ComboXCAT-IP
KVM-over-IP Module

User Guide

Rev 1.0
®
Rackit
Technology Corporation
www.RackitTechnology.com
®
271 Madison Avenue, New York, NY 10016
Tel: (212) 679-0050 • Fax: (212) 679-0040
Technology Corporation
1 . 8 0 0 . 6 3 6 . 3 4 3 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ComboXCAT-IP and is the answer not in the manual?

Questions and answers

Related Manuals for rackit ComboXCAT-IP

Summary of Contents for rackit ComboXCAT-IP

  • Page 1: User Guide

    ComboXCAT-IP KVM-over-IP Module User Guide Rev 1.0 ® Rackit Technology Corporation www.RackitTechnology.com ® 271 Madison Avenue, New York, NY 10016 Tel: (212) 679-0050 • Fax: (212) 679-0040 Technology Corporation 1 . 8 0 0 . 6 3 6 . 3 4 3 4...
  • Page 2 Certifications This equipment has been tested and found to comply with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference (2) This device must accept any interference received, including interference that may cause undesired operation.

  • Page 3: Table Of Contents

    ............12 3.3.6 Recommended Mouse Settings............12 3.3.7 Video Modes ..................13 Usage......................13 Prerequisites....................13 ComboXCAT-IP Login and Logout ............14 4.2.1 Login into ComboXCAT-IP ..............14 4.2.2 Logging Out of ComboXCAT-IP............17 The Remote Console.................17 4.3.1 Main Window of Remote Console ............18 4.3.2 Control Bar of Remote Console............19 4.3.3...
  • Page 4 Even log ....................89 5.6.3 Update Firmware ................90 5.6.4 Unit Reset ..................91 Technical Specifications ................93 Troubleshooting ....................94 FAQs .......................96 Addendum......................98 Key Codes ....................98 Video Modes....................99 User Role Permissions ................100 ComboXCAT-IP TCP port number............101 Bandwidth Consumption................101 Well-Known TCP/UDP Port Numbers .............103 Protocol Glossary ..................104...

  • Page 5: Product Overview

    1. Product Overview Introduction ComboXCAT-IP redirects local keyboard, mouse and video data to a remote administration console. It allows you to control one or many computers locally at the server site or remotely via the Internet using a standard browser. You can securely gain BIOS level access to systems for maintenance, support, or failure recovery over the Internet.

  • Page 6: Installation And Start Up

    LEDs on the Ethernet Connector: Orange LED -- 10BaseT Ethernet connection established Green LED -- 100BaseT Ethernet connection established Blinking: data in activity ON: no data in activity and link connected ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...

  • Page 7: System Requirements

    3. Slide in ComboXCAT-IP into the KVM switch slot, making sure ComboXCAT-IP is firmly inserted into the backplane. 4. Screw and secure ComboXCAT-IP onto the KVM Switch metal panel using the same screw that originally secured the slot cover. 5. Connect an Ethernet cable to the Ethernet port.

  • Page 8: When Controlled Servers Are Up And Running

    When Controlled Servers are Up and Running ComboXCAT-IP gives you a full control over the remote servers. The Management Console allows you to access the remote servers' graphics, keyboard and mouse and to send special commands to the servers.

  • Page 9: When Controlled Servers Are Dead

    Default IP address: 192.168.0.70 Default Net Mask: 255.255.255.0 If DHCP mode is enabled (IP auto configuration = DHCP), ComboXCAT-IP will try to contact a DHCP server in the subnet to which it is physically connected. If a DHCP server is found, it may provide a valid IP address, gateway address and net mask.
  • Page 10 DHCP server. It is recommended to configure a fixed IP assignment to the MAC address of ComboXCAT-IP. You can find the MAC address labeled on the bottom side of the metal housing. There is a Network Setup Software tool (ComboXCAT-IP-Setup) for setting up the network configuration (IP address, Subnet mask, DHCP, etc).
  • Page 11 Enter Super user login and password for Authentication (default: super/pass) c. Click Setup Device. If super login was authenticated, it'll show "Successfully configured device". Otherwise it'll show "Permission Denied". ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...

