Summary of Contents for UniData Communication Systems UNIFIBER GIGAROUTER UF72N

  • Page 2: User Manual

    GIGAROUTER UF72N User Manual Version: GIGAROUTER UF72N We are enthusiastic for providing tech support in every way. You can get in touch with local dearer as well as contact to Customer Service Department directly. Unidata SpA Via Portuense, 1555 - 00148 - Roma (RM) c/o Commercity M25 - M26 Tel.
  • Page 3 Copyright Copyright by Unidata.SpA. All rights are reserved. No Part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Unidata SpA. is the trademarks of Unidata SpA. No the trademarks may be counterfeited. Disclaimer Unidata SpA reserves the right to change the document from time to time at its sole discretion, and not to make the notice to anyone in advance.

  • Page 4: Intended Audience

    Preface Version Statement This Manual is provided for GIGAROUTER UF72N gateway, the software version must be at least 1.10. Brief Introduction This manual provides technical information on how to configure and operate application for your GIGAROUTER UF72N unit. Chapter 1: Provides an overview of GIGAROUTER UF72N Chapter 2: Introduces the product Chapter 3: Introduces the configuration via WEB-based Management Intended Audience...
  • Page 5 Drag Press a mouse button and move the mouse Table 3 Convention for Keyboard Operation Style Meanings “+”means an operation which presses down several keys in the Ctrl + C keyboard in the same time. E.g. “Ctrl + C” means press down the key of “Ctrl”...

  • Page 6: Table Of Contents

    CONTENTS OVERVIEW ..............................1 PRODUCT INTRODUCTION ........................2 ............................2 PPEARANCE ..........................3 ARDWARE NTERFACE ..............................3 EATURES ......................... 4 ORKING NVIRONMENT CONFIGURATION INTRODUCTION ......................5 ............................... 5 OGIN ................................ 5 ........................6 ETWORK ONFIGURATION 3.3.1 Network Status ..........................6 3.3.2 WAN Configuration ........................
  • Page 7 3.6.2 Upgrade ............................80 3.6.3 Reboot System ..........................81 3.6.4 Backup/Restore ........................... 81 3.6.5 Diagnostic ............................ 81 3.6.6 User Management ........................83 3.6.7 System Log ..........................83 3.6.8 TR069 ............................84 3.6.9 SNMP ............................86 3.6.10 User Access Right ........................87 ..............................
  • Page 8 4.5.7 SNMP ............................201...

  • Page 9: Overview

    Gigarouter UF72N User Manual 1 Overview A new series of ALL IN ONE INTELLIGENT Gateway GIGAROUTER UF72N is perfectly designed for SOHO, small and medium sized business (SMB) requiring application-based solutions of low-capital investment to communicate with various kinds of users, the complete VoIP features are built in.

  • Page 10: Product Introduction

    Gigarouter UF72N User Manual 2 Product Introduction 2.1 Appearance Figure 2-1 GIGAROUTER UF72N Front View Table 2-1 LED Status Indication Power is off Solid Green Device is running Power is off INTERNET type WAN PPPoE connection Slow Flash Green INTERNET authenticate failed Solid Green INTERNET type WAN connection is up...

  • Page 11: Hardware Interface

    Gigarouter UF72N User Manual Figure 2-2 GIGAROUTER UF72N Rear View l WAN: 1000/100/10Mpbs ethernet ports. l LAN(N): 1000/100/10Mpbs ethernet ports. l SFP: Gigabit fiber interface. l SD: Interface for SD card. l FXS: Analog telephone interface. l POWER: DC power input connector. l...

  • Page 12: Working Environment

    Gigarouter UF72N User Manual Management l Management Protocol: CLI,SNMPV1/2,Tr069,Web l LED Indications: Total 12LEDS for Power, WAN/LAN, Phone l Control Button: WPS Button, WLAN Button, Power Switch, Reset Button l Supports ALG, DMZ, PAT Firewall & Security l Firewall Protection: IDS&IPS, Block Ping/ICMP/IDENT, SPI Firewall, Portscan restriction l...

  • Page 13: Configuration Introduction

    Gigarouter UF72N User Manual 3 Configuration Introduction 3.1 Login The Web interface is ready for accessing about one minute after the device power on. The default LAN IP address is 192.168.100.1, you can access the Web interface via either WAN port or LAN port.

  • Page 14: Network Configuration

    Gigarouter UF72N User Manual 3.3 Network Configuration 3.3.1 Network Status The Status page shows all WAN and LAN interfaces configuration, and all physical ports connection status related to this device. 3.3.1.1 WAN Status Choose the menu Network→Status→WAN to load the following page. Figure 3-3 WAN Status 3.3.1.2...
  • Page 15 Gigarouter UF72N User Manual Choose the menu Network→WAN to load the configuration show page. Figure 3-6 WAN page Select an Interface Name to load the configuration page. 1) Static IP If a static IP address has been provided by your ISP, please choose the Static IP connection type to configure the parameters for WAN port manually.
  • Page 16 Gigarouter UF72N User Manual Gateway: Optional. Enter the Gateway assigned by your ISP. ► 2) DHCP If your ISP (Internet Service Provider) assigns the IP address automatically, please choose the DHCP connection type to obtain the parameters for WAN port automatically. Figure 3-8 WAN-DHCP The following items are displayed on this screen:...
  • Page 17 Gigarouter UF72N User Manual ► Device Type: Optional. ► Device Version: Optional. 3) PPPoE If your ISP (Internet Service Provider) has provided the account information for the PPPoE connection, please choose the PPPoE connection type (Used mainly for DSL Internet service). Figure 3-9 WAN-PPPoE The following items are displayed on this screen:...
  • Page 18 Gigarouter UF72N User Manual echo-requests are send without receiving a valid LCP echo-reply. 4) L2TP If your ISP (Internet Service Provider) has provided the account information for the L2TP connection, please choose the L2TP connection type. Figure 3-10 WAN-L2TP The following items are displayed on this screen: Enable: Enable this WAN interface (DATA can’t be disabled).
  • Page 19 Gigarouter UF72N User Manual Netmask: If Static IP is selected, configure the subnet mask of WAN port. ► Gateway: Optional. If Static IP is selected, configure the default gateway of WAN port. ► If DHCP is selected: Appoint Server IP: Optional.

  • Page 20: Lan Configuration

    Gigarouter UF72N User Manual Enable: Enable this WAN interface (DATA can’t be disabled). ► Type: Select PPTP if your ISP provides a PPTP connection. ► VLAN Enable: Optional. Enable VLAN to configure VLAN ID and VLAN Priority Level. ► VLAN ID: Optional.
  • Page 21 Gigarouter UF72N User Manual Figure 3-12 LAN page 1) Part 1: Configure LAN interfaces Click the Interface Name of existent LAN interface you want to modify. If you want to delete the entry, select it and click the Del (the VLAN1 is default existed, can’t be removed). Click the Add button to add a new entry.
  • Page 22 Gigarouter UF72N User Manual Figure 3-13 Configure LAN Interface The following items are displayed on this part. ► Interface Name: Name of this LAN interface. ► IP Address: Enter the IP address for this LAN interface. ► Netmask: Enter the subnet mask for this LAN interface. ►...

