Reversing Door Handle Placement
REVERSING THE DOOR:
A. Open the door to a 90 degree angle, take out the 2 screws from the lower door axis (2), remove the
door (3) and the axis plate from the door.
B. Take out the 3 hinge screws from the top right hinge (4) and remove it.
C.
at the top of the door frame.
D.
at top of the cabinet with 3 screws.
E. Install the door once correctly aligned.
WARNING: Disconnect power before removing doors.
Note:
C
6
D
7
8
E
7
B
4
A
2
3