  • Page 12: Configuration Setup Via Serial Console

    "Cancel" button. Configuration Setup via Serial Console For using serial terminal, ComboXCAT-IP has a serial line interface (host side). This connector is compliant with the RS-232 serial line standard. The serial line has to be configured with the parameters given in the table below.

  • Page 13: Keyboard, Mouse, And Video Configuration

    Gateway: [0.0.0.0] -- (0.0.0.0 for none) IP Auto-Configuration With this option, you can specify whether ComboXCAT-IP should get its network settings from a DHCP or BOOTP server. For DHCP, enter "dhcp", and for BOOTP enter "bootp". If you do not specify any of these, the IP auto-configuration is disabled and subsequently you will be asked for the following network settings.

  • Page 14: Comboxcat-Ip Keyboard Settings

    3.3.1 ComboXCAT-IP Keyboard Settings ComboXCAT-IP settings for the host's keyboard type have to be corrected in order to make the remote keyboard work properly. Check the settings in ComboXCAT-IP Web front-end for details. 3.3.2 Remote Mouse Settings A common seen problem with KVM devices is the synchronization between the local and remote mouse cursors.

  • Page 15: Host System Mouse Settings

    The following limitations do not apply in case of USB and Mouse Type "Windows >= 2000, MacOSX". While ComboXCAT-IP works with accelerated mice and is able to synchronize the local with the remote mouse pointer, there are the following limitations, which may...

  • Page 16: Single And Double Mouse Mode

    3.3.5 Single and Double Mouse Mode The information above applies to the Double Mouse Mode, where remote and local mouse pointers are visible and need to be synchronized. ComboXCAT-IP also features another mode, the Single Mouse Mode, where only the remote mouse pointer is visible.

  • Page 17: Video Modes

    ComboXCAT-IP recognizes a limited number of common video modes. When running X11 on the host system, please do not use any custom mode lines with special video modes. If you do, ComboXCAT-IP may not be able to detect them. We recommend using any of the standard VESA video modes, instead.

  • Page 18: Comboxcat-Ip Login And Logout

    The address used might be an IP address or a domain name, in the case where you have given your ComboXCAT-IP a symbolic name in the DNS. For instance, type the following in the URL field of your browser when establishing an unsecured connection: http://<IP address of ComboXCAT-IP >...
  • Page 19 When using a secure connection, type in: https://<IP address of ComboXCAT-IP > This will lead you to ComboXCAT-IP login page as shown below ComboXCAT-IP has a built-in super user that has all permissions to administrate your ComboXCAT-IP: Username super (factory default)
  • Page 20 Navigation Having logged into ComboXCAT-IP successfully, the main page of ComboXCAT-IP appears. This page consists of three parts; each of them contains specific information. The buttons on the upper side allow you to navigate within the front end. Within the right frame, task-specific information is displayed that depends on the section you have chosen before.

  • Page 21: Logging Out Of Comboxcat-Ip

    If there is no activity for 30 minutes, ComboXCAT-IP will log you out, automatically. A click on one of the links will bring you back to the login screen. Remote Console Preview Click on Click to open to start the remote console redirection Click on Refresh to refresh the picture.

  • Page 22: Main Window Of Remote Console

    NAT (Network Address Translation) settings have to be configured accordingly. In case ComboXCAT-IP is connected to your local network environment and your connection to the Internet is available using a proxy server only without NAT being configured, the Remote Console is very unlikely to be able to establish the desired connection.

