section shall give a summary of the performance of the REMOS GX. Detailed performance data is given in section 5 of this Pilot Operating Handbook. 115 kTAS @° 5.500 rpm...

  • Page 10: Fuel

    ROTAX service instruction SI-912- fuel qualities 016, preferably free of ethanol. Please refer to REMOS notification NOT-001 and ROTAX SI-912-016 for further information on suitable engine fluids (fuel, oil, cooling liquid, additives, etc). NOTE Have a frequent look on www.flyrotax.com...

  • Page 11: Propeller

    1.12 ICAO Designator ICAO Designator: (as per ICAO Doc. 8643) 1.13 Noise Certification According to noise requirements for Ultralight aircraft (LS-UL) dated August 1996, the REMOS GX is certified to a noise level of 60 dB (A). General Information 1 - 7...
  • Page 12 G3-8 MA FM 5201 - R01 General Information intentionally left blank General Information 1 - 8...
  • Page 13 G3-8 MA FM 5202 - R03 Operating Limitations Table of Contents sect. description page General Reference Airspeeds Airspeed Indicator Range and Markings Stalling Speeds at Maximum Takeoff Weight Flap Extended Speed Range Maneuvering Speed Never Exceed Speed Service Ceiling Load Factors 2.10 Approved Flight Maneuvers 2.11...

  • Page 14: General

    G3-8 MA FM 5202 - R03 Operating Limitations General This POH may only be used for aircraft SN429 or higher NOTE or with REMOS notification NOT-014 implemented. Reference Airspeeds speed description airspeed which shall never never exceed speed 135 kts...

  • Page 15: Airspeed Indicator Range And Markings

    G3-8 MA FM 5202 - R03 Operating Limitations Airspeed Indicator Range and Markings The following markings must be on the airspeed indicator at least. Additional markings are permissible, e.g. for recommended approach speed or for maneuvering airspeed. marking range description 42…78 kts white arc airspeed range for flaps extended...

  • Page 16: Flap Extended Speed Range

    G3-8 MA FM 5202 - R03 Operating Limitations Flap Extended Speed Range Flaps may be operated and the aircraft may be flown at airspeeds higher than V as long as flap deflection is limited. Following restrictions apply as a function of airspeed: ...

  • Page 17: Never Exceed Speed

    G3-8 MA FM 5202 - R03 Operating Limitations Never Exceed Speed Due do the reduced density of air at altitude, true airspeed is higher than calibrated or indicated airspeed. Therefore, V is limited to 135 kts true airspeed in order to prevent flutter. With increasing altitude V is limited to lower values than indicated by redline according to the following table.

  • Page 18: Approved Flight Maneuvers

    A general wind limitation is not defined for the REMOS GX. 2.13 Maximum Parachute Deploy Airspeed maximum parachute deploy airspeed...

  • Page 19: Engine

    0,15 bar = 2.2 psi max. 0,50 bar = 7.3 psi Please refer to REMOS notification NOT-001 and ROTAX SI-912-016 for further information on suitable engine fluids (fuel, oil, cooling liquid, additives, etc). NOTE Have a frequent look on www.flyrotax.com...

  • Page 20: Oil

    50 °C 120 °F max. 130 °C 266 °F Please refer to REMOS notification NOT-001 and ROTAX SI-912-016 for further information on suitable engine fluids (fuel, oil, cooling liquid, additives, etc). NOTE Have a frequent look on www.flyrotax.com and on www.remos.com...

  • Page 21: Weight And Balance

    126 lb max. fuel 2.20 Crew The REMOS GX is certified to be operated with a minimum of 1 occupant (the pilot in command) and a maximum of 2 occupants. If not otherwise defined by regulations or by the owner/operator, the pilot in command is seated on the left.

  • Page 22: Flight Conditions And Minimum Equipment List

    G3-8 MA FM 5202 - R03 Operating Limitations 2.21 Flight Conditions and Minimum Equipment List operation minimum equipment Day-VFR as per D-VFR Minimum Equipment List Night-VFR as per N-VFR Minimum Equipment List IFR in IMC not approved IFR in VMC as per IFR/VMC Minimum Equipment List Aerobatics not approved...
  • Page 23 G3-8 MA FM 5202 - R03 Operating Limitations N-VFR Minimum equipment list • as per D-VFR minimum equipment list, plus • ADAHRS module DYNON SV-ADAHRS-200 in order to drive the integrated artificial horizon of the SkyView system) • instrument panel lighting •...
  • Page 24 G3-8 MA FM 5202 - R03 Operating Limitations 2.22 Placards and Markings Inside Cabin The placards and markings feature the following color codes. Type Inside Information white lettering on a black background - white framed Safety white lettering on a black background - red framed Warning white lettering on a red background - white framed The following list does not define the layout but the content and intent...
  • Page 25 G3-8 MA FM 5202 - R03 Operating Limitations The following information placards are installed inside the cabin. Installation of these placards is mandatory placards location left cockpit not with oil thermostat installed center console actual callsign of aircraft switchboard switchboard switchboard switchboard right cockpit...
  • Page 26 G3-8 MA FM 5202 - R03 Operating Limitations placards location center console center console on knob oil temp placard not with oil thermostat installed Operating Limitations 2 - 14...
  • Page 27 G3-8 MA FM 5202 - R03 Operating Limitations The following safety placards are installed inside the cabin. Installation of these placards is mandatory placard location left cockpit above left cockpit screen left cockpit above left cockpit screen installed in combination with towing clutch only center stack on top of center stack...
  • Page 28 G3-8 MA FM 5202 - R03 Operating Limitations placard location aileron pushrod cut out baggage compartment when recovery system is installed Operating Limitations 2 - 16...

