Cordless Electric Mower
Safety & Operating Instructions
Model: ECOMOW470
Read and understand this manual and all instructions before operating this mower!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ECOMOW470 and is the answer not in the manual?

Questions and answers

Summary of Contents for LAZER ECOMOW470

  • Page 1 Cordless Electric Mower Safety & Operating Instructions Model: ECOMOW470 Read and understand this manual and all instructions before operating this mower!
  • Page 2: Table Of Contents

    ECOMOW470 Cordless Electric Mower- Safety & Operating Instructions Table of Contents Chapter 1: Important Safety Considerations....................... 1 Chapter 2: Setting Up Your Mower........................3 Chapter 3: Operating Your Mower........................8 Chapter 4: Charging and Caring for the Battery....................9 Chapter 5: Caring and Servicing Your Mower ....................10 Chapter 6: Troubleshooting Tips........................
  • Page 3: Protecting Yourself And Those Around You

    Before starting the mower, adjust the cutting height accordingly. Tall and thick grass cut at a higher level. Do not force the lawnmower forward in thick grass. The ECOMOW470 Cordless Electric Mower will do better and a safer job when cutting at a steady rate.
  • Page 4: Chapter 2: Setting Up Your Mower

    ECOMOW470 Cordless Electric Mower- Safety & Operating Instructions Handling the Battery Safely Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities. Contact your local government for information regarding the collection systems available. If electrical appliances are disposed of in landfills of dumps, hazardous substances can leak into the groundwater and get into the food chain, damaging your health and well-being.
  • Page 5 ECOMOW470 Cordless Electric Mower- Safety & Operating Instructions Assembling Your Mower Step 1: Read the Safety & Operating Instructions before proceeding For your safety, it is important to read the information in “Chapter 1: Important Safety Considerations” before you assemble or use the Mower.
  • Page 6 ECOMOW470 Cordless Electric Mower- Safety & Operating Instructions Step 4. Attach the Mulching Plug, Rear Bagger, or the Side Discharge Chute Mulching Plug 1. Install the mulching plug as shown in Figure 5. Be sure to push the block all the way in until the notch in its bottom is engaged.
  • Page 7 ECOMOW470 Cordless Electric Mower- Safety & Operating Instructions Step 5: Adjust the Cutting Height Using the Cutting Height Lever located at the side of the rear left wheel (Figure 8), adjust the Cutting Height so that you cut off only one (1) to two (2) inches of grass at a time.
  • Page 8 ECOMOW470 Cordless Electric Mower- Safety & Operating Instructions ECOMOW470 Cordless Electric Mower Specifications 29kg (64lbs), with battery Weight with Battery 20kg (44lbs), without battery Length (deck with bag): 132cm Length (deck without bag): 90cm Dimensions Length (overall): 144cm Width: 55cm...
  • Page 9: Chapter 3: Operating Your Mower

    ECOMOW470 Cordless Electric Mower- Safety & Operating Instructions Chapter 3: Operating Your Mower 1. To start the mower press the start button first, then squeeze the control levers (Figure 11). Release the start button when the motor starts and continue to hold the control levers (Figure 12).
  • Page 10: Chapter 4: Charging And Caring For The Battery

    3. Always keep mower & battery pack away from warmer, heat sources (stoves, radiators, open flames, etc), and hazardous chemicals. 4. Never attempt to charge your battery pack with a charger other than an ECOMOW470 Cordless Electric Mower charger. The charger is specifically designed to give optimal performance of you ECOMOW470 Cordless Electric Mower’s battery pack.
  • Page 11: Chapter 5: Caring And Servicing Your Mower

    ECOMOW470 Cordless Electric Mower- Safety & Operating Instructions Chapter 5: Caring and Servicing Your Mower Never make adjustments or repairs with the Motor running. Always stop the Motor, wait for the Blade to stop moving, and remove the Battery to prevent accidental starting.
  • Page 12 ECOMOW470 Cordless Electric Mower- Safety & Operating Instructions Removing and Attaching Blade Always check the blade for sharpness, damage, and tightness before and after each use. Replace the blade promptly if it has been bent or damaged. Removing the blade: Remove battery.
  • Page 13: Chapter 6: Troubleshooting Tips

    ECOMOW470 Cordless Electric Mower- Safety & Operating Instructions Blade Sharpening and Balancing When the Blade is dull, the cut ends of the grass end up ragged and may turn brown soon after mowing. A dull blade also causes the Battery to discharge faster. When this occurs, sharpen the Blade (assuming the Blade is otherwise in good condition).
  • Page 14 ECOMOW470 Cordless Electric Mower- Safety & Operating Instructions C. Cutting height may be set too low, causing heavy strain on motor by trying to cut too much grass. Raise to a higher cutting position. 6. Mower motor will not stop when operator A.
  • Page 15: Chapter 7: Parts Lists, Schematic Diagrams, And Warranty

    ECOMOW470 Cordless Electric Mower- Safety & Operating Instructions Chapter 7: Schematic Diagrams...
  • Page 16 ECOMOW470 Cordless Electric Mower- Safety & Operating Instructions...
  • Page 17 ECOMOW470 Cordless Electric Mower- Safety & Operating Instructions CE Declaration of Conformity ECOMOW470 Cordless Electric Mower is in compliance with the specification of the Machinery Directive and subsequent modifications, 2006/42/EC Joe Teng, Director of Sales Department Macauto Industrial Co., Ltd.
