Summary of Contents for Chord Micro MU
- Page 1 Micro MU MIDI Control Station Item ref: 169.010UK User Manual Caution: Please read this manual carefully before operating Damage caused by misuse is not covered by the warranty Version 2.0...
-
Page 2: Table Of Contents
Contents Introduction ....................... 3 Features ......................3 Parts and their functions ..................3 Setup ......................... 5 Making detailed settings ..................5 Global MIDI channel .................... 5 Keyboard CC mode channel ................. 5 Transpose ......................5 Pitch bend speed ....................5 Key velocity curve .................... -
Page 3: Introduction
In order to make best use of this product, it will be necessary to make some settings in whichever software package is being used so that the Micro MU is recognized as a controller and its functions are operable within the application. -
Page 4: Parts And Their Functions
5. Bank button The Micro MU has four banks. When the BANK button is on, you can use the [◄] button and the [►] button to switch between the four banks. A “bank” is a set of parameter assignments for the controllers (pads and knobs, etc.). -
Page 5: Setup
(Windows 98, Me, NT or 2000 not supported) Making detailed settings The following settings cannot be edited on the Micro MU instrument, so you need to use the Micro MU Editor software for these. The Micro MU control Editor can be downloaded from www.avsl.com. -
Page 6: Trigger Pads
Trigger pads Depending on the assign type, the trigger pads can transmit note messages or control change messages. For each trigger pad, you can individually specify the assigned message, the MIDI transmit channel, the behavior of the trigger pad, the note number, the control change number and the values transmitted when the pad turns on or off. -
Page 7: Knobs
Momentary The Note On or On Value will be transmitted when you press the trigger pad, and the Note Off or Off Value will be transmitted when you release it. Toggle The pad will act as a latching switch-pressing once for “ON” and again for “OFF” alternately. Note Number [C-1...G9/No Assign] This specifies the note number of the note message that is transmitted. -
Page 8: Sliders
Enable [Disable/Enable] Enables or disables the rotary knob. When disabled, turning the control will not transmit a MIDI message. Control Change Number [0...127] Specifies the control change number of the control change message that is transmitted. Left Value [0...127] Specifies the value of the control change message transmitted when you turn the knob all the way to the left. Right Value [0...127] Specifies the value of the control change message transmitted when you turn the knob all the way to the right. -
Page 9: Keyboard Operation In Edit Mode
Control Change Number [0...127] Specifies the control change number of the control change message that is transmitted. Upper Value [0...127] Specifies the value of the control change message transmitted when you move the slider all the way upward. Lower Value [0...127] Specifies the value of the control change message transmitted when you move the slider all the way downward. -
Page 10: Specifications
Key Enable [Disable/Enable] Enables or disables the key. If a key is disabled, operating that key will not transmit a MIDI message. Key Behavior [Momentary/Toggle] Selects one of the following two modes: Momentary Pressing the key will send a control change message with the “ON” value, releasing the key will send a control change message with the “OFF”...