  • Page 29: Operating Limitations

    G3-8 MA FM 5202 - R03 Operating Limitations The following warning placards are installed inside the cabin. Installation of these placards is mandatory placards location center console door door Operating Limitations 2 - 17...
  • Page 30 G3-8 MA FM 5202 - R03 Operating Limitations The following information placards and markings are found inside the cabin. Attaching these placards is not mandatory; these placards provide additional information to the pilot. placards location right cockpit baggage compartment metric units acceptable switchboard switchboard switchboard...
  • Page 31 G3-8 MA FM 5202 - R03 Operating Limitations 2.23 Placards and Markings Outside Cabin The placards and markings feature the following color codes. Type Outside Information black lettering on a white background - black framed Safety red lettering on a white background - red framed Warning red lettering on a white background - red framed The following list does not define the layout but the content and intent...
  • Page 32 G3-8 MA FM 5202 - R03 Operating Limitations The following information placards are installed outside the cabin. Installation of these placards is mandatory placards location fuel tank filler cap metric units acceptable Operating Limitations 2 - 20...
  • Page 33 G3-8 MA FM 5202 - R03 Operating Limitations The following safety placards are installed outside the cabin. Installation of these placards is mandatory placards location center of elevator next to the opening for aileron pushrod, covered by wing if not folded center of fixed surface of elevator, covered if elevator...
  • Page 34 G3-8 MA FM 5202 - R03 Operating Limitations The following information placards and markings are found outside the cabin. Attaching these placards is not mandatory; these placards provide additional information to the pilot. placards location wheel fairings placard set with one unit only acceptable static ports The following safety placards and markings are found outside the...
  • Page 35 G3-8 MA FM 1203 - R07 Emergency Procedures Table of Content sect. description page Definitions Jettison of Doors Spin Recovery Recovery System Emergency Descent Carburetor Icing Inadvertent Icing Encounter Overvoltage Generator Failure 3.10 Voltage Drop 3.11 Loss of Altimeter 3.12 Loss of Airspeed Indicator 3.13 Loss of Elevator Control...
  • Page 36 With the help of briefings, the pilot and passenger should recapitulate those procedures. This POH may only be used for aircraft SN429 or higher NOTE or with REMOS notification NOT-014 implemented. Emergency Procedures 3 - 2...
  • Page 37 G3-8 MA FM 1203 - R07 Emergency Procedures Jettison of Doors Procedure 1. door lock OPEN 2. hinge pin PULL 3. door JETTISON Spin Recovery Procedure 1. engine IDLE 2. aileron NEUTRAL 3. rudder OPPOSITE SPIN DIRECTION 4. elevator PUSH 5.
  • Page 38 G3-8 MA FM 1203 - R07 Emergency Procedures Emergency Descent Procedure 1. engine IDLE 2. flaps 3. carburetor heat PULL 4. electric fuel pump 5. airspeed in rough air 107 kIAS airspeed in calm air 135 kIAS Carburetor Icing Procedure 1.
  • Page 39 G3-8 MA FM 1203 - R07 Emergency Procedures Generator Failure Procedure 1. alternator failure IDENTIFY (red alarm light) 2. non essential systems 3. continue flight and land on appropriate airfield to determine the reason for the alternator failure During day VFR Operations, nonessential systems are all systems except for the radio and intercom.
  • Page 40 G3-8 MA FM 1203 - R07 Emergency Procedures 3.11 Loss of Altimeter Procedure for aircraft with more than one altimeter installed 1. AVIATE – NAVIGATE – COMMUNICATE 2. altimeter USE ALTERNATE ALTIMETER 3. in case of failure of all altimeters installed continue with procedure below aircraft with just one altimeter and within airspace requiring clearance 1.
  • Page 41 G3-8 MA FM 1203 - R07 Emergency Procedures 3.12 Loss of Airspeed Indicator Procedure for aircraft with more than one airspeed indicator installed 1. AVIATE – NAVIGATE – COMMUNICATE 2. airspeed indicator USE ALTERNATE ASI 3. in case of failure of all airspeed indicators installed continue with procedure below for aircraft with one airspeed indicator installed or total failure of ASI 4.200…4.600 rpm...
  • Page 42 G3-8 MA FM 1203 - R07 Emergency Procedures 3.13 Loss of Elevator Control Procedure aircraft equipped with recovery system 1. AVIATE – NAVIGATE – COMMUNICATE 2. declare emergency MAYDAY MAYDAY MAYDAY 3. recovery system DEPLOY aircraft without recovery system 1. AVIATE – NAVIGATE – COMMUNICATE 2.
  • Page 43 G3-8 MA FM 1203 - R07 Emergency Procedures 3.14 Loss of Aileron Control Procedure aircraft equipped with recovery system 1. AVIATE – NAVIGATE – COMMUNICATE 2. declare emergency MAYDAY MAYDAY MAYDAY 3. recovery system DEPLOY aircraft without recovery system 1. AVIATE – NAVIGATE – COMMUNICATE 2.
  • Page 44 G3-8 MA FM 1203 - R07 Emergency Procedures 3.15 Loss of Rudder Control Procedure aircraft equipped with recovery system 1. AVIATE – NAVIGATE – COMMUNICATE 2. declare emergency MAYDAY MAYDAY MAYDAY 3. recovery system DEPLOY aircraft without recovery system 1. AVIATE – NAVIGATE – COMMUNICATE 2.
  • Page 45 G3-8 MA FM 1203 - R07 Emergency Procedures 3.16 Loss of Trim System Procedure pitch down trim runaway or stuck trim with lot of trim down 1. AVIATE – NAVIGATE – COMMUNICATE 2. expect nose down attitude 3. keep nose up with manual stick input 4.
  • Page 46 G3-8 MA FM 1203 - R07 Emergency Procedures 3.17 Loss of Flaps Control System Procedure flaps stuck in deflected position or flaps down runaway 1. AVIATE – NAVIGATE – COMMUNICATE 2. max. flap speed = 78 kIAS 3. approach airspeed = 60 kIAS 4.
  • Page 47 G3-8 MA FM 1203 - R07 Emergency Procedures 3.18 Loss of Oil Pressure Procedure oil temperature not stable (constantly and rapidly rising) smell of oil, oil fumes, oil on windscreen 5. AVIATE – NAVIGATE – COMMUNICATE 6. PERFORM PRECAUTIONARY LANDING oil temperature stable (constant oil temperature) no obvious oil leakage, engine running smooth 1.
  • Page 48 G3-8 MA FM 1203 - R07 Emergency Procedures 3.19 High Oil Pressure Procedure oil temperature not stable (constantly and rapidly rising) smell of oil, oil fumes, oil on windscreen 1. AVIATE – NAVIGATE – COMMUNICATE 2. PERFORM PRECAUTIONARY LANDING oil temperature stable (constant oil temperature) no obvious oil leakage, engine running smooth 1.
  • Page 49 G3-8 MA FM 1203 - R07 Emergency Procedures 3.20 High Cylinder Head Temperature Procedure 1. AVIATE – NAVIGATE – COMMUNICATE 2. power setting REDUCE TO MIN. POSSIBLE 3. continue flight and land on appropriate airfield to determine the reason of the high cylinder head temperature 4.
  • Page 50 G3-8 MA FM 1203 - R07 Emergency Procedures 3.21 Engine Stoppage during Take-Off Procedure during take-off run (aborted take-off) 1. engine speed IDLE 2. brakes AS REQUIRED 3. engine during climb out (altitude below 500ft) 1. AVIATE – NAVIGATE – COMMUNICATE 2.
  • Page 51 G3-8 MA FM 1203 - R07 Emergency Procedures 3.22 Engine Stoppage in Flight Procedure case 1: altitude not enough for engine re-start 1. AVIATE – NAVIGATE – COMMUNICATE 2. landing site IDENTIFY 3. engine 4. fuel valve CLOSE 5. declare emergency MAYDAY MAYDAY MAYDAY 6.
  • Page 52 G3-8 MA FM 1203 - R07 Emergency Procedures 3.24 Engine on Fire During Take-Off Procedure during take-off run (aborted take-off) 1. engine speed IDLE 2. brakes FULL and SET 3. fuel valve CLOSE 4. carburetor heat PULL 5. electric fuel pump 6.
  • Page 53 G3-8 MA FM 1203 - R07 Emergency Procedures 3.25 Engine on Fire in Flight Procedure 1. AVIATE – NAVIGATE – COMMUNICATE 2. landing site IDENTIFY 3. fuel valve CLOSE 4. carburetor heat PULL 5. electric fuel pump 6. power setting FULL until ENGINE STOPS 7.
  • Page 54 G3-8 MA FM 1203 - R07 Emergency Procedures 3.26 Precautionary Landing Procedure 1. AVIATE – NAVIGATE – COMMUNICATE 2. landing site IDENTIFY 3. direction of wind IDENTIFY 4. landing direction INTO THE WIND or UPHILL 5. landing site inspection PERFORM LOW APPROACH 6.
