radiance RT801 Product Manual

RADIANCE
INSTRUMENTS PRODUCT
LTD.
MODEL

FEATURES

 Internal/external temperature display switchable
 External temperature high and low alarm setting
 Maximum / Minimum reading memory
 C / F exchange
 High accuracy
 Low battery indication
 Display Backlight
 Waterproof external sensor
 Foldaway stand
 Magnetic attachment
 Velcro magic tape fixing
 CE, NSF and RoHS compliant

SPECIFICATION

Measurement range
Accuracy
Display Resolution
Display reading update
Display Size
Battery
Battery life
Sensor cord length
Ambient temperature
Product size
Accessories

INSTALLATION

1. Plug the external sensor into unit.
2. Open the battery cover and install the battery with correct polarity positioning.
3. Unit Mounting:
a) By magnets -
b) By Velcro magic tape -
4. External sensor fixing:
a) General measurement-
b) Aquarium measurement-
5. Peel off display protective sheet.

OPERATION

C / F EXCHANGE
Press [C/F] on the backside to change temperature unit.
INTERNAL / EXTERNAL TEMPERATURE DISPLAY
Press [EXT/INT] button to display external or internal temperature.
INT: Reading from the internal sensor of the thermometer
EXT: Reading from the external sensor of the thermometer
MAXIMUM AND MINIMUM READING MEMORY
1. Press [MAX/MIN] to display maximum reading measured.
2. Press the button again to display minimum reading measured.
3. Press the button once more to display normally.
4. To reset the memory, Press and hold the button until a bar "---.-" is displayed.
5. Always reset the memory once before taking new readings.
PRODUCT MANUAL
MULTI-PURPOSE DIGITAL THERMOMETER
RT801
Internal: -10 to +50 C / -14 to +122 F
External: -50 to +70 C / -58 to +158 F
±0.5C between -20~50C , ±1C rest range
±1F between -4~122F, ±1.8F rest range
0.1
10 seconds
48(W) x 21(H) mm
3 volt, size CR2032 or equivalent x 1 piece (included)
About 10,000 hours in continuous operation
3 meters
0 ~ 50C / 32 ~ 122F
73(W) x 52(H) x 18(D) mm
1) Sensor holder x 1 pc
2) Double side tape x 1 pc
3) Battery x 1 pc
4) Velcro magic tape x 1 pc
5) External sensor x 1 pc
Attach the thermometer directly to the flat iron substance.
Wipe the desired installation place clean. Peel off one side of the protective
paper from the Velcro magic tape and attach the tape onto the recess area
under-side the magnets. Remove the protective paper from Velcro magic tape
and attach thermometer firmly onto the place.
Use the double side tape to stick the rectangular shape sensor holder onto the
desired place or use the screw provided to fix the holder. Insert the external
sensor into the sensor holder
Press the suction cup firmly onto the glass inside the aquarium tank with a depth
of about 100mm / 4'' then insert the external sensor into the suction cup.
>>>>> All rights reserved <<<<<
Version: 12
REV.: 3
06 May. 2013
PAGE 1 of 2
