IoT-Cloud 2.0 Configuration Software User Guide
1. Connect IoT-Cloud to the PC using a MicroUSB cable. Flip the power switch to the right. If you
plan to use IoT-Cloud while connected to a secondary Ethernet port on your computer, plug in
an Ethernet cable to IoT-Cloud and the PC as well.
2. Open the IoT-Cloud configuration software (cloudConfigured.exe) and open the COM port
associated with IoT-Cloud.
X-Z LAB, Inc.
|
Bishop Ranch 6
|
2440 Camino Ramon, Suite #264
Office: (925) 359-6908
|
San Ramon, CA 94583
|
Fax: (925) 380-6784
|
United States
Advertisement
Summary of Contents for X-Z Lab IoT-Cloud 2.0
- Page 1 IoT-Cloud 2.0 Configuration Software User Guide 1. Connect IoT-Cloud to the PC using a MicroUSB cable. Flip the power switch to the right. If you plan to use IoT-Cloud while connected to a secondary Ethernet port on your computer, plug in an Ethernet cable to IoT-Cloud and the PC as well.
- Page 2 3. Once the port is opened, the log will display the PC name, local IP address, and local gateway. 4. Click the Connect button to retrieve IoT-Cloud’s MAC address, IP address, port, and gateway. If successful, the log will indicate the status “Connected!” X-Z LAB, Inc. Bishop Ranch 6 2440 Camino Ramon, Suite #264...
- Page 3 6. Open RadSuite-Monitor and click on the gear icon. Click on System Settings and enter IoT- Cloud’s IP address and port, which were configured in step 8. Click OK to save changes. Once a proper Ethernet connection is established, IoT-Cloud will connect to RadSuite-Monitor. X-Z LAB, Inc. Bishop Ranch 6 2440 Camino Ramon, Suite #264...