  • Page 23: Wlan

    Gigarouter UF72N User Manual Choose the menu Network→LAN→Advanced Parameters to load this page. The following items are displayed on this part. ► LAN Isolate: Check the box to prohibit the access between LAN interfaces. ► Auto Bridge: Check the box to dynamically create IPTV bridge for STB. ►...
  • Page 24 Gigarouter UF72N User Manual ► Channel Width: Select any channel width from the drop-down list. The default setting is automatic, which can automatically adjust the channel width for your clients. If you choose to 11n or 11b/g/n Wireless mode, this configuration is required. Two values of width are provided: 20MHz and 20/40MHz.
  • Page 25 Gigarouter UF72N User Manual you can select either TKIP, or AES or TKIP/AES as Encryption. When WPA-PSK is set as the Authentication Type, you can select either TKIP or AES as Encryption. ► WPA Pre-Shared Key: You can enter ASCII characters between 8 and 64 characters. ►...
  • Page 26 Gigarouter UF72N User Manual Figure 3-17 Configure WIFI WPA Security The following items are displayed on this screen: ► SSID: The SSID enabled in WLAN→Basic Settings page.Read only ► Authentication: The authentication type selected: WPA, WPA2, WPA/WPA2. ► Algorithm: You can select either TKIP, or AES or TKIP/AES. ►...
  • Page 27 Gigarouter UF72N User Manual If PIN mode is selected, the following page is loaded. Figure 3-18 Configure WIFI WPS-PIN The following items are displayed on this screen: ► Enable WPS: Enable or disable the WIFI WPS function globally. ► WPS Mode: Choose the WPS mode: PIN.
  • Page 28 Gigarouter UF72N User Manual Figure 3-20 Configure WIFI Advanced Settings The following items are displayed on this screen: ► Fragmentation Threshold: This value is the maximum size determining whether packets will be fragmented. Setting the Fragmentation Threshold too low may result in poor network performance since excessive packets.
  • Page 29 Gigarouter UF72N User Manual Figure 3-22 View Wifi MAC Filtering The following items are displayed on this screen: ► MAC Filtering: Enable or disable the Wifi MAC filtering function globally. ► Filtering Rules: Two MAC filtering rules are provided: Allow: allow the stations specified by entries in the list to access. Deny: deny the stations specified by entries in the list to access.

  • Page 30: Modem

    Gigarouter UF72N User Manual 3.3.5 3G Modem Typically, 3G Modem WAN is used as uplink port as a backup. When inserting 3G Modem into USB port, the system recognized the SIM card and charges no problem. After dialing successful, 3G Modem will serve as a backup uplink usage.
  • Page 31 Gigarouter UF72N User Manual Figure 3-25 Configure 3G Modem-Advanced Parameters The following items are displayed on this screen: ► Authentication: 3G dial-up authentication, CHAP,PAP,Auto are provided. Default is Auto. ► DNS: The default is obtained from the dial-up network devices automatically. You can also configure DNS manually.

  • Page 32: Port Management

    Gigarouter UF72N User Manual 3.3.6 Port Management 3.3.6.1 Port Mirror Port Mirror, the packets obtaining technology, functions to forward copies of packets from one/multiple ports (mirrored port) to a specific port (mirroring port). Usually, the mirroring port is connected to a data diagnose device, which is used to analyze the mirrored packets for monitoring and troubleshooting the network.

  • Page 33: Ipv6 Configuration

    Gigarouter UF72N User Manual Figure 3-28 Media Type The following items are displayed on this screen: ► Media Type: provides the following six modes to all physical ports: 10M Half Duplex, 10M Full Duplex, 100M Half Duplex, 100M Full Duplex, 1000M Full Duplex, Auto-Negotiation.

  • Page 34: Data Service

    Gigarouter UF72N User Manual DNS manually. ► Enable DHCP-PD: Whether to enable DHCP-PD(prefix delegation) on WAN. LAN Configuration ► Enable LAN: If IPv6 or IPv4/v6 is choseN, select this to enable IPv6 stack on LAN. ► Link-Local Address: Select type of Link-Local address: Auto or Manual. If Manual is selected, you should specify address manually.
  • Page 35 Gigarouter UF72N User Manual Figure 3-31 ARP Table 3.4.1.3 Route Table Choose the menu Data Service→Status→Route Table to load the following page. Figure 3-32 Route Table 3.4.1.4 Net State Choose the menu Data Service→Status→Net State to load the following page. Page 27 of 203...

  • Page 36: Dhcp Server

    Gigarouter UF72N User Manual Figure 3-33 Net State 3.4.2 DHCP Server 3.4.2.1 Static Address Assign Choose the menu Data Service→DHCP Server→Static Address Assign, and then you can view and add address which is assigned for clients. When you specify a static IP address for a client on the LAN, that client will always receive the same IP address each time when it accesses the DHCP server.
  • Page 37 Gigarouter UF72N User Manual Figure 3-35 Add or Modify An Static Address Assign Entry The following items are displayed on this screen: Client IP Addres: The IP address reserved. ► Client Mask: The subnet mask of IP address reserved. ► Client MAC: The MAC address you want to reserve IP address.

  • Page 38: Nat Config

    Gigarouter UF72N User Manual Figure 3-37 DHCP Relay Overview Choose the menu Data Service→DHCP Server→DHCP Relay to load the following page. Figure 3-38 Configure DHCP Relay The following items are displayed on this screen: Enable DHCP Relay: Enable or disable DHCP Relay. ►...
  • Page 39 Gigarouter UF72N User Manual Figure 3-39 Basic Settings The following items are displayed on this screen: Max Nat Connections: Specify the maximum number of NAT connections. ► Enable MSS Auto Adaptive: Enable or disable auto adaptive the value of MSS(Maximum Segment ►...
  • Page 40 Gigarouter UF72N User Manual Figure 3-41 Add or Modify PAT Entry The following items are displayed on this screen: Enable: Enable or disable this PAT entry. ► Internet Port: Enter the service port provided for accessing external network. All the requests ►...

  • Page 41: Firewall Config

    Gigarouter UF72N User Manual DMZ Public IP: The public IP address for this DMZ entry. ► DMZ Private IP: The private IP address for this DMZ entry. ► Description: Enter a description string for this DMZ entry ► 3.4.3.4 ALG Settings Application Layer Gateway (ALG) allows customized Network Address Translation (NAT) traversal filters to be plugged into the gateway to support address and port translation for certain application layer "control/data"...
  • Page 42 Gigarouter UF72N User Manual Figure 3-45 Attack Defense The following items are displayed on this screen: Enable Broadcast Storm Defense: Enable or disable Broadcast Storm Defense. ► Enable Block Ping: Enable or disable Block Ping function. ► Enable TCP SYN Flood Defense: Enable or disable TCP SYN Flood Defense.
  • Page 43 Gigarouter UF72N User Manual intended victim's spoofed source IP address. Check the box to enable Fraggle Defense. Enable Smurf Defense: The Smurf Attack is a denial-of-service attack in which large ► numbers of Internet Control Message Protocol (ICMP) packets with the intended victim's spoofed source IP are broadcast to a computer network using an IP Broadcast address.
  • Page 44 Gigarouter UF72N User Manual Figure 3-48 View Access Control Entry The following items are displayed on this screen: Enable Access Control: Enable or disable access control from WAN. ► Policy: Default policy of access control: Allow or Deny. If Allow is selected, all ►...
  • Page 45 Gigarouter UF72N User Manual 3.4.4.3.2 User Authentication This sub-page is used to control Internet access through username and password. Choose the menu Data Service→Firewall Config→Internet Access-Ctrl→User Authentication to load the following page. Figure 3-50 View User Authentication Entry The following items are displayed on this screen: Enable User Authentication: Enable or disable user authentication globally.
  • Page 46 Gigarouter UF72N User Manual 3.4.4.3.3 Page Push HTTP Page push is a mechanism for sending unsolicited (asynchronous) data from web server to a web browser. When accessing the Internet for the first time, the specified HTTP page will be pushed to the browser when enabled.
  • Page 47 Gigarouter UF72N User Manual HTTPS Port: Port used with HTTPS access device. ► HTTPS: it is the result of simply layering the Hypertext Transfer Protocol (HTTP) on top of the SSL/TLS protocol. Internet Web Access: Allow Access: If enabled, allow user to access the device from the Internet via WEB. ►...
  • Page 48 Gigarouter UF72N User Manual device from the Internet via telnet. IPv6 Range: If IP Limit enabled, specifies the IPv6 address range that only allow access to the ► device from the Internet via telnet. Intranet Web Access: Allow Access: If enabled, allow access to the device from the Intranet via telnet. ►...
  • Page 49 Gigarouter UF72N User Manual IP Range: If IP Limit enabled, specifies the IPv4 address range that only allow access to the ► device from the Intranet via SSH. IPv6 Range: If IP Limit enabled, specifies the IPv6 address range that only allow access to the ►...
  • Page 50 Gigarouter UF72N User Manual Figure 3-57 Configure IP Filter The following items are displayed on this screen: IP Filter: If enabled, packet filtering is enabled by IP address. ► Policy: The policy for IP address list. Deny and Allow. ► You can export all the IP addresses as a file.
  • Page 51 Gigarouter UF72N User Manual Using Studying MAC: You can choose one or more MAC devices learned. Figure 3-59 Add a MAC Filter Entry 3.4.4.6 IP&MAC Binding Choose the menu Data Service→Firewall Config→IP&MAC Binding to load the following page. There are two ways to add a binding entry: You can manually enter a pair of IP and MAC, and then press Add Item.

