Aeotec ZW098 Manual

Aeotec by Aeon Labs LED Bulb.
1
Make any light a smart light.
LED Bulb brings the connected light bulb to Z-Wave. Offering
the perfect shades of cool and warm light, along with 16 million
shades of other coloured light, LED Bulb is the modern light bulb
as it should be: connected, controllable and perfectly considered.
LED BULB
2 Familiarise yourself with your LED Bulb.
View the expanded manual:
http://aeotec.com/support
Your LED Bulb contains all its technology within its silver and white
exterior. It has no external buttons.
ADDED WEIGHT OF THE DEVICE MAY CAUSE INSTABILITY
OF A FREE-STANDING PORTABLE LUMINAIRE.
THIS DEVICE IS NOT INTENDED FOR USE WITH
E M E R G E N C Y E X I T S O R N O T F O R E M E R G E N C Y
LIGHTING.
SUITABLE FOR USE IN ENCLOSED LUMINAIRES.
Quick start. Using LED Bulb.
3
With your LED Bulb now a part of your smart home, you'll be able
Getting your LED Bulb up and running is as simple as inserting it
into a lamp holder and adding it to your existing Z-Wave network. to schedule, configure and control it your Z-Wave gateway. Please
refer to the relevant pages of your gateway's user manual for
You'll need to set your Z-Wave hub to accept new products; to do
instructions on configuring LED Bulb to your needs.
this, please refer to its user manual.
Please note that the wall switch controlling LED Bulb needs to be
left in the on position in order for LED Bulb to function within your
Wall Switch Z-Wave network. In the off position, LED Bulb will not be able to
draw power and will not be remotely controllable nor be able to
serve as a Z-Wave repeater.
4 Advanced functions.
1. Toggle off the wall switch into the OFF position.
2. Remove any existing light bulb and replace it with LED Bulb.
Manually changing LED Bulb's colour.
3. Set your Z-Wave gateway to accept new products.
LED Bulb can fill your room with multiple shades of white and
4. With LED Bulb in its fitting, wait 2 seconds. Now toggle your
an additional 16 million different colours. It's possible to manually
wall switch ON. LED Bulb's green LED will blink to indicate that it
select some of these without the use of your Z-Wave gateway. To
is looking for a Z-Wave network to connect to.
do this;
5. After successfully connecting to your network, LED Bulb will
1. Toggle LED Bulb off, on, off, on in quick succession via its wall
illuminate. If a network connection has failed, it will remain
switch. LED Bulb has now entered colour cycle mode and will
without light.
cycle through the following colours: warm white, cold white, red, Security inclusion.
orange, yellow, green, cyan, blue and purple.
1. Set your Z-Wave hub into pairing mode.
2. When the colour cycle arrives at the colour you'd like to select,
2. Toggle off the wall switch controlling your LED Bulb to turn it
toggle off LED Bulb via the wall switch. The visible colour will be
off (keep it in the "OFF" state for 2 seconds) and then quickly
set as your bulb's default.
toggle on the wall switch on, off, on, off, on. The blue LED will
blink to indicate the Bulb is entering into secure pairing mode.
Removing LED Bulb from a Z-Wave network.
3. If LED Bulb has been successfully added to your Z-Wave
Your LED Bulb can be removed from your Z-Wave network at any
network, its RGB LED will be solid when you turn LED Bulb on.
time using your Z-Wave gateway. To set your gateway into removal
mode, please refer to the respective section of is user manual.
5 Manual configuration.
1. Set your Z-Wave gateway into device removal mode.
You may wish to manually configure LED Bulb via Z-Wave
2. Turn LED Bulb's wall switch on.
command classes through your gateway. What follows is a list of
3. Toggle LED Bulb's wall switch off, on, off, on, off, on in fast
the associated information.
succession.
4. LED Bulb should now be removed from your Z-Wave network.
Colour Display Cycle Configuration.
To confirm successful removal its colour will change to orange
Parameter 37 [4 byte] will cycle the colour displayed by LED Bulb
for 2 seconds before changing to white. If removal was
into different modes:
unsuccessful, LED Bulb will blink orange for 3 seconds before
changing to red for 2 seconds. 7 6 5 4 3 2
Removing LED Bulb from your Z-Wave network will reset LED Bulb Colour Transition
Value 1 (MSB) Reserved Colour Display Cycle
to default factory settings. Style
Colour Transition Style (2 bits)
7 6 5 4 3 2 1 0
The following values correspond to 3 different transition styles
Value 2 Cycle Count
between colours:
Value 3 Colour Change Speed
Colour Transition
Value 4 (LSB) Colour Residence Time
Description
Style
0 Smooth Colour Transition.
Colour Display Mode (4 bits)
1 Fast/Direct Colour Transition.
The Colour Display Cycle field can have the following values
2 Pulsating Dimming.
corresponding to 4 different modes:
3 Inactive (keep the current configuration values).
Colour Display
Description
Cycle
Cycle Count (8 bits)
0 Single Colour Mode.
The Cycle Count is used to define the number of repetitions/
Rainbow Mode(red, orange, yellow, green, cyan, blue,
1 cycles displayed by your LED Bulb in Colour Display Cycle before
violet, pinkish).
stopping.
Multi Colour Mode(colours cycle between selected
2
colours). Cycle Count Description
3 Random Mode. 0 Unlimited.
1 0
15 Inactive (keep the current configuration values). 1 to 254 Total number of repetitions/cycles before stopping.
255 Inactive (keep the current configuration values).
4 to 14 Reserved.
Colour Change Speed (8 bits)
This field specifies the transition speed when one colour changes
to another.
Speed Description
0 to 254 0 is the slowest and 254 is the fastest.
255 Inactive (keep the current configuration values).
Colour Residence Time (8 bits)
This field specifies the length of time each individual colour is
displayed before a transition.
Colour
Description
Residence Time
0 to 254 Corresponds from 0 to 25.4 seconds.
255 Inactive (keep the current configuration values).
The table above shows a decimal representation of the settings
that can be set on parameter 37.
Parameter 38 [4 byte] can be used to set up to 8 colours to
cycle between when LED Bulb is in Multi Colour Mode. Colours
transition from Colour Index 1-8.