  • Page 23: Control Bar Of Remote Console

    Figure 4-2 Remote Console Control Bar Ctrl+Alt+Delete Special button key to send the "Control Alt Delete" key combination to the remote system (see also section 6.4.1 for defining new button keys). ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...
  • Page 24 If the video display is of bad quality or distorted in some way, press this button and wait a few seconds while ComboXCAT-IP tries to detect the video mode of VGA port to the controlled host and adjust itself for the best possible video quality.
  • Page 25 In order to keep mouse pointers in sync in double mouse mode, it is recommended to disable the Enhance pointer precision in host computer if your ComboXCAT-IP connects to PS/2 host computer and select double mouse mode. A short description of the options as follows.
  • Page 26 When you designate "Scale to fit", the remote video displaying is scaled to fit the size of Remote Console window. Figure 4-5 Remote Console Options Menu:Scaling ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...
  • Page 27 Use this option if the fast sync does not work or the mouse settings have been changed on the host system. This method takes more time than the fast one and requires a correctly adjusted picture. Use the auto adjustment function to setup the picture. ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...
  • Page 28 Video Settings through the HTML-Frontend To enable local video port, select this option. This option decides if the local video output of ComboXCAT-IP is active and passing through the incoming signal from the host system. The option Noise Filter defines how ComboXCAT-IP reacts to small changes in the video input signal.
  • Page 29 Vertical Position Use the left and right buttons to move the picture in vertical direction while this option is selected. Reset this Mode Reset mode specific settings (Clock , Phase and Position) to the factory-made defaults. ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...
  • Page 30 Click to run this menu item for retrieving the whole video again from the controlled host and displayed on Remote Console. In normal situation, only changed parts of video will be packed and sent from ComboXCAT-IP, for saving network bandwidth. This function is mainly used for troubleshooting purpose where some old video fragments are displayed as not updated in time for some reason;...
  • Page 31 A confirmation dialog can be added that will be displayed before sending the selected command to the remote host. Select "OK" to execute the command on the remote host. ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...
  • Page 32 In this case the video compression is disabled, completely and all video data is transferred via network as full-quality video snippets. Therefore, a high amount of bandwidth is required to ensure the quality of the video picture. ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...
  • Page 33 The next two options allow you to set the compression level to a predefined level OR to set a level for "lossy" compression. This compresses well, but leads to degradation in image quality. Figure 4-12 Predefined Compression ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...
  • Page 34 Optimized/compression level 0, or between 1 and 8 bit for compression level 1 to 9. The higher the color depth, the more video information has to be captured and to be transferred. Figure 4-14 Encoding Color depth ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...

  • Page 35: Status Line Of Remote Console

    (in kb/s). If compressed encoding is enabled, a value in brackets displays the compressed transfer rate. Figure 4-16 Status line transfer rate For more information about Monitor Only and Exclusive Access settings, see related sections ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...

  • Page 36: Menu Options

    Remote Control The Remote Console is the redirected screen, keyboard and mouse of the remote host system that ComboXCAT-IP controls. The Remote Console window is a Java Applet that tries to establish its own TCP connection to ComboXCAT-IP. Starting the Remote Console opens a new window displays screen movement of host system, with its size automatically adjusted to optimum.

  • Page 37: Kvm Console

    To open the KVM console either click on the icon Console or Remote Control > KVM Console of the menu entry on the left or Click to open of the console picture on the right. ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...

  • Page 38: Telnet Console

    220 terminal or an according emulation, it is even possible to perform a console redirection as long as ComboXCAT-IP host machine is using a text mode screen resolution. Connecting to ComboXCAT-IP is done as usual and as required by the Telnet client, for instance in a UNIX shell: telnet 192.168.0.70 Replace the IP address by the one that is actually assigned to ComboXCAT-IP.
  • Page 39 Exits the current session and disconnects from the client version Displays the release information terminal Starts the terminal passthrough mode for serial port 1. The key sequence esc exit switches back to the command mode. ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...

  • Page 40: Virtual Media

    Before you go ahead with this setup, make sure both remote computer and local computer (the one connected to ComboXCAT-IP unit) would have to be running Win2000, XP or above operating systems. This function would not work on any other platforms.

  • Page 41: Floppy Disk

    1. You need to create the floppy to an image file first. 2. In this example, we use RawWrite software (or any other image-creator software) to create floppy image. Please use licensed software for this purpose. ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...
  • Page 42 3. You can find an image file saved at desire destination after you created it with RawWrite. 4. Open the browser to log into ComboXCAT-IP. Click Virtual Media > Floppy Disk. Click the Browse button to choose the image file.
  • Page 43 'img', e.g. floppy_vir.img. 2. The uploaded image file will be kept in the onboard memory of ComboXCAT-IP until the end of the current session, as you logged out, or initiated a reboot of ComboXCAT-IP. ComboXCAT-IP User Guide...