  • Page 52: Qos

    Gigarouter UF72N User Manual 3.4.5 3.4.5.1 Basic Settings QOS feature is enabled by default, based on 802.1P, strict priority scheduling mode. The device supports four priority queues, when QOS feature enabled. Choose the menu Data Service→QoS→Basic Settings to load the following page. Figure 3-61 Configure QoS Basic Settings The following items are displayed on this screen: Global Parameters...
  • Page 53 Gigarouter UF72N User Manual Bandwidth Setting Upstream Bandwidth: Configure the bandwidth of upstream. ► Downstream Bandwidth: Configure the bandwidth of downstream. ► Advanced Parameters Enable Voice Reservation: Enable voice reservation and give the value to reserved for voice ► Enable Video Reservation: Enable video reservation and give the value to reserved for video ►...
  • Page 54 Gigarouter UF72N User Manual Figure 3-63 View QoS Flow Rate Limit Entry Click the Index in the entry you want to modify. If you want to delete the entry, select it and click the Del. Click the Add button to add a new entry. Figure 3-64 Configure Qos Flow Rate Limit The following items are displayed on this screen: IP Range:...
  • Page 55 Gigarouter UF72N User Manual Figure 3-65 Configure Custom of Qos Flow Rate Limit The following items are displayed on this screen: Protocol Type: Custom protocol type, UDP or TCP. ► Port Range: Set port range. ► 3.4.5.4 Service The device supports to remap scheduling priority and remark the value of DSCP or 802.1P according to the service type.
  • Page 56 Gigarouter UF72N User Manual Click the Del in the entry you want to delete. Click the Index or Detail in the entry you want to modify, and then the following page will be loaded: Figure 3-68 Modify Qos ACL The following items are display on this page: Condition: ►...

  • Page 57: Ddns

    Gigarouter UF72N User Manual If L2 Data is selected: Figure 3-70 L2 Data Rule Type The following items are display on this page: ► SRC MAC: Source MAC address of packets. ► DEST MAC: Destination MAC address of packets. ► Ether Type: The ether type of packets.
  • Page 58 Gigarouter UF72N User Manual Figure 3-71 Configure DDNS The following items are display on this page: ► DDNS Enable: Active or inactive dynamic DNS service. ► Username: Enter account name of your DDNS account. ► Password: Enter password of your DDNS account. ►...

  • Page 59: Vpn

    Gigarouter UF72N User Manual 3.4.7 VPN (Virtual Private Network) is a private network established via the public network, generally via the Internet. However, the private network is a logical network without any physical network lines, so it is called Virtual Private Network. With the wide application of the Internet, more and more data are needed to be shared through the Internet.
  • Page 60 Gigarouter UF72N User Manual Figure 3-74 Configure PPTP Server The following items are displayed on this screen: Enable PPTP Server: Enable or disable the PPTP server function globally. ► IP Address Pool Range: Specify the start and the end IP address for IP Pool. The start IP address ►...
  • Page 61 Gigarouter UF72N User Manual Figure 3-76 Configure L2TP Server The following items are displayed on this screen: Enable L2TP Server: Enable or disable the L2TP server function globally. ► Local IP: Enter the local IP address of L2TP server. ► IP Address Pool Range: Specify the start and the end IP address for IP Pool.
  • Page 62 Gigarouter UF72N User Manual 3.4.7.4 IPSEC IPSEC (IP Security) is a set of services and protocols defined by IETF (Internet Engineering Task Force) to provide high security for IP packets and prevent attacks. To ensure a secured communication, the two IPSEC peers use IPSEC protocol to negotiate the data encryption algorithm and the security protocols for checking the integrity of the transmission data, and exchange the key to data de-encryption.
  • Page 63 Gigarouter UF72N User Manual Figure 3-79 Add or Modify IKE Safety Proposal Entry The following items are displayed on this screen: Proposal Name: Specify a unique name to the IKE proposal for identification and management ► purposes. The IKE proposal can be applied to IPSEC proposal. Encryption Algorithm: Specify the encryption algorithm for IKE negotiation.
  • Page 64 Gigarouter UF72N User Manual Figure 3-81 Add or Modify IKE Safety Policy Entry The following items are displayed on this screen: Policy Name: Specify a unique name to the IKE policy for identification and management ► purposes. The IKE policy can be applied to IPSEC policy. Operation Mode: Select the IKE Exchange Mode in phase 1, and ensure the remote VPN ►...
  • Page 65 Gigarouter UF72N User Manual Figure 3-82 View IPSEC Safety Proposal Configuration Click the Index in the entry you want to modify. If you want to delete the entry, select it and click the Del. Click the Add button to add a new entry. Figure 3-83 Add or Modify IPSEC Safety Proposal Entry The following items are displayed on this screen: Proposal Name:...
  • Page 66 Gigarouter UF72N User Manual Figure 3-84 View IPSEC Safety Policy Configuration Click the Index in the entry you want to modify. If you want to delete the entry, select it and click the Del. Click the Add button to add a new entry. Figure 3-85 Add or Modify IPSEC Safety Policy Entry The following items are displayed on this screen: Enable Ipsec:...

  • Page 67: Routing

    Gigarouter UF72N User Manual four IPSEC Proposals can be selected. 3.4.8 Routing 3.4.8.1 Static Route 3.4.8.1.1 IPv4 Choose the menu Data Service→Routing→Static Route→IPv4 to load the following page. Figure 3-86 Configure IPv4 Static Route The following items are displayed on this screen: ►...
  • Page 68 Gigarouter UF72N User Manual Figure 3-87 Configure IPv6 Static Route The configuration options of Ipv6 is similar to Ipv4, the prefix length is equal to mask of Ipv4 address. 3.4.8.2 Policy Route Choose the menu Data Service→Route→Policy Route to load the following page. Figure 3-88 View Policy Route Click the Index in the entry you want to modify.
  • Page 69 Gigarouter UF72N User Manual ► Enable PoliceRoute: Enable or disable the entry ► Next Hop Type: Select from pull-down list: Interface, Address. ► Interface: Specify the interface of next hop for the entry. ► Address: Specify the address of next hop for the entry. ►...

  • Page 70: Advanced Parameters

    Gigarouter UF72N User Manual ► Receive RIP Version: Specify receiving RIP version for the entry. ► Send RIP Version: Specify sending RIP version for the entry. ► Authorization Enable: Check the box to enable authorization. ► Key Mode: Specify the encryption mode of key, TEXT(plaintext),MD5(cipertext). ►...

  • Page 71: Multicast

    Gigarouter UF72N User Manual Listening to favorite tunes throughout the house • The Digital Living Network Alliance (DLNA) is a non-profit collaborative trade organization established by Sony in June 2003, which is responsible for defining interoperability guidelines to enable sharing of digital media between multimedia devices. DLNA uses UPnP for media management, discovery and control.
  • Page 72 Gigarouter UF72N User Manual Figure 3-96 View User Management Configuration Click the Index in the entry you want to modify. If you want to delete the entry, select it and click the Del. Click the Add button to add a new entry. Figure 3-97 Add or Modify User Management Entry The following items are displayed on this screen: Username:...

  • Page 73: Voip Service

    Gigarouter UF72N User Manual Share Name: Enter the share name. ► Allowed User: Select the users need to access the partition of the entry. ► 3.5 VOIP Service The Session Initiation Protocol (SIP) is a signaling protocol used for establishing sessions in an IP network.
  • Page 74 Gigarouter UF72N User Manual message. ► RTP Port: Local RTP port range. ► Local SIP Port: Local listening port. Click +Advanced Parameters to load the following page. Figure 3-101 Configure Advanced Parameters of SIP Service The following items are displayed on this screen: ►...

