Model
RunCam Mini FPV DVR
Power in
DC 3.3-5.5V
Work Current
250mA Max
Power out
DC 5V @ Max 250mA
Video in
CVBS@1Vp-p 75Ω
Video out
CVBS@1Vp-p 75Ω
Encoder
MJPEG@AVI
Resolution
VGA ( 640 x 480 ) @ 30fps ( NTSC ) / 25 fps ( PAL )
Audio in
MIC
Micro SD Card
Max 32G
Dimension
25 x 25mm @20 × 20 M2 holes
Net Weight
3.5g
RunCam Mini FPV DVR
User Manual
www.runcam.com
Advertisement
Table of Contents
Summary of Contents for RunCam Mini FPV DVR
-
Page 1: User Manual
Model RunCam Mini FPV DVR Power in DC 3.3-5.5V Work Current 250mA Max Power out DC 5V @ Max 250mA RunCam Mini FPV DVR User Manual Video in CVBS@1Vp-p 75Ω Video out CVBS@1Vp-p 75Ω Encoder MJPEG@AVI Resolution VGA ( 640 x 480 ) @ 30fps ( NTSC ) / 25 fps ( PAL ) - Page 2 LED Status Red LED Constantly on — Power status light Blue LED Constantly on — In standby mode Blue LED Blink slowly (1 time per second) — In recording mode VIDEO_OUT AUDIO_IN Blue LED Blink quickly (2 times per second) —...