  • Page 44: Cd-Rom Image

    Sharing => Permission settings) 3. Copy the CD-ROM ISO image file to this sharing folder. 4. Please fill in the sharing information as below picture. ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...
  • Page 45 Please fill in the 'Sharing Folder Permission' username and password 5. Image file set successfully. 6. Open the remote console and you can see the virtual CD as picture below. ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...
  • Page 46 To register the specified file image and its location click on the button "Set". The specified image file is supposed to be accessible from ComboXCAT-IP. The information above has to be given from the point of view of ComboXCAT-IP. It is important to specify correct IP addresses, and device names. Otherwise, ComboXCAT-IP may not be able to access the referenced image file.
  • Page 47 Choose an appropriate name for the share. You may also add a short description for this folder (input field "Comment"). ■ If necessary, adjust the permissions (button "permissions"). ■ Click "OK" to set the options for this share. ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...

  • Page 48: Drive Redirection

    This may confuse the remote host's operating system. We recommend to use the Drive Redirection with care, especially the write support. ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...
  • Page 49 Click Apply to submit your changes. There are two methods of Drive Redirections: 1. External Drive Redirection Utility 2. Built-in Java Drive Redirection function in Remote Console ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...

  • Page 50: Driver Redirection Utility Installation

    5.2.3.1 Driver Redirection Utility Installation Follow the Drive Redirection Setup Wizard step by step to install the driver. Figure 5-8 Drive Redirection Setup ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...
  • Page 51 Figure 5-9 Drive Redirection dialog Drive Redirection Utility: Device This is the address (either the DNS name or the IP address) of ComboXCAT-IP you would like to connect to. Drive The local drive you want to share with the remote computer, which could be Floppy disc, CD-ROMs, USB-Sticks and hard drives.
  • Page 52 3. While connecting to a legacy KVM switch, please select PS/2 mouse for Keyboard/Mouse setting from webpage. Otherwise you will not be able to use Hot-key. ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...
  • Page 53 You can access the software by its tray icon. The tray icon also shows whether a connection is established or not. A double click on the icon shows the application window, or with a right click you may access a small menu ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...
  • Page 54 Type the IP address of ComboXCAT-IP b. Choose the hard drive on remote computer you intended to share c. Type the username and password of 'ComboXCAT-IP' d. Click 'Connect' to create virtual drive on host computer ComboXCAT-IP User Guide...

  • Page 55: Built-In Java Drive Redirection

    DVD-Drive with the same procedure. However, this DVD-Drive Does NOT support Bootable function like Floppy and CD-ROM emulation. 5.2.3.2 Built-in Java Drive Redirection 1. Run Remote Control > KVM Console. 2. Click "Floppy" icon ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...
  • Page 56 Figure 5-10 Built-in Java Drive Redirection ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...
  • Page 57 3. Click Connect Drive or Connect ISO 4. Select a drive to redirect (if Connect Drive) 5. Select a ISO image to redirect (if Connect ISO) ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...

  • Page 58: Options

    [ if=/dev/fd0 ] [ of=/tmp/floppy.image ] dd reads the entire disc from the device /dev/fd0, and saves the output in the specified output file /tmp/floppy.image. Adjust both parameters exactly to your needs (input device etc.) ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...

  • Page 59: Creating Cd-Rom/Iso Images

    UNIX-like OS (UNIX, Sun Solaris, and Linux). To create a CD-ROM image file, copy the contents of the CD-ROM to a file. You can use the following command: dd [ if=/dev/cdrom ] [ of=/tmp/cdrom.image ] ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...
  • Page 60 "Copy Disc" section. Select the CD-ROM or DVD drive you would like to create an image from. Specify the filename of the image, and save the CD-ROM content in that file. Figure 5-13 Nero selection dialog ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...

  • Page 61: User Management

    Change password of currently logged in user: Old Password: type in current password New Password: type in new password Confirm New Password: re-type new password for verification Click "Apply" to submit your changes. ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...