  • Page 75: User

    Gigarouter UF72N User Manual ► Support Full Register: Each registration packets are generated, rather than re-issued. ► First Package With Auth Info: The first registration packet with authentication information. ► SDP With Audio When T38 Faxing: T38 fax signaling packet with audio information. 3.5.2 User 3.5.2.1...

  • Page 76: Supplementary

    Gigarouter UF72N User Manual Figure 3-104 Wildcard Group Configuration Click the Wildcard Group in the entry you want to modify. If you want to delete the entry, select it and click the Del. Click the Add button to add a new entry. Figure 3-105 Add or Modify Wildcard Group Configuration The following items are displayed on this screen: ►...
  • Page 77 Gigarouter UF72N User Manual Figure 3-107 Modify Supplementary Configuration The following items are displayed on this screen: ► Call Forwarding Unconditional: Enable or disable CFU function, if enabled, enter Call Number. 1) Set by keypad service system: *57*TN#, TN is the phone number to be redirected to.
  • Page 78 Gigarouter UF72N User Manual instant hotline. ► Delay Time: Time 0 indicates immediate Hotline, Otherwise, indicates delay Hotline. The Delay Time must be configured on the WEB. ► CID Restriction: Enable or disable CID Restriction. If Anonymous As UserName is chosen, user name content is Anonymous also.

  • Page 79: Codec Parameters

    Gigarouter UF72N User Manual Click the Information in the entry you want to modify. If you want to delete the entry, select it and click the Del. Click the Add button to add a new entry. Figure 3-111 Add or Modify Black&White List Entry The following items are displayed on this screen: ►...

  • Page 80: Dsp Parameters

    Gigarouter UF72N User Manual Figure 3-114 Add or Modify Fax Mode&Codec Priority The following items are displayed on this screen: ► Fax Mode: Choose fax mode, three types are provided: Transparent, T38, VBD. ► Codec Answer Strategy: Two modes are provided: Use Answerer Priority: Codec selection decisions based on the priority level configuration Use Offerer Priority:...

  • Page 81: Digitmap

    Gigarouter UF72N User Manual ► Delay Level: Choose the delay level, five levels are provided: Minimum, Smaller, Moderate, Larger, Maximum. ► DTMF Transfer Model: Select DTMF transmission mode: In-Band, INFO, RFC2833. ► RFC2833 Load Type: If RFC2833 is selected, specify payload type of RFC2833. ►...

  • Page 82: Signal Tone

    Gigarouter UF72N User Manual l “[0-9*#].T” denotes any number that dialing time out. Choose the menu VOIP Service→Digitmap to load the following page. Figure 3-116 Configure Digitmap The following items are displayed on this screen: ► Enable: Enable or disable digit map function. ►...

  • Page 83: Fxs Parameters

    Gigarouter UF72N User Manual Figure 3-117 Configure Signal Tone The following items are displayed on this screen: ► Tone Type: Select the type of signal tone. Dial Tone ► User Define Enable: Whether to use user-defined dial tone frequency. ► Dial Tone Frequency 1: ►...

  • Page 84: Centrex

    Gigarouter UF72N User Manual Figure 3-118 Configure FXS Parameters The following items are displayed on this screen: ► Min Flash Detect Time: The minimum time to detect the flash. ► Max Flash Detect Time: The maximum time to detect the flash. ►...
  • Page 85 Gigarouter UF72N User Manual Figure 3-119 Centrex&Ring Group Configuration The following items are displayed on this screen: ► Enable Centrex: Whether to enable centrex function globally. A hunt group is a collection of extensions that ring in a particular order when the hunt group number is dialed.

  • Page 86: Phone Book

    Gigarouter UF72N User Manual The following items are displayed on this screen: ► Telephone Number: The number will be added to the ring group. 3.5.10 Phone Book Choose the menu VOIP Service→Phone Book to load the following page. Figure 3-122 Configure Phone Book Click the Index in the entry you want to modify.
  • Page 87 Gigarouter UF72N User Manual Figure 3-123 Time Manual Configuration The following items are displayed on this screen: Configuration mode: Specify configuration mode of time, Auto Configuration or Manual ► Configuration, default is Manual Configuration. System Time: Enter the system time under Manual Configuration. ►...

  • Page 88: Upgrade

    Gigarouter UF72N User Manual Figure 3-124 Time Auto Configuration The following items are displayed on this screen: Enable NTP: Enable or disable NTP service. ► NTP Service Mode: Specify CPE role as NTP Client or both Client and Server. ► Primary NTP Server: Specify the primary NTP server for role as NTP client.

  • Page 89: Reboot System

    Gigarouter UF72N User Manual Web interface configuration index: SystemàUpgradeà( Configuration). 3.6.3 Reboot System Choose menu“System à Reboot”, then click Reboot button to reset the device. 3.6.4 Backup/Restore Choose the menu System→Backup/Restore to load the following page. Figure 3-125 Backup/Restore Configurations The following items are displayed on this screen: Backup Current Configurations: Save current parameters as customer default parameters.
  • Page 90 Gigarouter UF72N User Manual ► Ping Count: Specifies the number of Echo Request messages sent. ► Result: This page displays the result of diagnosis. Click Start button to check the connectivity of the Internet. Click Stop button to stop sending the Echo Request messages. Click Refresh button to refresh the web page.

  • Page 91: User Management

    Gigarouter UF72N User Manual The following items are displayed on this screen: ► Download URL: Enter the URL to test the download speed of WAN. For example http://speedtest1.szunicom.com/speedtest/random1000x1000.jpg ► Upload URL: Enter the URL to test the upload speed of WAN. For example http://speedtest1.szunicom.com/speedtest/random2000x2000.jpg Click the Start button to starting test.

  • Page 92: Tr069

    Gigarouter UF72N User Manual ► Log Level: By selecting the log level, only logs of this level will be shown. ► Log Content: By selecting the log content, only logs of selected content will be shown. ► Local Log Enable: Check this box to enable local log function.
  • Page 93 Gigarouter UF72N User Manual Figure 3-132 Configure TR069 The following items are displayed on this screen: ► Serial Number: The serial number of device. Read only. ► Enable: Enable or disable the TR069 function globally. ► ACS Address: Enter the IP address or domain name of ACS. ►...

  • Page 94: Snmp

    Gigarouter UF72N User Manual ► CPE Server Name: A part of the HTTP URL for an ACS to make a Connection Request notification to the CPE. In the form:http://host:port/path ► CPE Port: A part of the HTTP URL for an ACS to make a Connection Request notification to the CPE.

  • Page 95: User Access Right

    Gigarouter UF72N User Manual 3.6.10 User Access Right If the permission level of login user is super, you can see this web page. On this page, you can change the access right of the user to access the web pages. Choose the menu System→User Access Right to load the following page.

  • Page 96: Apply

    Gigarouter UF72N User Manual Figure 3-135 Modify User Access Right 3.7 Apply Follow the prompts,Some parameters will take effect after click the button of “Apply”. Figure 3-136 Apply 3.8 Print Function The device supports to link printer port and provides share printing capabilities to other computers. To use print function, you need do the following steps.
  • Page 97 Gigarouter UF72N User Manual Figure 3-137 Add Printer Connecting local printer Select "Local printer attached to this computer." Page 89 of 203...
  • Page 98 Gigarouter UF72N User Manual Figure 3-138 Connecting local printer Create a new port Select "Create a new port" and select "Standard TCP / IP Port" Figure 3-139 Create a new port Add print device Click Next, and add IP devices, assuming the device IP is 192.168.1.1. Page 90 of 203...
  • Page 99 Gigarouter UF72N User Manual Figure 3-140 Add IP LAN devices Configure printer port Select "Custom", click "Settings" to confirm the agreement as "RAW (R)" Page 91 of 203...
  • Page 100 Gigarouter UF72N User Manual Figure 3-141 Configuer printer port Add Printer Driver According to the printer manufacturer and printer type, select the appropriate driver. If the computer has not printer driver, you need to install the printer driver. After adding the printer, you can print through the USB printer. Page 92 of 203...
  • Page 101 Gigarouter UF72N User Manual Figure 3-142 Add Printer Driver Page 93 of 203...