  • Page 55 G3-8 MA FM 1203 - R07 Emergency Procedures 3.27 Emergency Landing on Land Procedure 1. AVIATE – NAVIGATE – COMMUNICATE 2. landing site IDENTIFY 3. direction of wind IDENTIFY 4. approach airspeed = 60 kIAS 5. max. flap speed = 78 kIAS 6.
  • Page 56 G3-8 MA FM 1203 - R07 Emergency Procedures 3.28 Emergency Landing on Water Procedure 1. AVIATE – NAVIGATE – COMMUNICATE 2. direction of wind IDENTIFY 3. approach airspeed = 60 kIAS 4. max. flap speed = 78 kIAS 5. flaps DOWN 6.
  • Page 57 G3-8 MA FM 1204 - R07 Normal Procedures Table of Content sect. description page Definitions Fuel Draining Preflight Check Before Start-Up Engine Start After Start-Up Engine Run Up Taxi Departure 4.10 Take-Off 4-10 4.11 Best Angle of Climb Speed (V 4-13 4.12 Best Rate of Climb Speed (V...
  • Page 58 With the help of briefings, the pilot and passenger should recapitulate those procedures. This POH may only be used for aircraft SN429 or higher NOTE or with REMOS notification NOT-014 implemented. Normal Procedures 4 - 2...
  • Page 59 When draining the aircraft take care that no fuel contaminates the environment. Dispose of drained or dumped fuel in an environmental correct manner. For further information about fuel containing ethanol please refer to the REMOS Notification NOT-001-ethanol-fuel. Normal Procedures 4 - 3...
  • Page 60 G3-8 MA FM 1204 - R07 Normal Procedures Preflight Check Checklist Checks outside the aircraft fuel system drained before moving the aircraft at all engine oil level (between min. and max. markings) level of engine coolant (between min. and max. markings) cowling is closed and properly secured propeller has no damage or wear nose gear and wheel/tire have no damage or wear, air pressure is...
  • Page 61 G3-8 MA FM 1204 - R07 Normal Procedures 26. fuselage has no damage right main gear and wheel/tire have no damage or wear, air pressure correct and suspension is free 28. lower wing strut attachment is secured 29. flap, linkage and hinges have no damage, rubber stops (flutter damper) on outer hinges are in place 30.
  • Page 62 G3-8 MA FM 1204 - R07 Normal Procedures Checks inside the aircraft aileron quick-fasteners are securely locked enough fuel on board for the flight both seats are properly secured in intended position both doors can be locked check proper functioning of the flap drive and gauge Insecurely connected, improper operation of control surfaces or insecurely locked fasteners will lead to loss of control of the aircraft!! Normal Procedures 4 - 6...
  • Page 63 G3-8 MA FM 1204 - R07 Normal Procedures Before Start-Up Checkliste 1. doors LOCKED 2. safety belts FASTENED 3. parking brake 4. recovery system ARMED 5. fuel valve OPEN Engine Start Procedure cold engine 1. master switch 2. anti-collision-light (ACL) 3.
  • Page 64 G3-8 MA FM 1204 - R07 Normal Procedures After Start-Up Procedure 1. engine has started STARTER DISENGAGE 2. choke 3. oil pressure 4. position-lights 5. avionics switch 6. intercom 7. radios ON and FREQUENCY SET 8. transponder AS REQUIRED 9. electric fuel pump 10.
  • Page 65 G3-8 MA FM 1204 - R07 Normal Procedures Taxi Procedure 1. landing light RECOMMENDED 2. parking brake RELEASE 3. engine speed AS REQUIRED 4. control on ground VIA PEDALS 5. min. turn radius ca. 20 ft = 7 m 6. braking AS REQUIRED 7.
  • Page 66 G3-8 MA FM 1204 - R07 Normal Procedures 4.10 Take-Off Procedure standard take-off 1. oil cooler flap AS REQUIRED 2. carburetor heat 3. electric fuel pump 4. flaps 5. elevator trim 2/3 UP 6. rudder and aileron NEUTRAL 7. engine power FULL POWER 8.
  • Page 67 G3-8 MA FM 1204 - R07 Normal Procedures short field take-off 1. oil cooler flap AS REQUIRED 2. carburetor heat 3. electric fuel pump 4. brakes 5. flaps 15 deg 6. elevator trim 2/3 UP 7. rudder and aileron NEUTRAL 8.
  • Page 68 G3-8 MA FM 1204 - R07 Normal Procedures soft field take-off 1. oil cooler flap AS REQUIRED 2. carburetor heat 3. electric fuel pump 4. brakes 5. flaps 15 deg 6. elevator trim 2/3 UP 7. rudder and aileron NEUTRAL 8.
  • Page 69 G3-8 MA FM 1204 - R07 Normal Procedures 4.11 Best Angle of Climb Speed (V Checklist 1. flaps 15deg or CLEAN 2. electric fuel pump 3. steepest climb = 50 kIAS 4. engine power FULL POWER 5. carburetor heat 6. oil cooler flap AS REQUIRED 7.
  • Page 70 G3-8 MA FM 1204 - R07 Normal Procedures 4.13 Cruise Checklist 1. flaps CLEAN 2. landing light ON (recommended) 3. engine speed AS REQUIRED 4. maneuvering speed = 88 kIAS 5. normal operating speed = 107 kIAS 6. never exceed speed = 135 kIAS 7.
  • Page 71 G3-8 MA FM 1204 - R07 Normal Procedures 4.14 Flying in Rain Checklist 1. electric fuel pump 2. carburetor heat 3. engine speed AS REQUIRED 4. oil cooler flap AS REQUIRED 5. coolant or CHT temp max. 135°C = 275°F max.
  • Page 72 G3-8 MA FM 1204 - R07 Normal Procedures 4.15 Flying Without Doors Procedure 1. door lock OPEN 2. gas spring on door DETACH 3. hinge pin PULL 4. door TAKE OUT CAREFULLY is reduced to 100 kIAS when flying without doors. NOTE Flying without doors leads to high wind velocities inside NOTE...
  • Page 73 G3-8 MA FM 1204 - R07 Normal Procedures 4.16 Recovery from Stall Procedure 1. stick back pressure RELEASE 2. rudder OPPOSITE to BANK 3. aileron NEUTRAL 4. engine power AS REQUIRED 4.17 Descent Checklist 1. flaps CLEAN 2. engine speed AS REQUIRED 3.
  • Page 74 G3-8 MA FM 1204 - R07 Normal Procedures 4.18 Approach Checklist 1. wind, weather, visibility 2. ATIS CHECKED 3. runway CORRECT DIRECTION 4. traffic pattern ALTITUDE and ROUTING 5. radios ON and FREQUENCY SET 6. transponder AS REQUIRED 7. carburetor heat AS REQUIRED 8.
  • Page 75 G3-8 MA FM 1204 - R07 Normal Procedures 4.19 Landing Procedure 1. full flaps airspeed = 78 kIAS 2. approach airspeed = 60 kIAS 3. flaps DOWN 4. target airspeed AS RECOMMENDED 5. engine power AS REQUIRED 6. elevator trim AS REQUIRED 7.
  • Page 76 G3-8 MA FM 1204 - R07 Normal Procedures advise In landing configuration, the airplane is very draggy and the propeller provides additional braking. Therefore, airspeed bleeds off quickly during flare. It is easy to misjudge altitude during flare. When flare is initiated too high and airspeed bleeds away the airplane may stall or bounce.
  • Page 77 G3-8 MA FM 1204 - R07 Normal Procedures 4.20 Balked Landing Procedure 1. engine power FULL POWER 2. carburetor heat 3. initial climb 50 kIAS 4. flaps retract SAFE ALTITUDE 5. steepest climb 50 kIAS 6. best climb 60 kIAS 7.
  • Page 78 G3-8 MA FM 1204 - R07 Normal Procedures 4.22 Shutdown Checklist 1. avionics switch 2. landing light 3. position lights 4. engine 5. ACL 6. cockpit lights 7. master switch 8. recovery system SECURED 9. parking brake It is permissible to switch avionics (GPS, radio, transponder, intercom) together with the avionics switch NOTE rather than separately.
  • Page 79 G3-8 MA FM 5205 - R01 Performance Table of Contents sect. description page General Summary of Flight Performances ISA Atmosphere Take-Off Distances Landing Distances Cruise Speed, RPM, Fuel Consumption, Range 5-10 Rate of Climb 5-11 Low Airspeed and Stall 5-12 Safe Glide Ratio 5-13 Performance 5 - 1...
  • Page 80 5% on any of the following criteria: climb, cruise, range This POH may only be used for aircraft SN429 or higher or with NOTE REMOS notification NOT-014 implemented. Summary of Flight Performances (stallspeed flaps 40°) kIAS (stallspeed flaps 0°)
  • Page 81 G3-8 MA FM 5205 - R01 Performance ISA Atmosphere All flight performance data are given for ISA standard atmosphere at sea level and standard temperature. To determine temperature in relation to ISA conditions please refer to the following chart: ISA std. Temperature 15000 14000 13000...