  • Page 62: Users And Groups

    User -- Has permission to access basic function of open Remote Console You can choose the desired level from the selection box role. ComboXCAT-IP comes with 1 pre-configured user account that has fixed permissions. The account "super" has all possible rights to configure the device and to use all functions ComboXCAT-IP offers.
  • Page 63 To guarantee an acceptable response time we recommend not to exceed the number of 15 users connected to ComboXCAT-IP at the same time. The memory space that is available onto ComboXCAT-IP mainly depends on the configuration and the usage of ComboXCAT-IP (log file entries etc.).

  • Page 64: Kvm Settings

    The following settings are user specific. That means, the super user can customize these settings for every users separately. Changing the settings for one user does not affect the settings for the other users. ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...
  • Page 65 Figure 5-15 User Console Setting ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...
  • Page 66 Allows to adjust both compression rate and the colour depth individually. Depending on the selected compression rate the data stream between ComboXCAT-IP and the Remote Console will be compressed in order to save bandwidth. Since high compression rates consum more computing power of ComboXCAT-IP, they should not be used while several users are accessing ComboXCAT-IP simultaneously.
  • Page 67 Remote Consoles of all other users to close. No one can open the Remote Console at the same time again until this user disables the exclusive access or logs off. ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...
  • Page 68 In this case all pressed keys should be released in reversed sequence. The minus sign builds single, separate key presses and releases. The star inserts a pause with duration of 100 milliseconds. ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...

  • Page 69: Keyboard/Mouse

    Mouse Speed Auto Mouse Speed Use this option if the mouse settings on host use an additional acceleration setting. ComboXCAT-IP tries to detect the acceleration and speed of the mouse during the mouse sync process. Fixed Mouse Speed Use a direct translation of mouse movements between the local and the remote pointer.

  • Page 70: Video

    Miscellaneous Video Settings Noise Filter This option defines how ComboXCAT-IP reacts to small changes in the video input signal. Turning on the noise filter can help reduce video flickering that is often caused by distortions, as well as lowering unnecessary bandwidth consumption. A large filter setting needs less network traffic and leads to a faster video display, but small changes in some display regions may not be recognized immediately.

  • Page 71: Device Settings

    Device Settings ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...

  • Page 72: Network

    The Network Settings panel allows changing network related parameters. Each parameter will be explained below. Once applied the new network settings will immediately come into effect. Figure 5-18 Network Settings ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...
  • Page 73 ComboXCAT-IP. IP Auto Configuration With this option you can control if ComboXCAT-IP should fetch its network settings from a DHCP or BOOTP server. For DHCP, select "dhcp" , and for BOOTP select "bootp" accordingly. If you choose "none" then IP auto configuration is disabled.
  • Page 74 Port number at which ComboXCAT-IP's Telnet server is listening. If left empty the default value will be used. SSH Port Port number at which ComboXCAT-IP SSH (Secure SHell) server is listening to. If left empty the default value (port 22) will be used. Bandwidth Limitation The maximum network traffic generated through ComboXCAT-IP ethernet device.

  • Page 75: Dynamic Dns

    5.5.2 Dynamic DNS Figure 5-19 Dynamic DNS A freely available Dynamic DNS service (www.dyndns.org) can be used in the following scenario. Figure 5-20 Dynamic DNS Scenario ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...
  • Page 76 IP address belonging to his card. The administrator has to register a ComboXCAT-IP that is supposed to take part in the service with the Dynamic DNS Server and assign a certain hostname to it. He will get a nickname and a password in return to the registration process.

  • Page 77: Security

    You have used this password during your manual registration with the Dynamic DNS Server. Check Time ComboXCAT-IP registers itself for initiating the IP address of ComboXCAT-IP stored in the Dynamic DNS server at this time. Check Interval This is the interval for reporting again to the Dynamic DNS server for updating the IP address associated with the Domain Name of ComboXCAT-IP.
  • Page 78 This is the IP filtering function, it keeps unauthorized hosts from accessing to ComboXCAT-IP by specifying IP filtering rules. It is important to fully understand what an IP filter is. If you don't fully understand this, you will get unexpected results against your original plan.
  • Page 79 Figure 5-22 Chain Rules of IP Filtering Check the "Enable Group based System Access Control" to edit the rules ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...
  • Page 80 Users can add a new IP filtering rule by setting the properties at adding line by Append or Insert. User can remove a rule by Remove or Delete. Figure 5-23 IP Filter Settings ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...