  • Page 102: Cli Introduction

    Gigarouter UF72N User Manual 4 CLI Introduction 4.1 Login The CLI interface is ready for accessing about one minute after the device powers on. The default LAN IP address is 192.168.100.1, you can access the CLI interface via either WAN port or LAN port. Enter telnet with IP address and then press ENTER, you can get access to the Login interface.

  • Page 103: Network

    Gigarouter UF72N User Manual Input the command “set language” to set the CLI language: Figure 4-3 Set CLI Language Network 4.2.1 3G Modem The command “show 3gmodem” show the 3G modem information as below: Figure 4-4 Show 3G Modem Information The command “set 3gmodem”...
  • Page 104 Gigarouter UF72N User Manual Figure 4-5 Configure 3G Modem Parameters The following items are displayed on this screen: ► SP Network: Other or Swisscom. If it is not the target user, you need to select the other. ► Connect Mode: Manual or Auto.

  • Page 105: Port Management

    Gigarouter UF72N User Manual Figure 4-6 Show 3G Modem Status The following items are displayed on this screen: ► Device Status: Indicates whether to insert 3G module. ► SIM Card Status: Indicates whether to insert 3G modem in the SIM card, the ready state means the SIM card is detected.

  • Page 106: Wan Parameter

    Gigarouter UF72N User Manual Figure 4-9 Show Port Status Information The command “show port media-type” show the port media type information as below: Figure 4-10 Show Port Media Type Information The command “set port media-type” configure the port media type parameters as below. Figure 4-11 Configure Port Media Type Parameters The following items are displayed on this screen: ►...
  • Page 107 Gigarouter UF72N User Manual The command “show wan” show the WAN interface configuration as below: Figure 4-12 Show Wan Parameter The wan interfaces include DATA、VOICE、MGMT、OTHER1 and OTHER2. Input “1” to show DATA parameter as below: Figure 4-13 Show DATA Interface Parameter Input “2”...
  • Page 108 Gigarouter UF72N User Manual Figure 4-14 Show VOICE Interface Parameter Input “3” to show MGMT parameter as below: Figure 4-15 Show MGMT Interface Parameter Page 100 of 203...
  • Page 109 Gigarouter UF72N User Manual Input “4” to show OTHER1 parameter as below: Figure 4-16 Show OTHER1 Interface Parameter Input “5” to show OTHER2 parameter as below: Page 101 of 203...
  • Page 110 Gigarouter UF72N User Manual Figure 4-17 Show OTHER2 Interface Parameter 4.2.3.2 Configure Wan Parameter The command “set wan” configure the wan interface parameter as below: Figure 4-18 Configure WAN Parameter The wan interfaces include DATA、VOICE、MGMT、OTHER1 and OTHER2. Input “1” to configure DATA parameter as below: Page 102 of 203...
  • Page 111 Gigarouter UF72N User Manual Figure 4-19 Configure DATA Interface Parameter The following items are displayed on this screen: Enable: Enable this WAN interface (DATA can’t be disabled). ► Type: Select PPPoE if your ISP provides xDSL Virtual Dial-up connection. ► VLAN Enable: Optional.
  • Page 112 Gigarouter UF72N User Manual Figure 4-20 Configure VOICE Interface Parameter The following items are displayed on this screen: Enable: Enable this WAN interface (DATA can’t be disabled). ► Type: Select Static IP if your ISP has assigned a static IP address for your. ►...
  • Page 113 Gigarouter UF72N User Manual Figure 4-21 Configure MGMT Interface Parameter The following items are displayed on this screen: Enable: Enable this WAN interface (DATA can’t be disabled). ► Type: Select DHCP if your ISP assigns the IP address automatically. ► VLAN Enable: Optional.
  • Page 114 Gigarouter UF72N User Manual Figure 4-22 Configure OTHER1 Interface Parameter The following items are displayed on this screen: Enable: Enable this WAN interface (DATA can’t be disabled). ► Type: Select PPTP if your ISP provides a PPTP connection. ► VLAN Enable: Optional.
  • Page 115 Gigarouter UF72N User Manual Gateway: Optional. If Static IP is selected, configure the default gateway of WAN port. ► If DHCP is selected: Appoint Server IP: Optional. If network has multiple DHCP servers, enter the IP address of your ► ISP’s DHCP server.

  • Page 116: Lan Parameter

    Gigarouter UF72N User Manual you are not clear, please consult your ISP. It’s not allowed to access the Internet via domain name if the Primary DNS field is blank. Secondary DNS: Optional. If a Secondary DNS Server address is available, enter it. ►...
  • Page 117 Gigarouter UF72N User Manual Figure 4-25 Show Static IP Parameter Input “2” to show binding IP configuration as below: Figure 4-26 Show Binding IP Parameter Page 109 of 203...
  • Page 118 Gigarouter UF72N User Manual Input “3” to show port route/bridge mode as below: Figure 4-27 Show Port Mode Parameter Input “4” to show advanced parameters as below: Figure 4-28 Show Advanced Parameter 4.2.4.2 Configure Lan Parameter The command “set lan” configure the LAN parameter as below: Figure 4-29 Configure LAN Parameter Input “1”...
  • Page 119 Gigarouter UF72N User Manual Figure 4-30 Configure Static IP Parameter The following items are displayed on this part. ► Interface Name: Name of this LAN interface. ► IP Address: Enter the IP address for this LAN interface. ► Netmask: Enter the subnet mask for this LAN interface. ►...
  • Page 120 Gigarouter UF72N User Manual ► Gateway: Optional .If Enable DHCP Server is selected, enter the Gateway address to be assigned. ► Primary DNS: Optional. If Enable DHCP Server is selected, enter the Primary DNS server address to be assigned. ► Secondary DNS: Optional.
  • Page 121 Gigarouter UF72N User Manual Figure 4-32 Configure Port Mode Parameter The following items are displayed on this part. ► Port: The physical LAN port name (LAN1~LAN4). ► Route/Bridge: Mode of this physical LAN port. The following four modes are provided: Route: route to WAN Transparent bridge: not modify the packets;...
  • Page 122 Gigarouter UF72N User Manual Figure 4-33 Configure Advanced Parameter The following items are displayed on this part. ► LAN Isolate: Check the box to prohibit the access between LAN interfaces. ► Auto Bridge: Check the box to dynamically create IPTV bridge for STB. ►...
  • Page 123 Gigarouter UF72N User Manual Figure 4-35 Show Basic Settings Input “2” to show security configuration as below: Figure 4-36 Show Security Parameter Page 115 of 203...
  • Page 124 Gigarouter UF72N User Manual Input “3” to show advanced settings as below: Figure 4-37 Show Advanced Settings Input “4” to show client information as below: Figure 4-38 Show Client Information Input “5” to show WPS configuration as below: Figure 4-39 Show WPS Parameter Input “6”...
  • Page 125 Gigarouter UF72N User Manual Figure 4-40 Show MAC Filtering Parameter 4.2.5.2 Configure WLAN Parameter The command “set wlan” configure the WLAN parameter as below: Figure 4-41 Configure WLAN Parameter Input “1” to configure basic settings as below: Page 117 of 203...
  • Page 126 Gigarouter UF72N User Manual Figure 4-42 Configure Basic Settings The following items are displayed on this part. ► Enable WiFi: Enable or disable the WIFI AP function globally. ► Channel: This field determines which operating frequency will be used. The default channel is set to AutoSelect, so the AP will choose the best channel automatically.
  • Page 127 Gigarouter UF72N User Manual the air. ► Isolated: Enable or disable isolate different clients from the same wireless station. ► LAN Isolated: Enable or disable isolation between the LAN and SSID. ► Max Client: Enter the maximum number of clients allowed to connect to the SSID. ►...
  • Page 128 Gigarouter UF72N User Manual Figure 4-44 Configure Advanced Settings The following items are displayed on this part. ► Fragmentation Threshold: This value is the maximum size determining whether packets will be fragmented. Setting the Fragmentation Threshold too low may result in poor network performance since excessive packets.
  • Page 129 Gigarouter UF72N User Manual Input “4” to configure MAC filtering parameter as below: Page 121 of 203...

