Page 1: Installation Manual
RGA10 Installation Manual www.audac.eu... - Page 2 Introduction Omnidirectional outdoor FM antenna The RGA10 is an omnidirectional outdoor FM antenna designed to be used in all kinds of installations, providing the best reception of FM radio signals where any kind of radio tuner is used. The aluminum structure of the antenna ensures resistance against all weather conditions and ensures it will last for many years in highly demanding outside environments.
- Page 3 It can be attached to a pole with a diameter of 30-50mm, by means of the mounting clip in the center position of the RGA10 To connect a coaxial cable to the RGA10, the coaxial cable should be stripped as shown in the figure below. Then slide the waterproof boot over the cable outer jacket, and assemble the F-connector to the cable end.
-
Page 4: Technical Specifications
Additional information Technical specifications Frequency range 87.5 ~ 108 MHz Impedance 75 Ohm Antenna gain 4 dB Horizontal / Vertical beamwidth 360° Dimensions �� �� �� �� �� Ø 450 x 80 mm Weight 590 g Mounting 30 - 50 mm pole Contruction Aluminum Connector...
