SHD1112 MOTION DETECTOR
TM
The Motion Detector is a Z-Wave
TM
Z-Wave enabled network. Z-Wave
logo can also be used with it regardless of the manufacturer, and ours can also be
used in other manufacturer's Z-Wave
controllable to our modules, such as On/Off Module SHD2110 and Lamp Module
SHD2210. Inclusion of this Motion Detector on other manufacturer's Wireless
Controller menu allows remote turn-on of connected modules and their connected
lighting when the Detector is triggered. Z-Wave
repeaters if they support that function.
The Motion Detector is designed to detect movement in a protected area by
detecting changes in infra-red radiation levels caused, for example, when a person
moves within or across the devices field of vision, a trigger radio signal will be
transmitted.
TM
Adding to Z-Wave Network
In the rear casing, there is a tamper switch which is used to carry out inclusion,
exclusion or association. Put
inclusion/exclusion mode, press the tamper switch on the detector to complete the
inclusion/exclusion process. The Motion Detector supports one association group
with five nodes. This has the effect that when the Detector trigger, all devices
associated with Detector will be operated.
The Motion Detector will stay "awake" for ten minutes when changing the status of
tamper switch from being pressed to be released or from being released to be
pressed to allow time for configuration. (FIGURE 1)
FIGURE 1
enabled device and is fully compatible with any
TM
enabled devices displaying the Z-Wave
TM
enabled networks. This Motion Detector is
TM
nodes in the system also act as
TM
a Z-Wave Wireless Controller

Choosing A Mounting Location

The recommended position for a Motion Detector is in the corner of a room
mounted 2m from the floor. At this height, the detector will detect movement
up to 6-12m depending on adjustment. (FIGURE 2a) Also, in this position, the
100 degrees fan-shaped detection pattern can normally offer greater protection
than mounting on a flat wall. Before selecting a position for a Motion Detector
the following points should be noted:
TM
1. Do not position the detector facing a window or direct sunlight.
Detectors are not suitable for use in conservatories or draughty areas.
2. Do not position the detector directly above or facing any source of heat, eg: fires,
radiators, boiler etc.
3. Where possible, mount the detector so that the logical path of an intruder would
cut across the fan pattern rather than directly towards the detector.(FIGURE
2b)
(M)
10
8
6
4
2
0
2
4
6
8
into
10
2.0
0 2 4
FIGURE 2a

Installation

1
100
°
6 8 10 (M)
FIGURE 2b
Motion