  • Page 81: Certificate

    However, it is possible to generate and install a new base64 X.509 certificate that is unique for a particular ComboXCAT-IP. In order to do that, ComboXCAT-IP is able to generate a new cryptographic key and the associated Certificate Signing Request (CSR) that needs to be certified by a certification authority (CA).
  • Page 82 CA after a more or less complicated traditional authentication process (depending on the CA). ■ Upload the certificate to ComboXCAT-IP using the "Upload" button as shown in Figure below. Figure 5-25 SSL Certificate Upload ComboXCAT-IP User Guide...
  • Page 83 After completing these three steps, ComboXCAT-IP has its own certificate that is used for identifying the card to its clients. If you destroy the CSR on ComboXCAT-IP there is no way to get it back! In case you deleted it by mistake, you have to repeat the three steps as described above.
  • Page 84 Confirm Challenge Password Confirmation of the Challenge Password Email The email address of a contact person that is responsible for ComboXCAT-IP and its security. Key Length This is the length of the generated key in bits. 1024 Bits are supposed to be sufficient for most cases.

  • Page 85: Serial Port

    5.5.5 Serial Port Figure 5-27 Serial Port ComboXCAT-IP Serial Settings allows you to specify what device is connected to the serial port and how to use it. Configuration or Console Login Do not use the serial port for any special function, use it only for the initial configuration.
  • Page 86 Since it is a point-to-point IP connection virtually every IP address is possible but you must make sure, it is not interfering with the IP settings of ComboXCAT-IP and your console computer. The default value will work in most cases.

  • Page 87: Date / Time

    Without a timeserver, your time setting will not be persistent, so you have to adjust it again, after ComboXCAT-IP loses power for more than a few minutes. To avoid this, you can use a NTP timeserver, which sets up the internal clock automatically to the current UTC time.

  • Page 88: Event Log

    Each of those events belongs to an event group, which can be activated separately. The common way to log events is to use the internal log list of ComboXCAT-IP. To show the log list, click on "Event Log" on the "Maintenance" page. In the Event Log ComboXCAT-IP User Guide Rackit Technology Corporation –...
  • Page 89 List Logging Enabled The common way to log events is to use the internal log list of ComboXCAT-IP . To show the log list, click on "Event Log" on the "Maintenance" page. Since ComboXCAT-IP's system memory is used to save all the information, the maximum number of possible log list entries is restricted to 1.000 events.
  • Page 90 Login succeed. Auth In contrast to the internal log file on ComboXCAT-IP, the size of the NFS log file is not limited. Every log event will be appended to the end of the file so it grows continuously and you may have to delete it or move it away from time to time.

  • Page 91: Maintenance

    Maintenance 5.6.1 Device Information Figure 5-30 Device Information ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...
  • Page 92 This section contains a summary with various information about this ComboXCAT-IP and it's current firmware and allows you to reset the card. The Data file for support allows you to download ComboXCAT-IP data file with specific support information. This is an XML file with certain customized support information like the serial number etc.

  • Page 93: Even Log

    5.6.2 Even log Figure 5-32 Event Log List The figure above displays the log list including the events that are logged by ComboXCAT-IP ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...

  • Page 94: Update Firmware

    Figure 5-33 Update Firmware ComboXCAT-IP is a complete standalone computer. The software it runs is called firmware. The firmware of ComboXCAT-IP can be updated remotely in order to install new functionality or special features. A new firmware update is a binary file which will be sent to you by email or which you can download from the supplier web site.

  • Page 95: Unit Reset

    Figure 5-34 Unit Reset This section allows you to reset specific parts of the device. This involves the both keyboard and mouse, the video engine and ComboXCAT-IP itself. Resetting the card ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...
  • Page 96 The whole process will take about half a minute. Resetting sub devices (e.g. video engine) will take some seconds only and does not result in closing connections. To reset a certain ComboXCAT-IP functionality click on the button Reset. Note: Only the super user is allowed to reset ComboXCAT-IP.

