- Page 1 User’s Manual © 2017 iLink Professionals, Inc. www.iLinkPro.com Pg 1/24...
-
Page 2: Revision History
(electronic, mechanical, photocopying, recording, or otherwise), or for any purpose, without the express written permission of ILink Professionals, Inc. © 2017 ILink Professionals, Inc. All rights reserved. -
Page 3: Table Of Contents
Warranty ....................18 Appendix ...................... 19 Command Packet Format ................ 19 Configuration File and Command Description .......... 19 Supported Character Set and Character Mapping ........23 Display Font, Tone and Transparent Background ........24 © 2017 iLink Professionals, Inc. www.iLinkPro.com Pg 3/24... -
Page 4: Package Contents
The iTIVO-HD not only inserting transaction text on the surveillance video but it also has powerful text analyzing capability that, when coupled with external input/output (e.g. - Page 5 The above figure shows a typical setup of a transaction surveillance system using iTIVO-HD text inserters. © 2017 iLink Professionals, Inc. www.iLinkPro.com Pg 5/24...
-
Page 6: Key Features
• 4-channel RS485 board, each channel can support up to 16 devices Interface Conversion (Optional) • Parallel to serial conversion board for interfacing to internal impact printer • LPT to serial conversion module for interfacing to external parallel printer • RS232-TCPIP module © 2017 iLink Professionals, Inc. www.iLinkPro.com Pg 6/24... -
Page 7: Controls, Connections And Jumpers
VIDEO IN 1Vpp video in. Connect to camera. ECR-POS RJ45 socket for serial interfacing (RS232) to POS or ECR serial port. /COM1 VIDEO OUT 1Vpp video out. Connect to recorder or TV monitor © 2017 iLink Professionals, Inc. www.iLinkPro.com Pg 7/24... - Page 8 RS485 board. Change RS232/RS485 accordingly. ECR-POS/COM1 Port DC Power Jack Connect to ECR/POS Connect to comport supplied 12VDC adapter Video Out Video In Connect to Connect to Camera DVR or Monitor © 2017 iLink Professionals, Inc. www.iLinkPro.com Pg 8/24...
-
Page 9: Operating Modes
3. Wait for “SIMULATION” text to appear on TV monitor. 6 Programming (Important note: The iTIVO-HD text inserter now comes with Config software to make the programming must easier. Please download it from www.ilinkpro.com) 6.1 PC Programming using HyperTerminal for Windows 2000/XP Downloading Procedure (to download configuration file to the device) 1. - Page 10 [FILE][Properties][Settings][Emulation] and [ASCII Setup] 5. Click on the Call icon to connect. 3. Select [Transfer][Send Text File] and choose your configuration file on the file browser. Click OK. © 2017 iLink Professionals, Inc. www.iLinkPro.com Pg 10/24...
- Page 11 2. Power up the device and toggle (press and release) the CLR switch within 2 sec. 3. Blinking text “UPLOAD SETTINGS” is displaying on the TV monitor to indicate uploading is in progress. 4. All settings of the device are dumped on the HyperTerminal screen. © 2017 iLink Professionals, Inc. www.iLinkPro.com Pg 11/24...
-
Page 12: Restoring Factory Default Settings
4. The device is now prompting for user to confirm the restoration. A 3 sec counter is also displayed while waiting for user to press the ‘CLR’ switch. 5. Press the CLR switch to confirm the restoration. © 2017 iLink Professionals, Inc. www.iLinkPro.com Pg 12/24... -
Page 13: In And Out Connections
PIN5 IN Connection (Alarm Trigger/Cash Drawer) ECR-POS/COM2 PIN7 Dry Contact = NC or NO PIN5 Examples of External Load RELAY 12V, R=1K5 5V, R=330R Bulb Buzzer Max 1.5 watt Piezo or self-excited © 2017 iLink Professionals, Inc. www.iLinkPro.com Pg 13/24... -
Page 14: Serial Cable And Wiring
8 Serial Cable and Wiring This section shows the possible ways of wiring up the iTIVO-HD and your cash register via serial interface. It may defer depending on your cash register. Please study the serial port of your cash register carefully before choosing the correct cable wiring. - Page 15 Internal TX jumper must be short if emulation is required. Prevention of data overrun (lost of transaction data due to memory overflow if baud rate is too fast) is always guaranteed in this connection. © 2017 iLink Professionals, Inc. www.iLinkPro.com Pg 15/24...