  • Page 130: Data Service

    Gigarouter UF72N User Manual Figure 4-46 Configure MAC Filtering Parameter The following items are displayed on this part. ► Enable MAC Filter: Enable or disable the Wifi MAC filtering function globally. ► Filtering Rules: Two MAC filtering rules are provided: Allow: allow the stations specified by entries in the list to access.
  • Page 131 Gigarouter UF72N User Manual Figure 4-48 Configure Static IP Assign The command will configure static ip assign. The following items are displayed on this screen: IP : The IP address reserved. ► Mask: The subnet mask of IP address reserved. ►...

  • Page 132: Nat Config

    Gigarouter UF72N User Manual 4.3.1.2 DHCP Relay The command “show dhcp-relay” shows the DHCP relay information as below: Figure 4-49 Show DHCP Relay Information The command "set dhcp-relay” configures the DHCP relay information as below: Figure 4-50 Set DHCP Relay Information The following items are displayed on this screen: Enable DHCP Relay: Enable or disable DHCP Relay.
  • Page 133 Gigarouter UF72N User Manual Figure 4-52 Configure NAT Basic Settings The following items are displayed on this screen: Max Nat Connections: Specify the maximum number of NAT connections. ► Enable MSS Auto Adaptive: Enable or disable auto adaptive the value of MSS (Maximum Segment ►...
  • Page 134 Gigarouter UF72N User Manual Figure 4-55 Configure PAT Rule The following items are displayed on this screen: Enable: Enable or disable this PAT entry. ► Internet Port: Enter the service port provided for accessing external network. All the requests ► from internet to this service port will be redirected to the specified server in local Page 126 of 203...
  • Page 135 Gigarouter UF72N User Manual network. Intranet Port: Specify the service port of the LAN host as virtual server. ► Intranet IP: Enter the IP address of the specified internal server for the entry. All the ► requests from the internet to the specified LAN port will be redirected to this host.
  • Page 136 Gigarouter UF72N User Manual Figure 4-58 Configure DMZ Rule The following items are displayed on this screen: Public IP: The public IP address for this DMZ entry. ► Private IP: The private IP address for this DMZ entry. ► 4.3.2.4 ALG Settings The command “show alg”...

  • Page 137: Firewall Config

    Gigarouter UF72N User Manual Figure 4-60 Configure ALG Parameters The following items are displayed on this screen: Enable SIP: Enable or disable SIP ALG. ► Enable H323: Allow Microsoft NetMeeting clients to communicate across NAT if selected. ► Enable FTP: Allow FTP clients and servers to transfer data across NAT if selected.
  • Page 138 Gigarouter UF72N User Manual Figure 4-62 Configure Attack Defense Parameters The following items are displayed on this screen: Enable Broadcast Storm Defense: Enable or disable Broadcast Storm Defense. ► Enable Block Ping: Enable or disable Block Ping function. ► Enable TCP SYN Flood Defense: Enable or disable TCP SYN Flood Defense.
  • Page 139 Gigarouter UF72N User Manual Enable Smurf Defense: The Smurf Attack is a denial-of-service attack in which large ► numbers of Internet Control Message Protocol (ICMP) packets with the intended victim's spoofed source IP are broadcast to a computer network using an IP Broadcast address. Check the box to enable Smurf Defense.
  • Page 140 Gigarouter UF72N User Manual Figure 4-64 Configure Service Type The following items are displayed on this screen: Name: Name of this entry, it will be list in Internet Access-Ctrl page. ► Protocol: Select the protocol for this entry. Four types are provided: TCP, UDP, ICMP and ALL. ►...
  • Page 141 Gigarouter UF72N User Manual Figure 4-65 Show Access Control Information The command “set access-control” configures the access control policy as below: Figure 4-66 Configure Access Control The following items are displayed on this screen: Enable Access Control: Enable or disable access control from WAN. ►...
  • Page 142 Gigarouter UF72N User Manual Page 134 of 203...
  • Page 143 Gigarouter UF72N User Manual Figure 4-67 Configure Access Control Rule The following items are displayed on this screen: Enable Rule: Enable or disable this rule. ► Source IP Range: Enter the source IP range in dotted-decimal format (e.g. 192.168.1.23). ► Destination IP Range: Enter the destination IP range in dotted-decimal format (e.g.
  • Page 144 Gigarouter UF72N User Manual The command “set user authentication list” configures the user authentication list as below. Enter 0 to add a new entry. Enter 2 and choose the entry you want to modify. If you want to delete the entry, enter 1 and choose the corresponding entry.
  • Page 145 Gigarouter UF72N User Manual Username: Enter the username of this entry. ► Password: Enter the password of this entry. ► Auth Mode: Choose the authentication mode of this entry. Provides four modes: ► Allow Multi-PC Access: Allows multiple computers to access the Internet using this account.
  • Page 146 Gigarouter UF72N User Manual Figure 4-72 Configure Web Access Control Parameters The following items are displayed on this screen: HTTP Port: Port used with HTTP access device. ► HTTP: Hypertext Transfer Protocol. HTTPS Port: Port used with HTTPS access device. ►...
  • Page 147 Gigarouter UF72N User Manual Figure 4-73 Show Telnet Access Control Information The command “set network-access-ctrl telnet” configures the telnet access control parameters as below: Figure 4-74 Configure Telnet Access Control Parameters The following items are displayed on this screen: Port: Port when using telnet tools access device.
  • Page 148 Gigarouter UF72N User Manual device from the Intranet via telnet. 4.3.3.4.3 The command “show network-access-ctrl ssh” shows the SSH access control information as below: Figure 4-75 Show SSH Access Control Information The command “set network-access-ctrl ssh” configures the SSH access control parameters as below: Figure 4-76 Configure SSH Access Control Parameters The following items are displayed on this screen: Port:...
  • Page 149 Gigarouter UF72N User Manual Allow Access: If enabled, allow access to the device from the Intranet via SSH. ► IP Limit: If enabled, allow only specific IP range to access the device from the Intranet via ► IP Range: If IP Limit enabled, specifies the IPv4 address range that only allow access to the ►...
  • Page 150 Gigarouter UF72N User Manual Figure 4-79 Configure Keyword Filter List The following items are displayed on this screen: Keyword Filter: If enabled, packet filtering is enabled by keyword. ► Policy: The policy for filtering web page, Deny and Allow. ► 4.3.3.5.2 IP Filter The command “show ip-filter”...
  • Page 151 Gigarouter UF72N User Manual Figure 4-81 Configure IP Filter Parameters The command “set ip-filter list” configures the IP filter list as below. Enter 0 to add a new entry. Enter 2 and choose the entry you want to modify. If you want to delete the entry, enter 1 and choose the corresponding entry.
  • Page 152 Gigarouter UF72N User Manual 4.3.3.5.3 MAC Filter The command “show mac-filter” shows the MAC filter information as below: Figure 4-83 Show MAC Filter Information The command “set mac-filter ” configures the MAC filter parameters as below: Figure 4-84 Configure IP Filter Parameters The command “set mac-filter list”...

