VBOX LITE User Manual

Register your Video VBOX to receive free scenes and our eBook on Advanced
Circuit Driving Techniques written by pro racing drivers and instructors.
www.vboxmotorsport.co.uk/register

Quick Start Guide

1. Mount the GPS antenna in the centre of your
vehicle's roof, away from roof bars or radio
antennas which can cause interference.
Note: If there is no metal underneath the antenna,
create a metallic 'ground plane' to get a reliable signal.
2. Push the antenna plug into the
3. Insert the PWR
ring to lock it in place.
Note: The Video VBOX takes about 35 seconds to
boot up, at which point the unit will beep to indicate it
is ready to use.
Securely attach the forward facing camera
4.
(marked HIGH RES) to the windscreen of your
car using the suction mount. If required, place the
Picture-in-Picture camera (marked
so that it faces the driver.
Use the 'Top' label on the camera to align. For
more precise alignment, use either the optional
preview monitor, or Video VBOX Setup software
preview function using a USB connected laptop
(see manual).
Note: Ensure the camera marked HIGH RES is
connected to the CAM1 socket, and the one marked
LOW RES is in the CAM2 socket.
GPS
connector and screw the metal
GPS antenna on vehicle roof
socket.
Ground plane needed on non-metallic surface
LOW RES)
On the SD card:
Video VBOX Setup
software
Circuit Tools software
User manual