  • Page 82 G3-8 MA FM 5205 - R01 Performance Take-Off Distances For take-off with max. take-off weight on an even, dry, paved runway with ISA conditions on sea level, dry aircraft and wind calm the following take-off distances apply: take-off flaps 0° 234 m take-off roll distance 770 ft...
  • Page 83 G3-8 MA FM 5205 - R01 Performance Performance data apply under ISA conditions on an even, dry, hard runway surface. Various circumstances have an effect on take-off performance. According to CAA-circular AIC 127-2006, it is recommended to use following add-ons on roll- and air distances: add-ons on take-off roll distance for dry grass + 20%...
  • Page 84 G3-8 MA FM 5205 - R01 Performance example calculation: Take-off with a REMOS GX equipped with Neuform propeller in 2.000ft at 35°C from wet grass runway, 5kt tailwind, wet wing, take- off with flaps 0°. Standard wheels are mounted with wheel fairings.
  • Page 85 G3-8 MA FM 5205 - R01 Performance Landing Distances Landing is to be done with full flaps (40 deg). After touchdown, brake to the max for shortest landing distance, but do not block the wheels. For landing with max. take-off weight on an even, dry, paved runway with ISA conditions on sea level, dry aircraft and wind calm the following landing distances apply: landing...
  • Page 86 G3-8 MA FM 5205 - R01 Performance Performance data apply under ISA conditions on an even, dry, hard runway surface. Various circumstances have an effect on take-off and landing performance. According to CAA-circular AIC 127-2006, it is recommended to use following add-ons on roll- and air distances: add-ons on landing roll distance for dry grass + 15%...
  • Page 87 G3-8 MA FM 5205 - R01 Performance example calculation: Landing on soft surface with 2.000ft field elevation at 22°C, 5kt tailwind, wet wing and 2% downhill slope 1. temperature acc. to ISA diagram 12°C real temperature 22°C temperature above ISA: 10°C add-on acc.
  • Page 88 G3-8 MA FM 5205 - R01 Performance Cruise Speed, RPM, Fuel Consumption, Range Rotax 912 UL-S, 100 hp engine, Sensenich or Neuform propeller engine speed fuel flow true airspeed endurance range [ rpm ] [ gph ] [ ltr/h ] [ kTAS ] [ h ] [ nm ]...
  • Page 89 G3-8 MA FM 5205 - R01 Performance Rate of Climb Propeller Sensenich or Neuform best angle of climb kIAS airspeed V best rate of climb kIAS airspeed V best rate of climb ft/min at MSL Climb is flown with flaps retracted, see section 4 NOTE Expect a performance loss of about 5% when flying NOTE...
  • Page 90 G3-8 MA FM 5205 - R01 Performance Low Airspeed and Stall If the center of gravity is within the permissible range, the aircraft will be fully controllable until reaching the stall speed. As the aircraft approaches the stall speed, this will be indicated by slight aerodynamic buffeting.
  • Page 91 G3-8 MA FM 5205 - R01 Performance Safe Glide Ratio Airspeed for best glide is 60kIAS. Safe glide ratio of the airplane with wind milling propeller is approximately 1:11. This will result in following glide distances: airspeed for best glide [ kIAS ] glide ratio [ -- ]...
  • Page 92 G3-8 MA FM 5205 - R01 Performance intentionally left blank Performance 5 - 14...
  • Page 93 G3-8 MA FM 1206 - R06 Weight-and-Balance-Information Table of Contents sect. description page Center of Gravity Range and Determination CG-Calculation Calculation Example Aircraft Specific Weights Weight and Balance Information 6 - 1...
  • Page 94 G3-8 MA FM 1206 - R06 Weight-and-Balance-Information General This section provides information how to determine the inflight center of gravity. Prior to each take-off, the pilot in command shall ensure that the center of gravity is within its permissible envelope. For a correct determination of the inflight center of gravity the pilot needs following information: •...
  • Page 95 G3-8 MA FM 1206 - R06 Weight-and-Balance-Information Station Definitions seats fuel baggage item station seats 210 mm 8.3 in baggage 950 mm 37.4 in fuel 960 mm 37.8 in empty/inflight CG variable Procedure for determination of empty CG is given in the maintenance handbook.
  • Page 96 G3-8 MA FM 1206 - R06 Weight-and-Balance-Information Aircraft Weighing Procedure To determine the aircraft empty weight and CG, put the aircraft on 3 weighing scales, positioned on a level surface. Before weighing, a level wing main chord has to be established (use pads between main wheels and scale beneath).
  • Page 97 G3-8 MA FM 1206 - R06 Weight-and-Balance-Information Change of Equipment After change of equipment with known weight and CG of the added or removed equipment the new empty weight and CG of the aircraft can also be calculated instead of being determined by weighing as follows: old empty weight new empty weight...
  • Page 98 G3-8 MA FM 1206 - R06 Weight-and-Balance-Information Operating Weights and Loading The CG range for any given airborne weight, measured from reference, must be within the permissible limits of 9.6in to 16.3in. minimum airborne weight not limited maximum take-off weight 600 kg 1.320 lb front limit of CG...
  • Page 99 G3-8 MA FM 1206 - R06 Weight-and-Balance-Information Center of Gravity Range and Determination The following procedure must be used to calculate the inflight CG. 1. moment calculation moment weight x station weight station moment empty weight ____ ____ ____ occupants ____ 210 mm = 8.3 in ____...
  • Page 100 G3-8 MA FM 1206 - R06 Weight-and-Balance-Information Calculation Example weight station moment 305 kg 318 mm 96,990 kg mm empty weight 670 lb 12.5 in 8,375 lb-in 70 kg 215 mm 15,050 kg mm occupants 175 lb 8.3 in 1,453 lb-in 10 kg 950 mm 9,500 kg mm...
  • Page 101 G3-8 MA FM 1206 - R06 Weight-and-Balance-Information Aircraft Specific Weights Below are noted the aircraft specific data. Pilots must use this information to ensure a correct weight and balance calculation prior to every flight. This is essential for safe flight. For detailed information of the weight and balance data and the equipment installed on the aircraft refer to the individual aircraft weight and balance report, which includes the equipment list.
  • Page 102 G3-8 MA FM 1206 - R06 Weight-and-Balance-Information intentionally left blank Weight and Balance Information 6 - 10...
  • Page 103 G3-8 MA FM 5207 – R03 Airplane and Systems Description Table of Contents sect. description pages General Airframe Control System Cockpit Overview 7-13 DYNON SkyView 7-14 COM and NAV/COM 7-19 Intercom and Audio Panel 7-25 GPS Equipment 7-29 Transponder 7-33 7.10 Autopilot 7-35...
  • Page 104 G3-8 MA FM 5207 – R03 Airplane and Systems Description sect. description pages 7.21 Engine 7-54 7.22 Propeller 7-55 7.23 Fuel System 7-55 7.24 Braking System 7-59 7.25 Special Equipment and Customizing 7-60 Systeme 7 - 2...
  • Page 105 G3-8 MA FM 5207 – R03 Airplane and Systems Description General This section of the POH shall give a brief introduction into the systems installed in the REMOS GX. For further information, maintenance and repair instructions see maintenance manual, latest revision. Airframe Type: Full composite carbon fiber aircraft with two seats.
  • Page 106 G3-8 MA FM 5207 – R03 Airplane and Systems Description assembly of the wing The wing consists of four main parts: wingbox, flap, aileron and wingtip. The wingtip is bolted to the wingbox, aileron and flap are hinged to allow control movements. The wing is completed by the cover glass of the landing light and the main wingbolt which attaches the wing to the fuselage.
  • Page 107 G3-8 MA FM 5207 – R03 Airplane and Systems Description structure of the wing The wingbox is built up by the upper and lower wing skin consisting of CFRP sandwich (foam). Loads are transferred into the main and rear wing spar. The structure is completed by the landing light bay and ribs reinforcing hinge areas, closing the wing to the wingtip and the fuselage.