  • Page 153: Qos

    Gigarouter UF72N User Manual Figure 4-85 Configure MAC Filter List The following items are displayed on this screen: MAC Filter: If enabled, packet filtering is enabled by MAC. ► Policy: The policy for MAC list. Deny and Allow. ► 4.3.4 4.3.4.1 Basic Settings The command “show qos basic-settings”...
  • Page 154 Gigarouter UF72N User Manual Figure 4-87 Configure QoS Basic Settings The following items are displayed on this screen: Qos Enable: Enable or disable QoS functionality. ► Scheduling Mode: PQ: PQ means strict priority, that is, when congestion occurs, first ► sending packets of high priority queue.
  • Page 155 Gigarouter UF72N User Manual Figure 4-88 Show Port Rate Limit Information The command “set qos port-limit” configures the port rate limit as below: Figure 4-89 Configure Port Rate Limit The following items are displayed on this screen: Port: Physical LAN port ►...
  • Page 156 Gigarouter UF72N User Manual Figure 4-90 Show Flow Rate Limit Information The command “set qos flow-limit” configures the flow rate limit as below. Enter 0 add a new entry. Enter 2 and choose the entry you want to modify. If you want to delete the entry, enter 1 and choose the corresponding entry.
  • Page 157 Gigarouter UF72N User Manual Page 149 of 203...
  • Page 158 Gigarouter UF72N User Manual Figure 4-91 Configure Flow Rate Limit The following items are displayed on this screen: IP Range: The IP range of LAN’s PC. ► Active Time: If not configured, which means that all time are in active ►...
  • Page 159 Gigarouter UF72N User Manual Limited Bandwidth(CIR): The limited bandwidth. ► Maximal Bandwidth(PIR): The maximum bandwidth. ► If Application is selected: Application Protocol: Such as HTTP, HTTPS, FTP, TFTP, SMTP, POP3, TELNET, etc. ► 4.3.4.4 Service The command “show qos service” shows the QoS service information as below: Figure 4-92 Show QoS Service Information The command “set qos service”...
  • Page 160 Gigarouter UF72N User Manual 4.3.4.5 The command “show qos acl-rule” shows the ACL rule information as below: Figure 4-94 Show ACL Rule Information The command “set qos acl-rule” configures the ACL rule as below: Figure 4-95 Configure ACL Rule The following items are displayed on this screen: ►...

  • Page 161: Ddns

    Gigarouter UF72N User Manual ► Ether Type: The ether type of packets. ► VLAN ID: The VLAN id of packets. ► 802.1p: The VLAN priority of packets. ► Drop: Drop the packets matched with the rule. ► Remark VID: Change the VID of packets matched with the rule. ►...

  • Page 162: Vpn

    Gigarouter UF72N User Manual Figure 4-98 Configure DDNS Parameters The following items are displayed on this screen: ► DDNS Enable: Active or inactive dynamic DNS service. ► Username: Enter account name of your DDNS account. ► Password: Enter password of your DDNS account. ►...
  • Page 163 Gigarouter UF72N User Manual Figure 4-99 Show PPTP Server Information The command “set pptp-server” configures the pptp server parameters as below: Figure 4-100 Configure PPTP Server Parameters The following items are displayed on this screen: Enable PPTP Server: Enable or disable the PPTP server function globally. ►...
  • Page 164 Gigarouter UF72N User Manual Figure 4-101 Configure PPTP Server User The following items are displayed on this screen: Username: Enter the account name of PPTP tunnel. It should be configured identically on server ► and client. Password: Enter the password of PPTP tunnel. It should be configured identically on server and ►...
  • Page 165 Gigarouter UF72N User Manual Figure 4-102 Show L2TP Server Information The command “set l2tp-server” configures the l2tp server parameters as below: Figure 4-103 Configure L2TP Server Parameters The following items are displayed on this screen: Enable L2TP Server: Enable or disable the L2TP server function globally. ►...
  • Page 166 Gigarouter UF72N User Manual Figure 4-104 Configure L2TP Server User The following items are displayed on this screen: Username: Enter the account name of L2TP tunnel. It should be configured identically on server ► and client. Password: Enter the password of L2TP tunnel. It should be configured identically on server and ►...
  • Page 167 Gigarouter UF72N User Manual 4.3.6.3 IPSEC 4.3.6.3.1 IKE Safety Proposal The command “show ike-proposal” shows the IKE Proposal information as below: Figure 4-105 Show IKE Proposal Information The command “set ike-proposal” configures the IKE Proposal as below. Enter 0 to add a new entry. Enter 2 and choose the entry you want to modify.
  • Page 168 Gigarouter UF72N User Manual Figure 4-106 Configure IKE Proposal The following items are displayed on this screen: Proposal Name: Specify a unique name to the IKE proposal for identification and management ► purposes. The IKE proposal can be applied to IPSEC proposal. Encryption Algorithm: Specify the encryption algorithm for IKE negotiation.
  • Page 169 Gigarouter UF72N User Manual Figure 4-107 Show IKE Policy Information The command “set ike-policy” configures the IKE Policy as below. Enter 0 add a new entry. Enter 2 and choose the entry you want to modify. If you want to delete the entry, enter 1 and choose the corresponding entry.
  • Page 170 Gigarouter UF72N User Manual Figure 4-108 Configure IKE Policy The following items are displayed on this screen: Policy Name: Specify a unique name to the IKE policy for identification and management ► purposes. The IKE policy can be applied to IPSEC policy. Operation Mode: Select the IKE Exchange Mode in phase 1, and ensure the remote VPN ►...
  • Page 171 Gigarouter UF72N User Manual Auth Mode: Select the authentication mode for this IKE policy entry. ► Pre Share Key: Enter the Pre-shared Key for IKE authentication, and ensure both the two ► peers use the same key. The key should consist of visible characters without blank space.
  • Page 172 Gigarouter UF72N User Manual Figure 4-110 Configure IPSEC Proposal The following items are displayed on this screen: Proposal Name: Specify a unique name to the IPSEC Proposal for identification and ► management purposes. The IPSEC proposal can be applied to IPSEC policy.
  • Page 173 Gigarouter UF72N User Manual Figure 4-111 Show IPSEC Policy Information The command “set ipsec-policy” configures the IPSEC Policy as below. Enter 0 to add a new entry. Enter 2 and choose the entry you want to modify. If you want to delete the entry, enter 1 and choose the corresponding entry.
  • Page 174 Gigarouter UF72N User Manual Figure 4-112 Configure IPSEC Policy The following items are displayed on this screen: Enable Ipsec: Enable or disable this IPSEC entry. ► IPSEC Policy Name: Specify a unique name to the IPSEC policy. ► Select Interface: Specify the local WAN port for this Policy.

  • Page 175: Routing

    Gigarouter UF72N User Manual Remote Subnet IP & Remote Subnet Netmask: Specify IP address range on your remote network ► to identify which PCs on the remote network are covered by this policy. IKE Safety Policy: Specify the IKE policy. ►...
  • Page 176 Gigarouter UF72N User Manual Figure 4-115 Show IPv6 Static Route Information The command “set static-route ipv6” configures the IPv6 static route as below. Figure 4-116 Configure IPv6 Static Route The configuration options of Ipv6 is similar to Ipv4, the prefix length is equal to mask of Ipv4 address. 4.3.7.2 Policy Route The command “show policy-route”...
  • Page 177 Gigarouter UF72N User Manual Figure 4-117 Show Policy Route Information The command “set policy-route” configure thes policy route as below. Enter 0 to add a new entry. Enter 2 and choose the entry you want to modify. If you want to delete the entry, enter 1 and choose the corresponding entry.
  • Page 178 Gigarouter UF72N User Manual Page 170 of 203...
  • Page 179 Gigarouter UF72N User Manual Figure 4-118 Configure Policy Route The following items are displayed on this screen: ► Enable PoliceRoute: Enable or disable the entry ► Next Hop Type: Select from pull-down list: Interface, Address. ► Interface: Specify the interface of next hop for the entry. ►...
  • Page 180 Gigarouter UF72N User Manual Figure 4-119 Show RIP Information The command “set rip switch” configures the RIP switch as below: Figure 4-120 Configure RIP Switch The following items are displayed on this page: ► Enable RIP Service: Enable or disable RIP service function globally. The command “set rip interface”...
  • Page 181 Gigarouter UF72N User Manual Figure 4-121 Configure RIP Interface The following items are displayed on this screen: ► Interface: Specify the interface for the entry. ► Receive RIP Version: Specify receiving RIP version for the entry. ► Send RIP Version: Specify sending RIP version for the entry.
  • Page 182 Gigarouter UF72N User Manual Page 174 of 203...

  • Page 183: Advanced Parameters

    Gigarouter UF72N User Manual Figure 4-122 Configure RIP Key Chain The following items are displayed on this screen: ► Key Chain Name: Enter the name of key chain. ► Key ID: Enter the ID of the entry. ► Key String: Enter the Key of the entry.