  • Page 97: Technical Specifications

    DHCP, PPP, SMTP, NTP, DDNS SSL 256-bit encryption of all transmitted data Security RSA 1024-bit encryption SSHv2 Authentication SSL / Certificate Floppy/CD-ROM/USB/HD drive redirection Virtual Media Floppy//CD-ROM ISO Image redirection ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...

  • Page 98: Troubleshooting

    Check whether the network connection is working in general (ping the IP address of ComboXCAT-IP). If not, check network hardware. Is ComboXCAT-IP powered on? Check whether the IP address of ComboXCAT-IP and all other IP related settings are correct! Also verify that all the IP infrastructure of your LAN, like routers etc., is correctly configured.
  • Page 99 Make sure your browser cache settings are feasible. Especially make sure the cache settings are not set to something like "never check for newer pages". Otherwise ComboXCAT-IP pages may be loaded from your browser cache and not from the card.

  • Page 100: Faqs

    Adjust the Brightness setting until the pinkish tint is reduced or eliminated. 2. Does any software require on servers which connect to ComboXCAT-IP? No, ComboXCAT-IP is a 100% hardware solution. No extra software require on servers. ComboXCAT-IP User Guide...
  • Page 101 9. Local mouse and remote mouse didn't sync after doing mouse Intelligent Sync. Please don't put window on left-up corner of remote console of ComboXCAT-IP. Intelligent Sync has to re-calculate the coordinate of mouse from left-up corner on remote console.

  • Page 102: Addendum

    , TILDE ESCAPE, ESC LEFT -, MINUS DOWN =, EQUALS RIGHT NUM LOCK NUMPAD0 <, LESS NUMPAD1 NUMPAD2 NUMPAD3 /, SLASH NUMPAD4 BACK SPACE NUMPAD5 NUMPAD6 NUMPAD7 NUMPAD8 ENTER PRINTSCREEN NUMPAD9 ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...

  • Page 103: Video Modes

    WINDOWS MENU B. Video Modes Table below lists the video modes ComboXCAT-IP supports. Please don't use other custom video settings besides of these. If done so, ComboXCAT-IP may not be able to detect them. Resolution (x, y) Refresh Rates (Hz)

  • Page 104: User Role Permissions

    Settings) KVM Settings: Keyboard/Mouse KVM Settings: Video Device Settings Maintenance: Device Information Maintenance: Event Maintenance: Update Firmware Maintenance: Unit Keyboard/ Keyboard/ Keyboard/ Reset Mouse, Video Mouse, Video Mouse, Video, Device ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...

  • Page 105: Comboxcat-Ip Tcp Port Number

    Color Depth configuration in order to match the different bandwidth limitations of the network type (UMTS, ISDN, etc.) The following suggested network bandwidth planning table for ComboXCAT-IP installation is from the test results with 3D-Labyrinth screen saver at Resolution 800x600, the worst case consuming the highest network bandwidth.
  • Page 106 16 colors kb/s ISDN/Modem 2 bit 13 - 17 gray scale V.90 kb/s GPRS/HSCSD 8 2 bit gray scale kb/s GSM Modem 9 (best 1 bit black&white video compression) kb/s ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...

  • Page 107: Well-Known Tcp/Udp Port Numbers

    SMTP (Simple Mail Transfer Protocol) Time TCP, UCP RLP (Resource Location Protocol) TACACS, TACACS+ BOOTP server BOOTP client TFTP Gopher Finger HTTP POP3 NNTP (Network News Transfer Protocol) 161/162 SNMP HTTPS ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...

  • Page 108: Protocol Glossary

    A protocol used to synchronize time on networked computers and equipment. PAP (Password Authentication Protocol) A method of user authentication in which the username and password are transmitted over a network and compared to a table of name-password pairs. ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...
  • Page 109 SSH (Secure Shell) A secure transport protocol based on public-key cryptography. Telnet A terminal protocol that provides an easy-to-use method of creating terminal connections to a network host. ComboXCAT-IP User Guide Rackit Technology Corporation – www.rackittechnology.com – 1-800-636-3434...