  • Page 108 G3-8 MA FM 5207 – R03 Airplane and Systems Description structure of the fuselage The skins of the fuselage are built of a monolithic layup of glass, carbon and Kevlar, reinforced by carbon tapes. Sandwich material (foam) is found in the fixed surface of the vertical tail only, which is an integral part of the fuselage.
  • Page 109 The wing strut is attached towards the wing and fuselage by a high tensile bolt, which is a genuine REMOS part. The wing strut can pivot about its axis some degree in order to allow the wing to be folded.
  • Page 110 G3-8 MA FM 5207 – R03 Airplane and Systems Description installation of horizontal tail The horizontal tail is made from GFRP. It is built up similar as the wing structure, consisting of ribs and spars. The elevator includes a trim tab, which is operated electrically. The trim tab does not have a dedicated hinge, but uses the elastic flap technology;...
  • Page 111 G3-8 MA FM 5207 – R03 Airplane and Systems Description Control System The control system is made of aluminium pushrods and crank bells for the elevator and aileron controls. The rudder is operated by steel cables. The trim system is an electrically driven trim tab on the elevator;...
  • Page 112 G3-8 MA FM 5207 – R03 Airplane and Systems Description elevator control system The control sticks are installed to a pivoting connection element (stick bridge). Thereby a push/pull input stick is transferred from the control stick through a bell crank and a push-pull tube towards the elevator. An electrical operated elevator trim tab is installed on the elevator.
  • Page 113 G3-8 MA FM 5207 – R03 Airplane and Systems Description aileron control system Both control sticks are linked together by a control rod system to ensure synchronous movement. The linkage is located beneath two fiberglass-panels on the floor of the cabin right in front of the seats. A translator connects the control stick linkage to the aileron linkage, which uses several bell cranks to establish the connection to the control surfaces.
  • Page 114 G3-8 MA FM 5207 – R03 Airplane and Systems Description flying with only one control stick installed Under certain conditions it might be favorable to have only one control stick installed. It is permissible to take out the control stick on the passenger side.
  • Page 115 Airplane and Systems Description Cockpit Overview general The REMOS GX is available with several avionic suites. Standard equipment is one DYNON D600 SkyView SE with 7” screen size and a PS Engineering PAR200A radio with integrated intercom. Optional equipment is a D700 or HDX800 instead of the D600 screen as well as a second one on the right side of the cockpit.
  • Page 116 G3-8 MA FM 5207 – R03 Airplane and Systems Description DYNON SkyView versions The DYNON SkyView Family is available in three versions: funktionality D600 D700 HDX800 ● HD screen ● touch screen ● ● ● primary flight instrumentation „six pack“ instrumentation ●...
  • Page 117 G3-8 MA FM 5207 – R03 Airplane and Systems Description screen of DYNON D600 and D700 Figures show elements. Display may vary in flight Systeme 7 - 15...
  • Page 118 G3-8 MA FM 5207 – R03 Airplane and Systems Description screen of DYNON HDX800 Figure shows elements. Display may vary in flight primary instrumentation The primary flight instrumentation and engine indication are realized by the DYNON SkyView glass cockpit system. This is an integrated system, it includes the “Electronic Flight information Display”...
  • Page 119 The offered functionality of the DYNON SkyView is more than offered and used in the REMOS GX. Therefore, it is possible that the DYNON manual references to functionalities that are not implemented into the REMOS GX.
  • Page 120 G3-8 MA FM 5207 – R03 Airplane and Systems Description color code In aviation it is common to have the HSI pointer displayed green when a VOR or ILS is selected as navigation source. The pointer is magenta when a GPS is selected as navigation source. joystick Push, tilt and rotate to select functionality and adjust values, On HDX800, the joystick needs...
  • Page 121 G3-8 MA FM 5207 – R03 Airplane and Systems Description COM and NAV/COM PS-Engineering PAR200A The PS-Engineering PAR200A is a VHF radio with 8.33kHz spacing with integrated intercom. It can manage another radio or NAV/COM (no MKR functionality). on/off, volume The PAR200A is switched on and off by pushing the VOL knob.
  • Page 122 G3-8 MA FM 5207 – R03 Airplane and Systems Description TRIG TY96/TY96A and TY97/TY97A The TRIG TY-series are VHF COM transceivers with 8.33kHz or 25kHz (A-suffix) frequency channel spacing. It incorporates a number of functions that save time and effort. The database technology allows to store and recall commonly used or recently used frequencies by an assigned name.
  • Page 123 G3-8 MA FM 5207 – R03 Airplane and Systems Description GARMIN GTR225A The GARMIN GTR225 or GTR225A is a VHF COM transceiver with 8.33kHz frequency channel spacing. It incorporates a number of functions that save time and effort. Provide the GTR225 with an airport identifier and it will automatically find its frequency (and vice versa) thanks to a built-in, updateable database.
  • Page 124 G3-8 MA FM 5207 – R03 Airplane and Systems Description GARMIN GNC255/A The GARMIN GNC255 or GNC255A is a VHF COM transceiver with 8.33kHz frequency channel spacing and a 200-channel VOR/LOC/GS NAV receiver in one combined housing. The GNC255A also incorporates workload-reducing functions such as automatic decoding of the Morse code station identifier for VOR/LOC/ILS, most-used frequency storage in unit memory, built-in course deviation indicator...
  • Page 125 G3-8 MA FM 5207 – R03 Airplane and Systems Description on/off, volume The radio is switched on and off by rotating the VOL knob. This knob also adjusts volume. COM/NAV display Pressing the C/N button changes display of NAV and COM frequencies. COM frequency Hit C/N first to select COM frequency band.
  • Page 126 G3-8 MA FM 5207 – R03 Airplane and Systems Description GARMIN SL40 The GARMIN SL40 is a 760-channel VHF COM transceiver with 25kHz frequency channel spacing. It incorporates active and standby flip-flop frequency tuning. Its frequency monitor function allows to check ATIS or emergency frequencies without leaving the assigned ATC channel The SL40 is the predecessor of the GARMIN GTR225/A.
  • Page 127 G3-8 MA FM 5207 – R03 Airplane and Systems Description Intercom and Audio Panel PS-Engineering PMA8000BT/i This is an audio panel with marker beacon receiver. It incorporates audio-in capability with several muting modes. The audio panel may be used with mono or stereo headsets. A common volume knob is provided for left and right seat.
  • Page 128 If mono headsets are plugged in, the signal for the right channel will short out with ground. The jacks in the REMOS GX do not provide an automated shutdown of the right channel if mono headsets are plugged in.
  • Page 129 G3-8 MA FM 5207 – R03 Airplane and Systems Description plugged in or pulled or out while the intercom is switched on. Always shut down the intercom when connecting or disconnecting headsets. From SN378 on all aircraft are equipped with stereo/mono switches. In this case mono headsets are approved without any adaptors.
  • Page 130 G3-8 MA FM 5207 – R03 Airplane and Systems Description GARMIN GMA340 This is an audio panel with marker beacon receiver. It incorporates audio-in capability with several muting modes. The audio panel may be used with mono or stereo headsets. Volume for left and right seat can be adjusted separately.
  • Page 131 G3-8 MA FM 5207 – R03 Airplane and Systems Description GPS Equipment GARMIN GPSMAP series The GPSMAP series by Garmin are navigation aids with color screen, operated by discrete buttons. The GPS is switched on automatically once the ignition key is set to AVIONIC. GPSMAP495/496 GPSMAP695/696 Basic operation is done by following icons:...