  • Page 184: Multicast

    Gigarouter UF72N User Manual Downstream Interface: The network interface connected to the DLNA client. ► 4.3.9 Multicast The command “show multicast” shows the multicast information as below: Figure 4-125 Show Multicast Information The command “set multicast” configures the multicast parameters as below. Figure 4-126 Configure Multicast Parameters The following items are displayed on this screen: Enable IGMP Proxy:...
  • Page 185 Gigarouter UF72N User Manual Figure 4-127 Show Sip Server Information Execute the command “set sip” to set the sip information as below: Figure 4-128 Configure Sip Server At first, the command will show the sip server information, and then begin to configure sip server. The following items are displayed on this screen: ►...
  • Page 186 Gigarouter UF72N User Manual Figure 4-129 Show Adavance Sip Information The command “set sipadvance” configures the advanced SIP information as below: Page 178 of 203...
  • Page 187 Gigarouter UF72N User Manual Figure 4-130 Configure Advance Sip Parameter The following items are displayed on this screen: ► Enable Keeping Alive: After successful registration, whether to send keep-alive packets. ► Keep Alive Mode: Keep alive mode: CLRF, OPTIONS or PING. ►...

  • Page 188: User

    Gigarouter UF72N User Manual 4.4.2 User 4.4.2.1 User The command “show sipuser” shows the sip user parameters as below: Figure 4-131 Show sip user Parameter The command “set sipuser” configures the sip parameter as below: Figure 4-132 Configure sip user Parameter The following items are displayed on this screen: ►...

  • Page 189: Supplementary

    Gigarouter UF72N User Manual ► Enable Register: Enable registering. 4.4.2.2 Wildcard Group The command “show groupregister” show wildcard group as below: Figure 4-133 Show Wildcard Group Parameter The command “set groupregister” sets wildcard group as below: Figure 4-134 Configure Wildcard Group Parameter 4.4.3 Supplementary The command “show extended-server”...
  • Page 190 Gigarouter UF72N User Manual Figure 4-135 Show User Supplementary The command “set extended-server” configures the user supplementary parameter as below: Page 182 of 203...
  • Page 191 Gigarouter UF72N User Manual Figure 4-136 Configure User Supplementary The following items are displayed on this screen: ► Min Flash Detect Time: The minimum time to detect the flash. ► Max Flash Detect Time: The maximum time to detect the flash. ►...
  • Page 192 Gigarouter UF72N User Manual to notify the user there is still a call on hold. ► (#)Quick Dial Key: Whether to send telephone number immediately after receiving the # key. ► Asterisk Func Key: Whether to use the ‘*’ key as flash key. ►...
  • Page 193 Gigarouter UF72N User Manual Figure 4-137 Show Abbreviated Number The command “set abbr-dial” sets the abbreviated number of the user as below: Figure 4-138 Configure Abbreviated Number The following items are displayed on this screen: ►0-add,1-delete,2-modify: Input “0” to add new abbreviated number item, input “1” to delete a abbreviated numbe from thelist, input “2”...
  • Page 194 Gigarouter UF72N User Manual abbreviated numbe from the list. ► Abbreviated Number: The abbreviated number. ► Phone Number: The Actual phone number. The command “show whiteblack-list” shows the white list and the black list of the user as below: Figure 4-139 Show White & Black List The command “set whiteblack-list”...

  • Page 195: Codec Parameters

    Gigarouter UF72N User Manual Figure 4-140 Configure White & Black List The following items are displayed on this screen: ► List Type: Choose type of Black&White List, four types are provided: Incoming Blacklist, Incoming Whitelist, Outgoing Blacklist, Outgoing Whitelist. ► Phone Number: the phone number or sip account.

  • Page 196: Dsp Parameters

    Gigarouter UF72N User Manual Figure 4-141 Show Codec Parameters The command “set codec” configures the codec parameters as below: Figure 4-142 Configure Codec Parameters ► G.711A Packet Period: RTP packetization period of G.711A codec. ► G.711u Packet Period: RTP packetization period of G.711U codec. ►...
  • Page 197 Gigarouter UF72N User Manual Figure 4-143 Show DSP Parameter The command “set dsp” configures DSP parameters as below: Figure 4-144 Configure DSP Parameters The following items are displayed on this screen: ► Echo Cancellation: Enable or disable echo cancellation. ► Silence Detection/Suppression: Enable or disable silence detection and silence suppression.

  • Page 198: Digitmap

    Gigarouter UF72N User Manual Smaller, Moderate, Larger, Maximum. ► DTMF Transfer Model: Select DTMF transmission mode: In-Band, INFO, RFC2833. ► RFC2833 Load Type: If RFC2833 is selected, specify payload type of RFC2833. ► T38 Max FAX Rate: Select the maximum rate, when using T38 fax mode: Unlimited, 2400bps, 4800bps, 7200bps, 9600bps, 12000bps, 14400bps.
  • Page 199 Gigarouter UF72N User Manual Figure 4-147 Show Signal Tone Parameter The command “set tone” configures signa l tone parameters as below: Page 191 of 203...
  • Page 200 Gigarouter UF72N User Manual Figure 4-148 Configure Signal Tone Parameter The following items are displayed on this screen: ► Tone Type: Select the type of signal tone. Dial Tone ► User Define Enable: Whether to use user-defined dial tone frequency. ►...

  • Page 201: Centrex

    Gigarouter UF72N User Manual ► Ring Back Tone Frequency 1: ► Ring Back Tone Frequency 2: ► On Time: ► Off Time: Distinction Ring: Specify the ring cadence for the FXS port. In these fields, you specify the on and off pulses for the ring.

  • Page 202: Phone Book

    Gigarouter UF72N User Manual Figure 4-150 Configure Centrex Parameter The following items are displayed on this screen: ► Enable Centrex: Whether to enable centrex function globally. ► Group Number: The phone number of this ring group. ► Ringing Policy: Phone ringing policy: Alternate, Ordinal, Parallel. ►...
  • Page 203 Gigarouter UF72N User Manual Figure 4-151 Show Phone Book Parameter The command “set callroute” configures telephone book parameters as below: Figure 4-152 Configure Phone Book Parameter The following items are displayed on this screen: ► Phone Prefix: The prefix of this phone book. ►...

  • Page 204: Save And Reload Voip Parameter

    Gigarouter UF72N User Manual ► Description: Description of this rule. 4.4.10 Save and Reload VOIP Parameter VOIP parameter will take effect after save and reload commands: Figure 4-153 Save and Reload Parameter 4.5 System 4.5.1 Time Management The command “show time-management” show the time management information as below: Figure 4-154 Show Time Management Information The command “set time-management”...
  • Page 205 Gigarouter UF72N User Manual Figure 4-155 Configure Time Management Parameters The following items are displayed on this screen: Enable NTP: Enable or disable NTP. ► Enable DST: Enable or disable the Daylight Saving Time(DST). ► DST Offset: Enter the offset of DST. ►...

  • Page 206: Reboot System

    Gigarouter UF72N User Manual 4.5.2 Reboot System Enter command “reset” to reset the device. 4.5.3 Backup/Restore The command "load config" backup/restore the configurations as blow. Enter 0 to save current parameters as custom default configurations, Enter 1 to reset to custom default parameters, Enter 2 to reset to factory parameters.

  • Page 207: Tr069

    Gigarouter UF72N User Manual Figure 4-158 Show System Log Information The command “set syslog” configure the system log parameters as below. Figure 4-159 Configure System Log Parameters The following items are displayed on this screen: 4.5.6 TR069 The command “show tr069” show the tr069 information as below: Page 199 of 203...
  • Page 208 Gigarouter UF72N User Manual Figure 4-160 Show TR069 Information The command “set tr069” configure the tr069 parameters as below. Figure 4-161 Configure TR069 Parameters The following items are displayed on this screen: ► Serial Number: The serial number of device. Read only. ►...
  • Page 209 Gigarouter UF72N User Manual ► ACS Address: Enter the IP address or domain name of ACS. ► ACS Port: Enter the port of ACS. ► ACS Server Name: Enter the TR069 server name of ACS. ► SSL Enable: Enable or disable the SSL(Secure Sockets Layer) for TR069. ►...
  • Page 210 Gigarouter UF72N User Manual The command “set snmp” configure the snmp parameters as below. Figure 4-163 Configure SNMP Parameters The following items are displayed on this screen: ► Register Enable: Check this box to enable SNMP register. ► Server Address or Domain: Enter the IP address or domain name of register server.

Table of Contents