-
Page 16: Prog/Com2 Cable And Wiring
ECR-POS/COM1 Cable and Wiring section for other alternatives. 8.3 Standard Pinout of RS-232 Interface The table below shows the standard pinout of a DTE DB-9 connector. DTE(Data Terminal Equipment) DB-9 Male (PC, POS, ECR) Signal © 2017 iLink Professionals, Inc. www.iLinkPro.com Pg 16/24... -
Page 17: Interface Conversion
Centronics printer is also known as LPT printer. This interface module, together with associated cables, converts the Centronics interface to serial interface. Please refer to LPT (Centronics) to Serial Interface Conversion, Cable and Installation document for more details. © 2017 iLink Professionals, Inc. www.iLinkPro.com Pg 17/24... -
Page 18: Operating Characteristics
C to 55 Humanity: 20 to 90% RH (Non-condensing) Physical Weight: 400g, device only. Dimension: 103L, 98W, 28H. In mm. 11 Warranty One year limited warranty from the date of purchase. © 2017 iLink Professionals, Inc. www.iLinkPro.com Pg 18/24... -
Page 19: A Appendix
FFXXXXXXXXXXXX: This field contains the 14-character fixed pattern to indicate end of packet. iTIVO-HD will return “OK” for every valid packet. Note: All values in a packet are hexadecimal format, except the end-of-packet pattern. Example... - Page 20 = 0x20 - 2B or 0x2n, where n is the index of an exception. ; LEN = 19 (0x13) ;---------------------------------------------------------------------------------------------- ; Data Field Value Default Meaning/*Default ;---------------------------------------------------------------------------------------------- ; D0 Exception_Enable 1 (0x01) disable/enable ; D1 String_Match 1 (0x01) ignore/matching ; D2 Val_Compare_Operator 0 (0x00) none/less/greater/negative/equal © 2017 iLink Professionals, Inc. www.iLinkPro.com Pg 20/24...
-
Page 21: Input Level
;---------------------------------------------------------------------------------------------- ; CMD = 0x50 ; LEN = 2 (0x02) ;---------------------------------------------------------------------------------------------- ; Data Field Value Default Meaning/*Default ;---------------------------------------------------------------------------------------------- ; D0 Parity | Baudrate 2 (0x02) 2K4/4K8/*9K6/14k4/19K2/28K8/38K4/57K6/115K2 Note1: 0x00-0x08, no parity (8-bit mode) © 2017 iLink Professionals, Inc. www.iLinkPro.com Pg 21/24... - Page 22 64 (0x40) Note: 0x00 = buzzer off ;---------------------------------------------------------------------------------------------- AA55 70 01 40 FFXXXXXXXXXXXX === Force Carriage-return (CR) === (CR is inserted when the max number of character is reached for a line) ;---------------------------------------------------------------------------------------------- © 2017 iLink Professionals, Inc. www.iLinkPro.com Pg 22/24...
-
Page 23: Supported Character Set And Character Mapping
A.3 Supported Character Set and Character Mapping Supported Character Set Alpha Numeric 0 ~ 9, a ~ z, A ~ Z Symbols $%?./:-+=_‘ Character Mapping ASCII Character iTIVO-HD Character Others Space character © 2017 iLink Professionals, Inc. www.iLinkPro.com Pg 23/24... -
Page 24: Display Font, Tone And Transparent Background
A.4 Display Font, Tone and Transparent Background © 2017 iLink Professionals, Inc. www.iLinkPro.com Pg 24/24...