  • Page 132 G3-8 MA FM 5207 – R03 Airplane and Systems Description GARMIN aera660 and aera series The GPS aera series by Garmin are prime class navigation aids with brilliant color screen and touch operation. The GPS is switched on automatically once the ignition key is set to AVIONIC. aera 5xx series aera660 aera 796...
  • Page 133 G3-8 MA FM 5207 – R03 Airplane and Systems Description Following gestures operate the GPS: select zoom zoom in scroll zoom out Basic operation is done by following icons: shows sectional map NEAREST shows nearest airfields DIRECT TO enabled direct navigation to airfield selected FPL List shows active flightplan and allows programming ZOOM...
  • Page 134 G3-8 MA FM 5207 – R03 Airplane and Systems Description FlymapL This GPS is the top-end equipment offered in the REMOS GX. It relies solely on touchscreen operation. Tap and hold on a map item and a context menu opens.
  • Page 135 G3-8 MA FM 5207 – R03 Airplane and Systems Description Transponder DYNON D600/D700 The top bar displays the transponder status as shown below: To set the transponder hit the softkey XPNDR from the main menu. The XPDR menu will now show up as follows: turns on ground mode, pressing the softkey again will put the transponder into standby mode activates Mode A, pressing the softkey again will...
  • Page 136 G3-8 MA FM 5207 – R03 Airplane and Systems Description DYNON HDX800 The top bar displays the transponder status as shown below. To set the transponder touch into the top bar in the area that displays the transponder status. The XPDR control page will appear as follows: IDENT squawks ident squawks VFR...
  • Page 137 VOR (ILS is a special version of a VOR with just one radial). In the version as offered by REMOS, the autopilot does not offer VNAV, it can only hold or change a selected altitude. The autopilot does not provide vertical guidance on an ILS or GPS-based LPV approaches.
  • Page 138 G3-8 MA FM 5207 – R03 Airplane and Systems Description autopilot modes The DYNON autopilot has two modes: 1. track and altitude (TRK+ALT) The autopilot keeps your selected altitude, climbs or descents to it and follows a given ground track. Setting up or even select a navigation source is not required.
  • Page 139 G3-8 MA FM 5207 – R03 Airplane and Systems Description example, is the selected HSI source is the SkyView GPS, and there is an active flightplan, the autopilot will fly that flightplan. Or if the source is a VOR, the autopilot will seek to capture and hold the set radial to or from the VOR.
  • Page 140 G3-8 MA FM 5207 – R03 Airplane and Systems Description control wheel steering When the autopilot is engaged, press and hold the AP/DISC button on the control stick to put the autopilot into control wheel steering mode. While control wheel steering mode is active, the autopilot servos are temporarily disengaged.
  • Page 141 G3-8 MA FM 5207 – R03 Airplane and Systems Description Then the AP/DISC button is released, the autopilot engages in TRK+ALT mode. TRK and ALT are synchronized to the aircraft’s current GPS ground track and altitude. selecting a navigation source From the main menu select PFD to open the PFD menu, then hit HSI SCR to cycle the HSI through the different navigation data sources that are connected to the SkyView system.
  • Page 142 G3-8 MA FM 5207 – R03 Airplane and Systems Description HSI+ALT Engages autopilot in HSI and altitude mode, this requires to select and set up a navigation source first, otherwise this softkey is greyed out. Subsequent presses of this button disengages the autopilot again.
  • Page 143 G3-8 MA FM 5207 – R03 Airplane and Systems Description adjusting altitude Click on one of the joysticks or kick it up or down and then select the ALT bug by either rotating the joystick or clicking up or down. Once the ALT bug is selected, adjust the bug and therefore altitude by rotating the joystick.
  • Page 144 G3-8 MA FM 5207 – R03 Airplane and Systems Description 7.11 Inflight Entertainment The aircraft is equipped with a 3.5mm jack for feeding in audio signals for inflight entertainment. Any audio source can be connected to this jack in the switchboard, just right of the power lever. Except for the GARMIN GMA340, all intercom or audio panels allow coupling a cellphone, either direct via BLUETOOTH®...
  • Page 145 G3-8 MA FM 5207 – R03 Airplane and Systems Description GARMIN GMA340 audio panel Limited audio functionality is provided on aircraft equipped with only the GMA 340. GPS and audio-in cannot be put through the intercom at the same time. If audio is played, the 3.5mm jack of the Garmin GPS must be disconnected.
  • Page 146 G3-8 MA FM 5207 – R03 Airplane and Systems Description 7.12 Engine Operation center stack The ignition and starter keylock is located in the lower part in the center stack; positions are off – left magneto – right magneto – both magnetos –...
  • Page 147 7.13 Electric System general The electrical system of the REMOS GX is powered by a generator, which is capable of 250W at engine speeds of at least 4,000 RPM. At lower engine speeds the output of the alternator is lower. Below a certain engine speed, the alternator is not able to support the power demand for all electrical equipment.
  • Page 148 NOTE power consumption and the battery will be discharged. aircraft battery capacity The aircraft battery on the REMOS GX has a high responsibility regarding a reliable electric system. Use min. 6Ah for any equipment. Installation of battery with higher capacity than minimum specified is acceptable and recommended.
  • Page 149 Take the battery out of the aircraft in winter time if you do not fly and stow it in a dry place at room temperature. Aircraft owners that operate their REMOS GX throughout the entire year, even in the cold winter time, or on airfields with long taxi distances, are strongly recommended to use a battery with a higher capacity than the minimum specified.
  • Page 150 G3-8 MA FM 5207 – R03 Airplane and Systems Description aircraft battery specification lead battery specification cold cranking amps min. 150 A battery type starter lead battery (AGM preferred) example Hawker Odyssey PC545 Hawker Genesis 12EP13 lithium battery specification cold cranking amps min.
  • Page 151 G3-8 MA FM 5207 – R03 Airplane and Systems Description switchboard All controls of the REMOS GX are located at the central control panel. All switches are clearly labeled. The switch panel incorporates the following: • Switch for ACL •...
  • Page 152 G3-8 MA FM 5207 – R03 Airplane and Systems Description circuit breakers The electrical system of the REMOS GX consists of a BUS system, split into master-BUS and avionics-BUS. All electrical components are protected with circuit breakers (CB). The fuse for the charge control check light is located behind the switch panel.
  • Page 153 7.15 Flaps Flaps on the REMOS GX can be selected at any position between 0° and 40° with the flap selector switch in the center stack, position of the flaps is displayed in the SkyView system: •...
  • Page 154 G3-8 MA FM 5207 – R03 Airplane and Systems Description 7.16 Cockpit Lighting The REMOS GX cockpit features an effective LED panel lighting system, which can be dimmed independently from the instrument lights. It is a dazzle-free system designed for Night-VFR use.
  • Page 155 G3-8 MA FM 5207 – R03 Airplane and Systems Description 7.19 Baggage and Luggage Place light luggage below the luggage nets behind the seats. Larger baggage must be stowed in the baggage compartment behind the pilot seat. It is accessible with the pilot seat taken out. Even if volume permits, the max.
  • Page 156 G3-8 MA FM 5207 – R03 Airplane and Systems Description 7.21 Engine The engine used on the REMOS GX is the ROTAX 912 ULS-2, which complies with ASTM F2239. The engine is a 4 stroke, 4 cylinder horizontally opposed, duel carbureted, twin spark ignition engine with one central camshaft, pushrods and overhead valves.

