Summary of Contents for C-SCOPE M-SCAN
-
Page 2: Table Of Contents
Power Line Indicator Erase Submersion in Water & Searching 12. Application Note 1. Understanding the M-Scan Magnetometer 14. Application Note 2. How Objects Appear to a Magnetometer 16. Application Note 3. Depth 17. Application Note 4. Using near Large Ferrous Objects... -
Page 3: Get Started
3. Turn the M-Scan on by pressing ON/OFF The display should come on. 4. Hold the M-Scan in one hand at 45º to the ground and move Hold the M-Scan slowly across the area to be searched marking places where the in one hand at 45º... -
Page 4: Features
The sensitivity setting controls the effective depth that the magnetometer. It responds when it detects ferromagnetic M-Scan will find a ferromagnetic object. The M-Scan uses material (material that is able to be magnetised, such as iron) eight AA batteries in the sealed battery compartment giving... -
Page 5: Controls
2. Volume Up/Down 3. Sensitivity Up/Down 4. Erase Button 5. Bar graph 6. Sensitivity Indicator 7. Volume Indicator M-SCAN 8. Digital Signal Indicator 9. Power Line Warning 10. Battery Indicator 11. Flange Symbol Refer to Application Note 2 (page 13) -
Page 6: How The M-Scan Works
M-Scan to produce a different signal. When no ferromagnetic objects are present, the speaker emits a steady low frequency tone but as the M-Scan gets closer to a ferromagnetic object the audio pitch increases until the strongest signal from the object is directly under the end of the sensor tube. -
Page 7: Basic Operation And Description
The battery compartment is located on the underside Take care to ensure that each battery is in the orientation shown of the M-Scan. Use a coin to rotate the latch anti clockwise on the holder (batteries should alternate) and that the holder 90°... -
Page 8: Preparation
(eg S2). Check that the battery symbol (on the top right of the display) shows at least two bars before commencing the search. The M-Scan will work with one segment showing but it is not recommended. -
Page 9: Volume
There is a standard headphone 3.5mm jack socket under and V8 is the loudest. the cover on the base of the M-Scan. The audio from the load The display will momentarily speaker is not cut out when headphones are connected. -
Page 10: Visual Indication
If the signal is very broad this also indicates a deeply buried object. If the sensitivity is reduced or the M-Scan is lifted up When nearing ferromagnetic 0.5m (1.5 ft) and the object traversed again and the signal... -
Page 11: Power Line Indicator
Notes: Hold the M-Scan at 45° to the ground. Scan from side to side 1. Shielded cables (e.g. those in a steel conduit or armour) keeping the end of the sensor tube at the same distance from will not be indicated. -
Page 12: Application Note 1. Understanding The M-Scan Magnetometer
Application Note 1. Understanding the M-Scan Magnetometer The C-Scope M-Scan magnetometer is designed to detect the presence of iron and steel objects by sensing the magnetic field which surrounds them. The Earth’s magnetic field is ever present, and the instrument cancels this background field out, so that small variations in field can be detected. - Page 13 A representation of the Earth’s magnetic field is shown in Figure 1. Note that Magnetic North is a few degrees away The M-Scan has two sensors in the long metal tube, spaced from True North and that the Magnetic North Pole is actually approximately 20 inches/ 50cms apart.
-
Page 14: Application Note 2. How Objects Appear To A Magnetometer
Application Note 2. How Objects Appear to a Magnetometer Iron objects tend to concentrate the magnetic field lines around If the iron object is flat in shape and horizontal (A), it will appear them distorting the Earth’s field. The magnetic field produced by to be rather like a horizontal bar magnet, and will form a North an iron object will tend to follow the same orientation as the Pole on its North side and a South Pole of similar strength... - Page 15 North to South or vice versa. With careful use of the M-Scan, and knowledge of the pipe-section lengths, it may be possible to locate the flanged Figure 4 An iron pipe run may appear as a series of long joints.
-
Page 16: Application Note 3. Depth
It is recommended that the search is repeated at a lower sensitivity or with the M-Scan raised 0.5m (1.5 ft) so small objects close to the surface are not detected. -
Page 17: Application Note 4. Using Near Large Ferrous Objects
Application Note 4. Using near Large Ferrous Objects A feature of the M-Scan is the ‘Erase’ button. The instrument Figure 6 A feature of the M-Scan is the ‘Erase’ button, is balanced during manufacture to produce a response close which cancels interfering fields from nearby objects to zero in Earth’s field. -
Page 18: Application Note 5. Finding The Centre Of A Target
Application Note 5. Finding the Centre of a Target The sensors in the M-Scan are orientated along the axis of the This also has relevance in mid-latitude regions of the world, tube. When the tube is placed at right-angles to a magnetic field where the Earth’s field dips down at an angle, and buried objects... - Page 19 In Figure 8 there are two smaller, but detectable, side lobes (A) either side of a central main peak (C) when using the M-Scan vertically to find a magnetised marker pin. Note there is a null either side of the centre (B) where the lines of magnetic flux are at right angles to the sensor tube.
- Page 20 Copyright © 2015 C.Scope International Ltd. All Rights Reserved. C.Scope has a policy of continuous product development and reserves the right to change the design, specification and labelling without notice. All errors and omissions excepted. We make every effort to ensure that the information we provide about our products and their use is correct.
