Delton 2230A Instruction Manual

INSTRUCTION MANUAL
DIGITAL MULTI METER
2230A/2230B
We thank you very much for your purchasing our
POCKET PERSONAL DIGITAL MULTIETER, This
model is a most Reliable, high-precision instrument,
designed by our excellent technology.
Before you use your new instrument, please read this
Operators Manual completely and familiarize yourself
Thoroughly with all functions and connections, With
proper use and care your Digital Multimeter will give you
years of satisfactory service.

SAFETY RULES

● Always check to make sure that the function switch
is set to the proper position.
● When
making measurements,
dangerous voltages may be present in normally
safe areas.
● Always disconnect the circuit under test prior to
attaching test leads, as voltages may be present in
capacitors even
disconnected
● To avoid electrical shock,use CAUTION when
working above 60V DC or 25V AC rms.
● Make sure all power (AC or DC) is disconnected
(OFF) when making
measurement.
● Never make measurement with the battery cover of
battery case OFF.
● Never fail to keep the maximum tolerable input.
● The POCKET PERSONAL DMM is designed for low
voltage applications. The measurement should be
limited to the circuit under 500V (AC/DC)
● NEVER use this meter if it is WET, DAMP or has
con-densation on it or the probes.
● When making measurements MAKE SURE your
hands NEVER touch anything xecrpt the plastic part
of the probes.

SPECIFICATIONS

Measuring Method:Dual integration mode
Display:3 -3/4 digital LCD reading of appprox 3260.
Range:Auto ranging
Polarity Automatic
polarity,minus(-) sign for negative polarity.
Overrange indication:"OL" mark indication (Except
AC/DC )
Sampling:2 times/s
Low Battery indication " " mark is displayed when the
battery voltage drops below operating voltage
Auto power off :The meter is powered off 15 minute
later after the last operation was made to bring back
display ,please return the function switch to the OFF.
Bar graph display
Operational temperature :0～40℃，80%RH(max)
CAUTION
when the main power
resistance
no indication for
Storage temperature :-20℃～60℃,70%RH (max)
Power consumption: 6Mw(TYP)
Size:54(W)×108(H)×12(D)mm
Weight:Approx 110g (include batteries and case )
Accessores:Batteris ,LR-44(1.55V)

MEASUREMENT RANGES

Note/Accuracy specified for temperature range of
23℃± 5℃, 80%RH(max)
function
DCV
as
ACV
is
OHM
(OHMS)
0~2.000V
DCmA
ACmA

DECSRIPTION OF PANEL

positive
Function switch
Switch for changing the measurement function (Ω / )
for resistance,countinuity check.
(VOLT)for voltage measurement
( mA)for current measurement
(OFF) for power OFF
Hard cover case
Instrument manual
range
resolution
2230A 2230B
300mV 300mV 0.1 mV
3V 3V 1 mV
30V 30V 10 mV
300V 300V 100 mV
500V 500V 1 mV
3V 3V 1 mV
30V 30V 10 mV
300V 300V 100 mV
500V 500V 1 mV
300Ω 300Ω 0.1Ω
3KΩ 3KΩ 1Ω
30KΩ 30KΩ 10Ω
300KΩ 300KΩ 100Ω
3MΩ 3MΩ 1KΩ
30MΩ 30MΩ 10KΩ ±(10.0% of rdg +5 digits)
300Ω 300Ω 0.1Ω
0~2.000V 1 mV
30mA 10μA
※
300mA 100μA
※
30mA 10μA
※
300mA 100μA
※
2
1
1
accuracy
±(1.3% of rdg +2 digits)
±(0.7% of rdg +2 digits)
±(1.3% of rdg +2 digits)
±(2.3% of rdg +5 digits)
±(2.0% of rdg +4 digits)
±(2.0% of rdg +2 digits)
±(6.0% of rdg +2 digits)
±(10.0% of rdg +2 digits)
±(2.0% of rdg +2 digits)
±(2.5% of rdg +5digits)