  • Page 157: Fuel System

    2-blade, composite 2. Neuform 2. CR3-65-47-101,6 3-blade, composite 7.23 Fuel System The fuel system of the REMOS GX consists of the following components: • filler neck (lockable and non-lockable versions available) • fuel tank (see section 2 and 7 and NOT-001 for fuel grades) •...
  • Page 158 G3-8 MA FM 5207 – R03 Airplane and Systems Description overview of airframe sided fuel system Systeme 7 - 56...
  • Page 159 G3-8 MA FM 5207 – R03 Airplane and Systems Description fuel shut-off valve engine sided fuel system Fuel is fed from the fuel tank to the electric fuel pump. This pump is a boost pump that sets the fuel system under pressure and reliably prevents any tendency for vapor lock.
  • Page 160 G3-8 MA FM 5207 – R03 Airplane and Systems Description Through the fuel shut-off valve and the firewall, the fuel is routed towards the fuel divider. This unit provides ports for measuring fuel pressure and fuel flow and feeds the carburetors. With the fuel shut-off valve closed no fuel is fed to the engine and the engine will fail due to fuel starvation.
  • Page 161 G3-8 MA FM 5207 – R03 Airplane and Systems Description 7.24 Braking System The braking system of the REMOS GX consists of the following components: • reservoir • master cylinder • parking brake valve • brake lines • brake cylinder, brake disc and brake pads...
  • Page 162 These avionics systems may replace the equipment mentioned in this manual in part or whole. The installation of this equipment must be approved by REMOS and listed in the equipment list. For operating instructions please refer to the manuals belonging to the equipment installed.
  • Page 163 POH Supplement – Flight Training...
  • Page 164 G3-8 MA FM 1209 – R07 Supplement Flight Training Table of Content sect. description page Introduction Take-Off Climb Cruise Stall Slip Glide Descent Approach 9-10 Touch Down 9-13 Supplement Flight Training 9 - 1...
  • Page 165 Introduction This chapter should enable you to familiarize yourself with the flight performance and flight characteristics of the REMOS GX. To complete these instructions, please refer to the appropriate sections in the POH. The following pages describe flight characteristics experienced during...
  • Page 166 G3-8 MA FM 1209 – R07 Take-Off Take-off under normal conditions 1. After the pre-flight check has been completed, buckle up, warm up the engine and line up on the active runway. Keep flaps up. Take-off may also be performed with flaps 15deg, but this leads to higher pilot workload and the slightly shorter take-off distance with flaps 15deg is often not a limiting criterion.
  • Page 167 G3-8 MA FM 1209 – R07 Climb Climb with Best Angle of Climb With engine set to full power, establish V = 50 kIAS for all flap settings. At this airspeed the aircraft will achieve the steepest angle of climb. During climb it is essential to monitor oil and water (CHT) temperatures.
  • Page 168 When flying in gusty weather conditions, the normal operating airspeed V = 107 kIAS should not be exceeded for safety reasons. The REMOS GX offers very stable flight characteristics even in heavy weather conditions. Cruise in rain or with dirty aircraft Raindrops and bugs affect the performance of the aircraft.
  • Page 169 G3-8 MA FM 1209 – R07 Stall The REMOS GX is fully controllable when flying at a wide range of airspeeds. At airspeeds below the lower speed limit, the aircraft will display very stable stall characteristics. If the airspeed is reduced by the pilot gradually pulling back on the control stick, aerodynamic buffet will occur, indicating that the aircraft is approaching the stall speed.
  • Page 170 G3-8 MA FM 1209 – R07 Slip The slip is a very stable flight condition and is also very easy to perform. This maneuver is used to increase aerodynamic drag to enable a high rate of descent. Before establishing a slip, you have to ensure that the airspeed is within the required limits.
  • Page 171 G3-8 MA FM 1209 – R07 Glide The aircraft can glide well with the engine off. Best glide ratios are achieved within an indicated airspeed of 60 kIAS. These speeds will establish a glide ratio of about 1:11 with the flaps retracted (0° position).
  • Page 172 G3-8 MA FM 1209 – R07 Descent When descending from level flight it is important to monitor engine temperatures. During descent, the temperatures will decrease, which could cause engine failure or carburetor icing to develop. Therefore we strongly recommend that you not exceed the lower limits of these temperatures.
  • Page 173 Or use all your guts. Approach under tailwind conditions When on final approach with a tailwind component, the REMOS GX does not require different approach or flare procedures than those used in calm or headwind conditions. However, you do have to keep in mind that the landing distance will increase significantly.
  • Page 174 Raindrops on the wing surfaces influence the aerodynamic characteristics of the airfoil; drag will increase while lift decreases. The airfoil used on the REMOS GX features stable flight characteristics in rainy conditions. Therefore, there are no special advisories for flights within rain.
  • Page 175 The aircraft has very good low speed characteristics and as such is easily controllable all the way through the landing phase. After a good approach has been conducted, the REMOS GX does not require much action to land with a perfect touch down. It is important to establish a safe and stable airspeed during the approach.
  • Page 176 G3-8 MA FM 1209 – R07 Imprint Pilot Operating Handbook REMOS GX Supplement Flight Training ASTM Edition Copyright REMOS AG © REMOS 2007-2017, all rights reserved...
  • Page 177 POH Supplement – Glider Towing...
  • Page 178 G3-8 MA FM 1210 – R07 Supplement Glider Towing Table of Content sect. description page General Information 10-2 Operating Limitations 10-3 Emergency Procedures 10-5 Normal Procedures 10-7 Performance 10-10 Weight and Balance 10-16 Systems 10-17 Aircraft Ground Handling and Service 10-18 Supplement Glider Towing 10 - 1...
  • Page 179 Quick Reference For use as a glider towing aircraft, the REMOS GX is equipped with the TOST E85 tow release clutch, which is connected to the fuselage tail by a specially developed mounting frame. To release the tow rope a release lever is located on the left hand side of the pilot seat (colored yellow).
  • Page 180 300 dN Maximum Glider Take-Off Weight The maximum permissible take-off weight of the glider to be towed varies with the propeller mounted to the REMOS GX. The following operating limitations may not be exceeded: Propeller Glider Tonini GT-2...
  • Page 181 • as per D-VFR minimum equipment list, plus • TOST tow release clutch type E85 • REMOS mounting frame for tow release clutch • yellow colored release handle • rear view mirror placed on main spar carrythrough Flying Without Doors...
  • Page 182 G3-8 MA FM 1210 - R07 Emergency Procedures Engine Failure Procedure Case 1: altitude not enough for engine re-start 1. AVIATE – NAVIGATE – COMMUNICATE 2. landing site IDENTIFY 3. glider pilot NOTIFIED 4. glider pilot RELEASE ROPE 5. engine 6.
  • Page 183 If the glider pilot cannot recover from the abnormal flight attitude and does not or cannot release the tow rope, the NOTE REMOS GX pilot must release the tow rope to recover from the abnormal flight attitude. If the abnormal flight attitude cannot be recovered from...
  • Page 184 G3-8 MA FM 1210 - R07 Normal Procedures Preflight Check Checklist 1. Perform standard preflight check 2. Check tow release clutch and test-release a tow rope Take-Off Procedure 1. oil cooler flap OPEN 2. carburetor heat 3. electric fuel pump 4.
  • Page 185 G3-8 MA FM 1210 - R07 Normal Procedures Climb Briefing Flight tests have been conducted with various glider airplanes. These tests revealed that modern composite gliders, especially when loaded with water ballast, must be towed faster than older wooden sailplanes. The modern gliders are usually towed with...
  • Page 186 G3-8 MA FM 1210 - R07 Normal Procedures Approach Checklist 1. wind, weather, visibility 2. ATIS CHECKED 3. runway CORRECT DIRECTION 4. traffic pattern ALTITUDE and ROUTING 5. radios ON and FREQUENCY SET 6. transponder AS REQUIRED 7. carburetor heat AS REQUIRED 8.
  • Page 187 G3-8 MA FM 1210 - R07 Performance Take-Off Roll Distance If the REMOS GX is equipped with a Sensenich R70EN or a Neuform CR3-65 propeller, the following take-off roll distances apply (under the conditions of a hard surface runway, ISA conditions, no wind and lift-off at 50 kIAS.
  • Page 188 G3-8 MA FM 1210 - R07 Performance Take-Off Air Distance If the REMOS GX is equipped with a Sensenich R70EN or a Neuform CR3-65 propeller, the following take-off air distances apply (under the conditions of a hard surface runway, ISA conditions, no wind and lift-off at 50 kIAS.
  • Page 189 G3-8 MA FM 1210 - R07 Performance Take-Off Distance over 50ft The following diagram presents the total take-off distance over 50ft (under the conditions of a hard surface runway, ISA conditions, no wind and lift-off at 50 kIAS. Take-Off Distance over 50ft ISA, hard surface, no wind 2500 2000...
  • Page 190 G3-8 MA FM 1210 - R07 Performance Effects on Take-Off Distance Performance data apply under ISA conditions on an even, dry, hard runway surface. Various circumstances have an effect on take-off performance. According to CAA-circular AIC 127-2006, it is recommended to use following add-ons on roll- and air distances: add-ons on take-off roll distance for dry grass + 20%...
  • Page 191 G3-8 MA FM 1210 - R07 Performance ISA std. Temperature 15000 14000 13000 12000 11000 10000 9000 8000 7000 6000 5000 4000 3000 2000 1000 temperature [ °C ] Supplement Glider Towing 10 - 14...
  • Page 192 G3-8 MA FM 1210 - R07 Performance Tested Glider Configuration The following gliders have been towed during flight tests: LS-1, LS-4, Baby-III, Astir and Twin Astir, Hornbach, Junior, Jantar, Pirat, Puchacz, Discus and DuoDiscus, Blanik, DG-100/300/500, DG-1000, ASK-21 and ASW-24, Nimbus and Cirrus, Cobra, PIK-20. Remarks Based on the rules of the Light Sport Aircraft airworthiness standards, the maximum dimension is defined by the weight of the...
  • Page 193 • TOST tow release clutch, type E 85 • REMOS mounting frame for tow release clutch • release handle (colour yellow) • REMOS oil temperature regulation flap •...
  • Page 194 G3-8 MA FM 1210 - R07 Systems The tow release handle is installed inside the cabin of the REMOS GX. The handle is located on the left hand side of the pilot seat, colored yellow. Pulling the handle releases the tow rope. The handle should provide a free play of 1/2 to 1 inch.
