Digiguard C-TVI-BL8304-W Manual

3MP TVI, All-in-One HD CAMERA
C‐TVI‐BL8304‐W

Key Features:

∙ 1/3" 3.1MP CMOS Sensor
∙ Mode TVI 3M ; AHD/ CVI 1080P
∙ With IR‐CUT, DWDR, DNR, UTC, OSD
∙ Video Output: TVI/AHD/CVI/CVBS
SPECIFICATION
DESCRIPTION
Imaging Device 1/3" 3.1MP CMOS Sensor
Effective Pixels
Scanning System
Synchronization
Horizontal Resolution TVI 3M ; AHD/ CVI 1080P
Video Output
S/N Ratio More than 50dB (AGC Off)
Min. Illumination
IRIS Adjustment
LENS 2.8~12 Manual Zoom Lens
Auto/FLK/1/25,30sec ~ 1/60000sec
Electronic Shutter
IR LEDs
Gama Characteristic
IR Distance
IR Status
Auto Gain Control
Day&Night
Privacy Masking
3D-DNR LEVEL(0~100)Adjustment
Digital Zoom
SENS-UP
MOTION
Digital Effect OFF / V-FLIP / MIRROR / ROTATE
Dimension (mm) 218(W) x 90(H) x 90(D)mm
Weight(g)
Input Voltage
Power Consumption IR OFF : 210mA / IR ON : 1000mA(±10%)
Operating Temp/Hum. -10ºC~ +50ºC / 30% ~ 80% RH
Storage Temp. / Hum. -20ºC ~ +60ºC / 20% ~ 90% RH
PAL
1080P (1920 X 1536)
Progressive Scan
Internal, Negative Sync
TVI/AHD/CVI/CVBS
0.001Lux(Color)/F1.2
Auto
MANUAL(X2~X512)
4PCS 42μ LEDs
0.45
60 Meters
Under 10 Lux by PD
Auto
Auto
On / Off (Programmable)
1.0X-8.0X
0FF/ X2-X8
ON/OFF
1400
DC 12V(±10%)
WARRANTY
Product BULLET CAMERA
Purchase
Address
Dealer
Please contact purchasing office or service center when you find any damage or
▶
problem with this product.
The warranty period is 2 years from Invoice date.
▶
◈A/S without cost◈
Within Warranty Period
When damages
occurred in
Repair or Replace
nomal working
environment
◈A/S with cost◈
Damage by customer's negligence
1. Damage by customer's careless handling
chargeable 2. Damage by natural disaster (Fire, Flood, etc.)
case even 3. Damage by not keeping the cautions and instructions on manual
within 4. Damage by not using appointed power(frequency, voltage) or adapter.
warranty 5. Damage by disassemble or cleaning by customer
6. Damage by repairment by a person excepting the dealer
DIMENSION
Warranty Period: 2 years
Model C‐TVI‐BL8304‐W
Serial No.
Customer
Representative
Warranty details
Within warranty After Warranty
Product
A/S without cost
Product
exchange
Warranty details
A/S with cost