  • Page 195 G3-8 MA FM 1210 - R07 Aircraft Ground Handling and Service During regular servicing intervals, the tow release clutch must be cleaned, lubricated and checked to assure proper operation. A general overhaul of the release clutch must be conducted every 4 years or 4,000 towing operations, whatever comes first.
  • Page 196 G3-8 MA FM 1210 - R07 Imprint Pilot Operating Handbook REMOS GX Supplement Glider Towing ASTM Edition Copyright REMOS AG © REMOS 2007-2017, all rights reserved...
  • Page 197 POH Supplement – Banner Towing...
  • Page 198 G3-8 MA FM 1211 - R04 Supplement Banner Towing Table of Content sect. description page General Information 11-2 Operating Limitations 11-3 Emergency Procedures 11-5 Normal Procedures 11-7 Performance 11-9 Weight and Balance 11-12 Systems 11-13 Aircraft Ground Handling and Service 11-14 Supplement Banner Towing 11 - 1...
  • Page 199 Quick Reference For use as a banner towing aircraft, the REMOS GX is equipped with the TOST E85 tow release clutch, which is connected to the fuselage tail by a specially developed mounting frame. To release the tow rope a release lever is located on the left hand side of the pilot seat (colored yellow).
  • Page 200 Low drag banners up to 216m have been tested. max. drag 700 N at 73 kCAS max. weight 20 kg Approved banners should be used. Crew During banner towing operations, the REMOS GX must be operated only pilot passenger allowed, except training/instruction). Minimum Equipment List •...
  • Page 201 G3-8 MA FM 1211 - 04 Operating Limitations Flying Without Doors not permitted during towing operations Required Placards and Markings Adjacent to the airspeed indicator: Adjacent to the tow release handle: At the release clutch bracket: Supplement Banner Towing 11 - 4...
  • Page 202 G3-8 MA FM 1211 - 04 Emergency Procedures Engine Failure Procedure Case 1: altitude not enough for engine re-start 1. AVIATE – NAVIGATE – COMMUNICATE 2. landing site IDENTIFY 3. engine 4. fuel valve CLOSE 5. declare emergency MAYDAY MAYDAY MAYDAY 6.
  • Page 203 G3-8 MA FM 1211 - 04 Emergency Procedures Failure of the Release Clutch Procedure 1. approach airspeed 60 kIAS 2. full flaps airspeed 78 kIAS 3. max. airspeed with banner 65 kIAS 4. flaps DOWN 5. engine power AS REQUIRED 6.
  • Page 204 G3-8 MA FM 1211 - 04 Normal Procedures Preflight Check Checklist 1. Perform standard preflight check 2. Check tow release clutch and test-release a tow rope Take-Off Procedure 1. oil cooler flap OPEN 2. carburetor heat 3. electric fuel pump 4.
  • Page 205 G3-8 MA FM 1211 - 04 Normal Procedures Approach Checklist 1. wind, weather, visibility 2. ATIS CHECKED 3. runway CORRECT DIRECTION 4. traffic pattern ALTITUDE and ROUTING 5. radios ON and FREQUENCY SET 6. transponder AS REQUIRED 7. carburetor heat AS REQUIRED 8.
  • Page 206 G3-8 MA FM 1211 - 04 Performance Take-Off Distance take-off distance over 50ft hard surface, no wind, ISA 1200 1000 Tonini Propeller Neuform Propeller Sensenich Propeller Rospeller Propeller banner area [ qm ] Supplement Banner Towing 11 - 9...
  • Page 207 G3-8 MA FM 1211 - 04 Performance Effects on Take-Off Distance Performance data apply under ISA conditions on an even, dry, hard runway surface. Various circumstances have an effect on take-off performance. According to CAA-circular AIC 127-2006, it is recommended to use following add-ons on roll- and air distances: add-ons on take-off roll distance for dry grass + 20%...
  • Page 208 G3-8 MA FM 1211 - 04 Performance ISA std. Temperature 15000 14000 13000 12000 11000 10000 9000 8000 7000 6000 5000 4000 3000 2000 1000 temperature [ °C ] Supplement Banner Towing 11 - 11...
  • Page 209 • TOST tow release clutch, type E 85 • REMOS mounting frame for tow release clutch • release handle (colour yellow) • REMOS oil temperature regulation flap •...
  • Page 210 G3-8 MA FM 1211 - 04 Systems The tow release handle is installed inside the cabin of the REMOS GX. The handle is located on the left hand side of the pilot seat, colored yellow. Pulling the handle releases the tow rope. The handle should provide a free play of 1/2 to 1 inch.
  • Page 211 G3-8 MA FM 1211 - 04 Aircraft Ground Handling and Service During regular servicing intervals, the tow release clutch must be cleaned, lubricated and checked to assure proper operation. A general overhaul of the release clutch must be conducted every 4 years or 4,000 towing operations, whatever comes first.
  • Page 212 G3-8 MA FM 1211 - 04 Imprint Pilot Operating Handbook REMOS GX Supplement Banner Towing ASTM Edition Copyright REMOS AG © REMOS 2007-2017, all rights reserved...
  • Page 213 POH Supplement – Continued Airworthiness...
  • Page 214 G3-8 MA FM 1212 - R03 Supplement Continued Airworthiness Table of Content sect. description page Purpose 12-2 Continued Airworthiness System 12-3 Owner/Operator Responsibilities 12-5 Release of Notices to the Public 12-7 Documentation Update 12-8 Maintenance and Annual Condition Inspection 12-9 Modifications or Change of Equipment 12-10 Repairs...
  • Page 215 G3-8 MA FM 1212 - R03 Purpose Continued Airworthiness is everything that is required to keep an aircraft in a safe condition to fly. This does not only include the technical part like maintenance and annual condition inspection. It also includes update of documentation, e.g. Pilot Operating Handbook, issuing repair instructions and repair approvals, change on equipment and feedback of the customer to the manufacturer.
  • Page 216 If a customer does not inform the manufacturer by means of this form, REMOS AG also accepts any other way of information as long as it contains at least the following information: •...
  • Page 217 • decision of corrective action The continued airworthiness system of REMOS AG does not only cover events that have occurred during operation of the aircraft. Proposals for improvements or corrections, service difficulties, findings during maintenance events or annual condition inspections are also covered by the continued airworthiness system.
  • Page 218 G3-8 MA FM 1212 - R03 Owner/Operator Responsibilities During handover of the aircraft, the owner/operator is introduced into the continued airworthiness system of REMOS AG. The customer is informed about the following: • The maintenance handbook provides all information that the customer needs to comply with the regulations, especially with continued airworthiness and maintenance.
  • Page 219 This information is provided by means of the customer commitment form, which is part of the maintenance manual. The owner/operator shall sign this form and send it to REMOS AG. On this form the owner/operator shall also provide the manufacturer with current contact data.
  • Page 220 REMOS AG to its customers. • NOTIFICATION will be issued in case service information is required. The public is notified via the website www.remos.com which is the central means of communication of REMOS AG to its customers. Supplement Continued Airworthiness 12 - 7...
  • Page 221 Documentation Update Any documentation update will be released on the website www.remos.com. Owner/operators will not be informed by postal mail, unless such a documentation update is mandatory for safety of flight and is released by a safety alert or a service bulletin. Examples for documentation updates are new revisions of: •...
  • Page 222 G3-8 MA FM 1212 - R03 Maintenance and Annual Cond. Inspection Maintenance intervals of all REMOS aircraft are 25h for the first maintenance event, followed by 100h inspections. In case that AVGAS 100LL is used for more than 30% of the time, oil change interval is reduced to 50h.
  • Page 223 A&P Mechanic or a Part 145 Repair Station with appropriate ratings after the work is accomplished. Then this LOA will be signed by the Head of Design of REMOS AG and handed out to the customer. This procedure will be performed by e-mail.
  • Page 224 G3-8 MA FM 1212 - R03 Modifications or Change of Equipment Without having updated the equipment list and weight and balance or not having changes that are not part of the maintenance manual approved by the manufacturer, the aircraft is considered not airworthy and unsafe to fly.
  • Page 225 A&P Mechanic or a Part 145 Repair Station with appropriate ratings after the work is accomplished. Then this Repair Approval will be signed by the Head of Design of REMOS AG and handed out to the customer. This procedure will be performed by e-mail.
  • Page 226 G3-8 MA FM 1212 - R03 Repairs The extent of work cannot generally be defined; it is always an individual project. Working hours of the engineering department will be charged by the hour according to actual pricelists. This procedure is not intended and built up for the manufacturer to make money of it.
  • Page 227 G3-8 MA FM 1212 - R03 Contact Data The manufacturer of the REMOS aircraft and the only responsible entity for continued airworthiness is REMOS AG Franzfelde 31 D-17309 Pasewalk G E R M A N Y Tel: +49-3973-225519-0 Fax: +49-3973-225519-99 Email: service@remos.com...
  • Page 228 G3-8 MA FM 1212 - R03 Imprint Pilot Operating Handbook REMOS GX Supplement Continued Airworthiness ASTM Edition Copyright REMOS AG © REMOS 2007-2017, all rights reserved...
  • Page 229 POH Supplement – Abbreviated checklists...
  • Page 230 G3-8 MA FM 1213 – R01 Supplement Abbreviated Checklists intentionally left blank Supplement Abbreviated Checklists 13 - 1...
  • Page 231 REMOS only. This POH supplement section 13 offers abbreviated checklists released by REMOS. By using these abbreviated checklist, the pilot in command acknowledges that the content is abbreviated and might be incomplete. Always refer to sections 3 and 4 for full version of these checklists.
  • Page 232 G3-8 MA FM 1213 – R01 Supplement Abbreviated Checklists intentionally left blank Supplement Abbreviated Checklists 13 - 3...
  • Page 233 G3-8 MA FM 1213 – R01 Supplement Abbreviated Checklists CHECK BEFORE ENGINE START LANDING preflight check ......OK approach ......BRIEFED seat belts ....... FASTENED flaps ........DOWN brake ......... SET approach speed ....60 KIAS ENGINE START SHUTDOWN master switch ......ON brake..........
  • Page 234 G3-8 MA FM 1213 – R01 Supplement Abbreviated Checklists ABBREVIATED EMERGENCY CHECKLIST AVIATE – NAVIGATE - COMMUNICATE DECLARE EMERGENCY SPIN RECOVERY GENERATOR FAILURE engine ......... IDLE non-essentials ...... OFF aileron ......NEUTRAL system ..TROUBLESHOOT rudder....OPPOSITE SPIN ENGINE FIRE ON GROUND elevator ......
  • Page 235 G3-8 MA FM 1213 – R01 Imprint intentionally left blank Supplement Abbreviated Checklists 13 - 6...
  • Page 236 G3-8 MA FM 1213 – R01 Imprint Pilot Operating Handbook REMOS GX Abbreviated Checklists ASTM Edition Copyright REMOS AG © REMOS 2007-2017, all rights reserved...

Table of Contents
